- Page 1 Manual CTA CT-HDVD-HDCX-IR-V2 Kit - Includes Transmitter and Receiver User Manual CT-HDVD-HDCXIR-RX-V2 Additional Receiver User Manual...
- Page 2 Table of Contents 1. Safety Instructions ......................2 2. Introduction .........................3 3. Features ........................3 4 Package Contents ......................3 5. Installation Requirements ...................3 6. Panel Descriptions....................4-5 7. IR Remote Control ......................6 8. Connections........................7 9. Specifications ......................8 10. Warranty ......................9-10 1. Safety Instructions The lightning flash with arrowhead symbol, within an equilateral triangle, indicates the presence of uninsulated dangerous voltage within the product that could pose a risk of electric shock to users.
- Page 3 2. Introduction The CT-HDVD-HDCX-IR-V2 has been designed to convert HDMI signals up to 1080p for trans- mission over a single75 ohm RF coaxial cable such as RG6, RG59 or RG11. The transmitter uses a 64 QAM mode to achieve long distance transmission with minimal signal degradation, and a source can easily be set up for one to one transmit and display.
- Page 4 6. Panel Descriptions CT-HDVD-HDCX-IR-V2 Transmitter Rear Panel 1. RF Out 4. USB (S/W update) 2. HDMI Out ( pass through) 5. Input 12 V DC Power Adapter (Included) 3. HDMI In CT-HDVD-HDCX-IR-V2 Transmitter Front Panel 1. Display Screen 3. Channel Up Button 2.
- Page 5 6. Panel Descriptions CT-HDVD-HDCX-IR-V2 Receiver/ CT-HDVD-HDCXIR-RX-V2 Rear Panel 1. RF Signal Receiver 3. IR Receiver Extension Cable Interface 2. HDMI Output 4. Input 12V DC Power Adapter(Included) CT-HDVD-HDCX-IR-V2 Receiver/CT-HDVD-HDCXIR-RX-V2 Front Panel 1. Display Screen 3. Channel Up Button 2. Channel Down Button 4.
- Page 6 7. IR Remote Control The IR remote is used solely to change the receive channel of the RX device at the TV. This channel selection is for the receivers only, and is not passed across the coax to the transmitter(s). 1.
- Page 7 8. Connections One Transmitter to One Receiver Connection One Transmitter to Multiple Receivers Connection Multiple Transmitters to Multiple Receivers Connection...
- Page 8 9. Specifications Specifications 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, HDMI Input 1080i@50/60Hz, 1080p@50/60Hz HDMI Output Pass through RX HDMI Output 1080p@60Hz Video Encoding H.264 Audio Encoding MPEG2 Frequency Range 177-213MHz, 473-857MHz Effective Bit Rate Max. 23.75 bits RF Out 40 dBuV RF RX Sensitivity -74dBm RF Interface...
- Page 9 CABLETRONIX - 2 Years Limited Warranty CABLETRONIX. (the “Company”) warrants to the Original Purchaser that the item purchased is free from defects in workmanship or material under normal use. This warranty starts on the date of shipment of the hardware to the Original Purchaser.
- Page 10 the possibility of such damages, or for any claim brought against your by another party. Jurisdic- tions vary with regard to the enforceability of provisions excluding or limiting liability for incidental or consequential damages. You should check the laws of your local jurisdiction to find out whether the above exclusion applies to you.
