- Page 1 Instruction Manual DIPO INDUCTION COOKERS AND WARMERS DC23 Version 2 DCP23 Version 2 DCR23 Version 1 DWR04 Version 2 DWU05 Version 1...
- Page 2 CONTENTS PARTS INCLUDED Product Features Induction unit (appropriate model) ▪ Specifications Temperature probe (DCP23 only) ▪ Parts Included Control panel (DCR23 only) ▪ Safety Instructions Cleaning & Maintenance Instruction Manual ▪ Installation Any damage to the appliance as a result of Operation freight must be reported to the Freight Suitable Pots...
- Page 3 Return to manufacturer or authorised repairer for repair prior to use. This appliance contains no user-serviceable parts. Roband Australia, one of our agents, or a similarly qualified person(s) should carry out repairs. Keep cord away from heated surfaces.
- Page 4 INSTALLATION Remove all packaging materials, tape, and any protective plastic from the machine. Remove any glue residue from the protective plastic or tape using citrus cleaner. Place the product on a firm, level surface in the desired position. Install at least 100mm from combustible materials and a least 50mm from any other appliance.
- Page 5 OPERATION DC23 Note: DC23 has 10 steps when operating on the “heat” function, and 7 steps when operating on the “warm” function. DCP23 Note: DCP23 has 10 steps when operating on the “heat” function, and 7 steps when operating on the “warm”...
- Page 6 Timer Function only available on DCP23 SUITABLE POTS 5. Using the Timer Function: • Press the power button to turn the unit on. • Press Timer Button. At first, “720” will be displayed. • Press the “Min/Sec” button. “720” will blink. Base of Pot/Pan - Pot/Pan must have a flat Bottom By turning the “Control Knob”...
- Page 7 TROUBLESHOOTING Check that the temperature sensor is If the unit does not function check the following connected to the product correctly. points before calling for service. “E5” means that the Symptoms Action sensor is not connected. Check that the unit is Turn off and unplug the plugged in.
- Page 8 CIRCUIT DIAGRAM Figure 1 - DC23 Figure 2 - DCP23 Figure 3 - DCR23 and DWR04 Figure 4 - DWU05...
- Page 9 NOTES...
- Page 10 NOTES...
- Page 11 Tubular Heating Elements is not a warranty fault. Roband or any subsidiary company or Agent shall not be liable for loss of profit or damage to other equipment and property except where it is in breach of the guarantees provided in accordance with applicable legislation.
- Page 12 © Copyright 2024 – Roband Australia Pty Ltd ® All rights reserved. No part of this work may be reproduced or copied in any form or by any means, electronic or mechanical, including photocopying or posting to a website, without the written permission of the publisher.
