Refrigerator
Service manual
- Notice -
This Service Manual is only intended for use by properly trained and authorized service technicians.
not properly quali ed. This Manual is not intended to be all-encompassing. You should read, in its
necessary information needed to perform eld-service repairs. Read all Information and instructions
for any test or procedure before attempting it. Be sure to determine if you have the necessary
skills,tools and test equipment before beginning a speci c task.
Advertisement
Table of Contents
Related Manuals for Beko BFBD30216SS
Summary of Contents for Beko BFBD30216SS
- Page 1 Refrigerator Service manual - Notice - This Service Manual is only intended for use by properly trained and authorized service technicians. not properly quali ed. This Manual is not intended to be all-encompassing. You should read, in its necessary information needed to perform eld-service repairs. Read all Information and instructions for any test or procedure before attempting it.
-
Page 2: Table Of Contents
Each of the listings below is a hyperlink (when viewing electronically) to that page in this PDF manual. Click on a topic to go to that page. To return to this Table of Contents, simply click on the “b” in the Beko logo at the top of each page. -
Page 3: Serial Number & Qr Codes
FreeStanding Refrigerator Serial Number & QR Codes The serial tag is located on either the upper left-hand wall of the refrigerator section, or bottom of the compartment, beneath the large crisper drawer. Model Remove the right crisper drawer to see the serial tag. Serial Number SERVICE MANUAL... -
Page 4: Safety Information
If the refrigerator is malfunctioning, it must not be operated until it is repaired by an Authorized Servicer. There is a risk of electrical shock! The unit should be plugged into a three-prong, grounded and polarized 15A, 120V, 60Hz dedicated wall outlet. Beko US, Inc. will not be responsible for damages incurred while using the product in a way that does not comply with the electrical code of the location where the product is installed. -
Page 5: Installation, Electrical & Plumbing Requirements
FreeStanding Refrigerator Installation, Electrical & Plumbing Requirements The refrigerator must not be located too close to a heat source. Be sure it is installed at least 12” (30cm) from cooktops, ovens, radiators or stoves, and at least 2” (5cm) from electric ovens. Also, be sure the unit is not subject to direct sunlight or excessively humid locations. Do not install the refrigerator in place where the temperature falls below 50OF/10OC. -
Page 6: Theory Of Operation
Compressor & Evaporators The Beko refrigerator has two evaporators, but only one compressor, charged with R600a refrigerant. The Fresh Food and Freezer compartments are sealed from each other. As there is no transfer of air between the two compartments, the temperature management for each compartment is accomplished by the individual evaporators and sensors. -
Page 7: Refrigerator Components
FreeStanding Refrigerator Refrigerator Components Display Glass Shelver Door Shelf Half Double Everfresh Half Crisper Body Half Soft Freezer Partition Gallon-sizedd Soft Freezer Body Door Shelf Full Fresh Food Fan Fresh Food Exaporator (Not accessible) Air Sensor Fresh Food Cover LED Lighting Soft Freezer Senser Soft Freezer Rail SERVICE MANUAL... -
Page 8: Freezer Components
FreeStanding Refrigerator Freezer Components Freezer Top Drawer Ice Container Freezer Bottom Drawer LED Lighting Ice Maker Freezer Fan Freezer Top Drawer Rail Air Sensor Inner Liner Rail Freezer Cover Evaporator Sensor Thermal Fuse Air Sensor Defrost Element Evaporator SERVICE MANUAL... -
Page 9: Rear & Compressor Area Components
FreeStanding Refrigerator Rear & Compressor Area Components Fill Tube Heaters & Water Line Motor Valve Inverter Compresser Condenser Condenser Fan Water Vale SERVICE MANUAL... -
Page 10: Gas Flow Diagram & Parts
FreeStanding Refrigerator Gas Flow Diagram & Parts CONNECTIONS COMPONENTS 1. Compressor-Coil Condensor A - Compressor 2. Coil Condensor-Flange Heater B - Coil Condensor 3. Flanger Heater-Dryer C - Flange Heater 4. Dryer-Step Valve D - Dryer 5. Step Valve-FF Capillary Tube E - Step Valve 6. -
Page 11: Electrical Components & Speci Cations
FreeStanding Refrigerator Electrical Components & Specifications Quantity Component Stock Number Specifications Freezer Fan Motor 5815550100 12Vdc, 1.8W, CW -2300RPM ± 15% Condenser Fan Motor 5783015200 12Vdc, 1.8W ± 20%, CCW - 1600RPM ± 200 Fresh Food Fan Motor 5799900100 12Vdc, 0.78W, CW - 2100RPM ± 200 LED Board (6 LED) 4940162100* 12Vdc, 1.4W, 120mA... -
Page 12: Display & User Option Settings
FreeStanding Refrigerator Display & User Option Settings 1. Power Key - Press and hold this key for 3 seconds to turn the refrigerator on/o . 2. Wi-Fi Key - Press this key to turn the Wi-Fi on/o and Press and hold for 3 seconds to set up Wi-Fi. 3. -
Page 13: Service Mode
FreeStanding Refrigerator Service Mode (Service Mode should be done before any other diagnostic or disassembly procedures.) Fresh Food Freezer Quick Display Power Wi-Fi Temp Set Temp Set Freeze With the refrigerator and with the display on, press and hold the “Fresh Food Temp Set” & “Quick Freeze” keys for 3 seconds, until “P0”... -
Page 14: Error Code
FreeStanding Refrigerator Error Codes Error Codes Error Explanation Freezer Compartment Air Sensor Error Freezer Compartment Evaporator Sensor Error Fresh Food Compartment Evaporator Sensor Error (only On The Products Where The Related Error Is Shown On The Display) Fresh Food Compartment Air Sensor Error Freezer Defrost System Error Ambient Sensor/Humidity Sensor Error Icematic Air Sensor Error... -
Page 15: E0 - Freezer Compartment Air Sensor Error
FreeStanding Refrigerator E0 - Freezer Compartment Air Sensor Error >>2 Stop Is E0 ashing? Check cables connected to control board sensor socket (KN6) pins 5 & 6. Is the cable >>3 >> disconnected? >>4 Sloved Reconnect the cable and turn the refrigerator back on. Is error still there? Remove the harness from the KN6 socket on the control board. -
Page 16: E2 - Fresh Food Compartment Evaporatorsensor Error
(3 & 4). Is the resistance reading between 5k and 200k? (10k at 77°F (25°F)) Sloved Replace the Control Board. (Turn refrigerator back on) Contact Beko As the sensor is enclosed in polyure, it cannot be replaced 1-888-905-0799 E3 - Fresh Food Compartment Air Sensor Error >>2... -
Page 17: E4, E12 - Freezer Defrost System Error
FreeStanding Refrigerator E4 - Freezer Defrost System Error An E4 error does not necessarily mean you have a fault in the dafrost heating system. Follow these steps to determaine the true cause. >>2 Stop Is E4 ashing? >>4 >>3 Is there signi cant frost build-up (not ice, see question 3 for ice) in the freezer? >>10 >>15 Is there an ice build-up at the bottom of the freezer compartment... -
Page 18: E5: Ambient/ Humidity Sensor Error
FreeStanding Refrigerator E5: Ambient/ Humidity Sensor error >>2 Stop Is E5 ashing? Check cables connected to Sensor socket (KN7) pins 3 & 4. Is the cable disconnected? >>3 >>4 >>4 Sloved Reconnect the cable and turn the refrigerator back on. Is error still there? Remove the harness from the KN7 socket on the control board. -
Page 19: E13 - Freezer Compartment Fan Error
FreeStanding Refrigerator E13 - Freezer Compartment Fan Error >>2 Stop Is E13 ashing? Check cables connected to control board Lights & Fan socket (KN10) pins 6 & 14. Is the >>3 >>4 cable disconnected? >>4 Sloved Reconnect the cable and turn the refrigerator back on. Is error still there? Using a multimeter, measure the DC voltage pins 6 &... -
Page 20: Freezing In The Fresh Food Compartment
Food heater. Do you read 120Vac between pins 1 & 6? Sloved Fresh Food heater functioning properly. Contact Beko Fresh Food heater not accessible, not repairable. With the doors closed, check for continuity on the control board at socket KN6 between >>14... -
Page 21: Not Cooling In The Fresh Food Compartment
FreeStanding Refrigerator Not Cooling in the Fresh Food Compartment >>2 >>3 Are things freezing in the Fresh Food compartment? Sloved Follow the instructions for that error code for resolution. >>4 >>5 Is the refrigerator in Vacation Mode? Are there dashes in the temperature display? Sloved Take unit out of Vacation Mode. -
Page 22: High Temp Error
FreeStanding Refrigerator High Temp Error The High Temp Error icon is displayed when the Freezer temperature is too warm after the initial 72 hours of operation. If the Freezer temperature reaches 28°F (-2.2°C) or higher, and doesn’t drop below 16°F (-9°C) within 12 hours, the High Temp Error icon will be illuminated, an alarm will sound and the set temperature and highest temperature reached in the Freezer will alternate in the dis-play. -
Page 23: Wiring Diagram
FreeStanding Refrigerator Wiring Diagram SERVICE MANUAL... -
Page 24: Removing The Rear Wall
FreeStanding Refrigerator Removing the Rear Wall 1.Remove all the shelves. 2.Remove all the drawers. 3.Remove the crisper lids. SERVICE MANUAL... - Page 25 FreeStanding Refrigerator Removing the Rear Wall 4.Pull out on the bottom side of crisper rail. 5.Remove screw plug. 6.Remove screw. 7.Pull out on the middle of the 8.Unplug the connector right and left side. rear panel and unclip the bottom SERVICE MANUAL...
-
Page 26: Removing The Fresh Food Fan
FreeStanding Refrigerator Removing the Fresh food fan 1.After removing the rear panel, 2.pull out the fan from rear panel. unplug the connector VitaminZone 1.Unclip the lens from rear 2.Unclip the light board. 3. Unplug the connectors. panel to access the VitaminZone. VioLED 1.Unclip the VioLED board to 2.Unclip the lter to remove it. -
Page 27: Freezer Fan
FreeStanding Refrigerator Freezer Fan (Freezer Drawer must be removed rst) 1.Remove the single screw 2.Remove the evaporator cover 3.Unplug the fan connector. securing the freezer evaporator by pulling out on the bottom. cover. 4. After removing freezer evaporator cover, pull out the fan from cover. Defrost Element &... -
Page 28: Condenser Fan
FreeStanding Refrigerator 4. Remove the three retaining clips 5. Carefull peel the defrost element 6. Peel the defrost o the back and from the back of the evaporator. o of the front of the evaporator. remove, Replace in reverse order. A Drain Heater is located inside the rear wall and is therefore not accessible or replaceable. -
Page 29: Inverter Box
FreeStanding Refrigerator Inverter box 1. Remove 6 screw securing the 2. Using a pry tool, pull the steel 3.Remove the screw secuting the compressor cover. back wall from the cabinet. ground wire. 4. Remove the screw on the inverter 5. Remove inverter cover. 6.Remove the screw locking cable cover. -
Page 30: Ice Maker, Fill Tube Heater, Display
FreeStanding Refrigerator Ice Maker 1. After removing the drawer unit 2. Unplug the harness to the ice 3. Dismantling the ice maker by Remove the screw on the cover of maker to remove. Replace in pulling it towards yourself. the ice maker. reverse order. - Page 31 FreeStanding Refrigerator Reed Switches 1.Unclip the access panel at the 2. Unplug the harness to the Reed 3.Unscrew the Reed Switch to bottom of the Left Fresh Food Door. Switch. remove it from the bottom access panel. Bottom Access Panel with Reed Switch Handle 1.
-
Page 32: Reversible Door
FreeStanding Refrigerator Reversible Door Reversible Kit Bottom Hinge L Middle Hinge L Middle Hinge Pin Top Hinge L Top Hinge Cover L Upper Door Brow Cover L FF Door Closer L FRZ Door Closer L Reversible Door Stickker SERVICE MANUAL... - Page 33 FreeStanding Refrigerator Reversible Door Service Equipment Torx screwdriver Phillips screwdriver Flat screwdriver Cordless screwdriver Adjustable wrench Side cutting pliers Reversible Door 1. First, remove screw at top 2. Remove the top hing cover R. 3. Remove the ambient sensor from hinge cover R.
- Page 34 FreeStanding Refrigerator Reversible Door 7. Remove the screw at the top 8. Remove the top hinge R. 9. Remove the upper door brow hinge R. cover L. 10. Plug in the ambient sensor 11. Remove the cover upper socket 12. Assembly upper cover socket with door cable.
- Page 35 FreeStanding Refrigerator Reversible Door 19. Remove the freeze door. 20. Remove the screw and middle 21. Remove Flange hole plug middle hinge R on the right. on the left. 22. Assembly the Flange hole plug 23. Remove the middle hinge hole 24.
- Page 36 FreeStanding Refrigerator Reversible Door 31. Remove the screw at the 32. Assamble the bottom hinge L 33. Tilt the cabinet back to its bottom cabinet. with cabinet. original position or 90 degrees. 34. Remove the screw, hinge 35. Assambly the hinge stopper 36.
- Page 37 FreeStanding Refrigerator Reversible Door 43. Assamble the hinge stopper 44. Assemble the door closer L 45. Assamble the screw and freeze with the freeze door closer L. with the freeze door. door closer L. 46. Assemble the freeze door with 47.
-
Page 38: Reed Switch, Handle
FreeStanding Refrigerator Troubleshooting Symptom Possible Cause Corrective Action The Freezer compartment is The Freezer compartment temperature is set too Set Freezer temperature to a higher setting. too cold, but the refrigerator low. temperature is ne.remove, Replace in reverse order. The Fresh Food compartment The Fresh Food temperature is set too low. -
Page 39: Warranty
MAY BE BUYING THIS PRODUCT, EXCEPT AS OTHERWISE PROVIDED IN THIS WARRANTY STATEMENT. Beko will repair or replace at no cost to the consumer, any Beko does not assume any responsibility for incidental or loss of use of the appliance, or any associated equip- (Warranty is void if the product is used commercially, e.g.,...
