  • Page 1 ™ 16 Series ™ CobraNet Audio Bridge CAB 16i CAB 16o CAB 16d User Manual Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 2 ATTENTION: Afin de réduire le risque de choc électrique, ne pas enlever le couvercle. Il ne se trouve à l’intérieur aucune pièce pouvant être reparée par l’utilisateur. Confiez I’entretien et la réparation de l’appareil à un réparateur Peavey agréé. AVERTISSEMENT: Afin de prévenir les risques de décharge électrique ou de feu, n’exposez pas cet appareil à la pluie ou à...
  • Page 3 The information contained in this manual is subject to change without notice. Peavey Electronics is not liable for improper installation or configuration. The information contained herein is intended only as an aid to qualified personnel in the design, installation and maintenance of engineered audio systems.
  • Page 4 Setting The Hardware Base Address Setting The CobraNet Audio Bundle Testing, Testing..32-33 Testing, Testing..Digital Style! 34-35 Tech Support & Warranty Registration Additional Resources Specifications 38-39 Warranty Statement Page 4 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 5 CobraNet Input and Output Controls (Bundle Numbers in the OFF position) (Figure 18) CAB Device Audio Bundle Number controls shown in the OFF position. (Figure 19) Test Configuration (CAB 16i, CAB 16o) 32-33 Test Configuration (CAB 16d) 34-35 Peavey Electronics Corp. Page 5 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 6 The design, implementation and maintenance of this infrastructure is critical to the opera- tion and performance of the CAB 16 Series products. Peavey Electronics does not support nor service network cabling, hubs, switches, patch bays, wall plates, connector panels or any other type of network interconnect device. Please ensure that these components and their associated installation techniques have been properly designed and installed for CobraNet audio appli- cations.
  • Page 7 * Asterisk indicates that these items are shipped installed on the CAB 16 Series product. If any of these items are missing, please contact your Authorized Peavey Architectural Acoustics contractor/dealer. This User Manual covers the following CAB 16 Series products:...
  • Page 8 For in-depth information on MediaMatrix, refer to the online help. Additional resources are listed in this manual. Page 8 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 9 CobraNet audio systems. For the latest list of CobraNet compliant products, please refer to Peak Audio’s website at http://www.peak audio.com. Peavey Electronics Corp Page 9 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 10 Audio Path Control Panel CobraNet Output Output Side of Control Panel Audio Path Fig. 2, The CobraNet audio transport devices and their control panels. Page 10 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 11 CobraNet audio system using MediaMatrix products. If you understand it..kinda, but still need help, read on..you’ll see how it all fits together as you start hooking up CABs and passing audio from point to point. Peavey Electronics Corp Page 11...
  • Page 12 When the GAIN control is at 0 dB, the input sensi- tivity is determined solely by the Full Scale Sensitivity button. Page 12 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 13 When the GAIN control is at 0 dB, the input sensitivity is determined solely by the Full Scale Output button. Peavey Electronics Corp Page 13 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 14 The windows include separate functionality for input and output bundles. Page 14 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 15 Indicated” which means that the emphasis status is not specified. “None” means that there is no emphasis. “50/15” indicates that the signal contains 50/15 us and CCIT J.17 indicates that CCITT J.17 is used. Peavey Electronics Corp Page 15 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 16 ON during normal activity. (If this LED stays ON during idle, it may indicate an RS-485 conductor polarity inversion.) POWER LED Indicates that the CAB 16 is powered from an AC mains power source. Page 16 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 17 AUDIO INPUT CONNECTORS Balanced, three-wire line level audio input connections on removable Euro connectors. This illustration shows the connector header only. The unit is shipped with matching black pluggable connectors for each audio channel. Peavey Electronics Corp Page 17 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 18 ON during normal activity. (If this LED stays ON during idle, it may indicate an RS-485 conductor polarity inversion.) POWER LED Indicates that the CAB 16 is powered from an AC mains power source. Page 18 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 19 AUDIO OUTPUT CONNECTORS Balanced, three-wire line level audio output connections on removable Euro connectors. This illustration shows the connector header only. The unit is shipped with matching black pluggable connectors for each audio channel. Peavey Electronics Corp Page 19 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 20 ON during normal activity. (If this LED stays ON during idle, it may indicate an RS-485 conductor polarity inversion.) POWER LED Indicates that the CAB 16 is powered from an AC mains power source. Page 20 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 21 Euro connectors. Each digital channel carries two audio channels. This illustration shows the connector header only. The unit is shipped with matching black plug- gable connectors for each audio channel. Peavey Electronics Corp Page 21 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 22 DSP-cn card. This type of connection is normally used for testing and troubleshooting and has limited advantages in actual sys- tem installations. MediaMatrix Frame with MM-DSP-cn DPU Card “Crossover” CAT5 Cable (See p. 26-27) CAB 16o Fig. 5, Direct Connection Example Page 22 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 23 With this type of connection, there is no “input” or “output”. Balanced Connection Positive (+) Negative (-) Shield (SH) From RS-485 Device To Next RS-485 Device Fig. 7, RS-485 Serial Data Connections Peavey Electronics Corp Page 23 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 24 8-10 meter range with good 75 Ohm coaxial cable. We do not recom- mend that you exceed this distance when using S/PDIF devices with the CAB 16d. Page 24 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 25 CHANNEL STATUS to Consumer Mode before the interface between the S/PDIF device and CAB 16d is completed. The Consumer Mode Select Switch can be found in the CAB 16d CHANNEL STATUS BLOCK, located within the CAB 16d’s software control panel. (See pages 14-15.) Peavey Electronics Corp Page 25 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 26 16, only the ORANGE and GREEN pairs are actually used. BUT...it is very important that you build the cable with ALL PAIRS properly terminated. This will prevent any confustion later, and give your cable a solid mechanical connection. Page 26 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 27 Pin 8 Brown Pair Green Pair Green Pair Orange Pair Blue Pair Blue Pair Orange Pair Brown Pair Pin 1 Pin 8 Fig. 12, CAT 5 “crossover” cable Peavey Electronics Corp Page 27 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 28 Network Connection Audio Input CAB 16i Primary CAB 16i Secondary or “Backup” Fig. 13, CAB 16i Link Connection Example Page 28 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 29 “dual” CAB units. Where addition- al CABs are used, additional redun- dant units must also be added. Redundant Audio Outputs Fig. 15, CAB 16d Link Connection Example Peavey Electronics Corp Page 29 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 30 LED’s will indicate traffic. You can further test the connection by test- ing the functions of the CAB and verifying the response. Fig. 17, Hardware & Software Addressing Controls Page 30 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 31 (Multicast) networks with MediaMatrix systems. For more information on using a Multicast network with CobraNet, please refer to page 37, Additional Information, and see the article on “Bundle Assignments in CobraNet Systems”. Peavey Electronics Corp Page 31 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 32 ™ input block 100 BaseT Ethernet Switch “The Processing, a MediaMatrix System” MediaMatrix CobraNet MainFrame (shown Network with 1-MM-DSP-cn Connector and 1-MM-DSP (MM-DSP-cn) cards) Page 32 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 33 I/O so we have some control and panning of the stereo signal. Of course, additional processing could easily be added from the MediaMatrix Device menu. “The Output Side” “The Input Side” “The Processing” Peavey Electronics Corp Page 33 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 34 100 Base T Ethernet Switch “The Processing, a MediaMatrix System” MediaMatrix CobraNet Network MainFrame (shown with 1-MM-DSP-cn Connector and 1-MM-DSP (MM-DSP-cn) cards) Page 34 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 35 Input ™ Audio Bundle set to “286” at the Taxi AND the CobraNet ™ input block CAT5 Cable (typ.) “The Output Side” “The Input Side” “The Processing” Peavey Electronics Corp Page 35 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 36 Interactive”, published monthly. Also on our website are message board forums that include questions and answers on all audio topics. This forum is a great way to learn more about audio, Peavey products and system design from other audio professionals around the world. You can also get help by sending us an e-mail or posting a request on the message board.
  • Page 37 There are several excellent sources for obtaining information regarding these topics. The resource list below represents the most current documentation on the state-of-the-art as of the date of this printing (Fall 2000). The links are a part of the Peavey Architectural Acoustics or Peak Audio websites.
  • Page 38 A/D. Top-most output of D/A (CAB 16o). Top-most LED indicates level 1 dB below clipping LED indicates level 1 dB below clipping Page 38 http://aa.peavey.com copyright 2000 All Rights Reserved Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 39 5. All Cab16i measurements are made using a 40 Ohm source imped- transmitted to the CAB 16o through an Ethernet switch. ance at 24 dBu sensitivity unless otherwise stated. Peavey Electronics Corp Page 39 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 40 What Peavey Will Do We will repair or replace (at Peavey's discretion) products covered by warranty at no charge for labor or materials. If the product or component must be shipped to Peavey for warranty service, the consumer must pay initial shipping charges. If the repairs are covered by warranty, Peavey will pay the return shipping charges.
  • Page 41 Features and Specifications subject to change without notice. A product of Peavey Electronics Corporation 711 A Street / Meridian, MS 39301 / USA / (601) 483-5376 / FAX (601) 486-1678 http://aa.peavey.com Copyright 2000 All Rights Reserved Printed in USA 4/2000...
