INSTALLATION MANUAL
PROFESSIONAL SECURITY MODULE
SMS with 4 Zone Security Module Port
MODEL: TIS-SEC-PRO
Input
Output
Function programmable
options
Security
Dimensions
Housing
BARCODE (UPC-A)
The Security Professional Module enhances
security systems with SMS communication,
offering 4 sensor zones, 1 relay output, and battery
backup for reliable operation. Ideal for remote
monitoring and control, it's perfect for customized
security solutions.
P R O D U C T S P E C I F I C AT I O N S
Dry Inputs
Battery Power
SIM Slot
Relay
SMS
Wired Zone
1 Relay
PRG button
Levels
Arming commands
Alarm Commands
Width × length × height
Materials
Casing color
IP rating
PRODUCT INFORMATION
4X Dry Inputs
Buckup 12V Battery Input
SIM CARD
1x Relay Output 1A
Sending 16 SMS to 8 numbers
Receiving 16 SMS from 8 numbers
4 Hardwired Zone
To Link to Siren or other output
To Broadcast Address
Vacation, Away, Night, Day, Disarm
20 for each level
20 for each level
73mm x 76mm x 90mm
ABS anti fire
Black Gray
IP 20
Advertisement
Table of Contents
Summary of Contents for TIS TIS-SEC-PRO
- Page 1 INSTALLATION MANUAL PROFESSIONAL SECURITY MODULE SMS with 4 Zone Security Module Port MODEL: TIS-SEC-PRO PRODUCT INFORMATION The Security Professional Module enhances security systems with SMS communication, offering 4 sensor zones, 1 relay output, and battery backup for reliable operation. Ideal for remote monitoring and control, it’s perfect for customized...
-
Page 2: Safety Instructions
SA, AUSTRALIA Wanchai, Hong Kong TIS Logo is registered trademark of TIS CONTROL. All of the specification are subject to change without notice. w w w . t i s c o n t r o l . c o m... -
Page 3: Installation Steps
DIN rail by two mounting screw holes Connect a Cat5e TIS network data cable to the TIS-BUS port as per the connection diagram. No need to loop the TIS-bus cable if 2 DIN rail modules are connected... - Page 4 SA, AUSTRALIA Wanchai, Hong Kong TIS Logo is registered trademark of TIS CONTROL. All of the specification are subject to change without notice. w w w . t i s c o n t r o l . c o m...
-
Page 5: Troubleshooting
MODEL: TIS-SEC-PRO TROUBLESHOOTING Reason: The module’s address conflicts with another device in the TIS network. You need to PRG Button Blinks Red Color Rapidly press and hold the PRG button for 6 seconds so that the module can get a new address.
