MYFIT ZIP AIR
RECALL REMEDY INSTRUCTIONS
Keep these instructions for future use; store with the new user guide.
This Remedy Kit is to be used when installing the MyFit Zip Air in
the following configuration:
Harness Mode: When installed with a vehicle Lap-Belt ONLY
and no Tether Anchor for children weighing between
25 and 40 lbs: Use Recline Positions 1 & 2 ONLY.
DO NOT use Recline Positions 3 & 4.
DO NOT use Forward Crotch Buckle Position
WARNINGS
READ ALL INSTRUCTIONS BEFORE USE - Failure to follow these
warnings and instructions could result in injury or death to your child.
•ONLY install this car seat in recline positions 1 & 2 when using the
vehicle lap belt and no top tether for children weighing between
25-40 lbs.
•ALWAYS make sure the LATCH connectors are securely attached to
the D-rings when not in use.
•Check to make sure the LATCH straps lay flat and are snug against
the sides of the child restraint when stored.
THIS REMEDY KIT INCLUDES:
D-ring Strap
x2
Replacement
User Guide
IS0238E_01
ChiccoUSA.com
If you have any questions
regarding this remedy kit or
installation instructions please
contact Chicco Customer
Service at 1-877-424-4226.
Important: Discard
the original user
guide (IS0176E_02)
x1
and replace with the
included user guide.
STEP 1
1a. Unbuckle the Chest Clip and lift the Zip-On Head Rest Pad up.
Then unzip the side of the Seat Pad. Un-hook the elastic strap from
the top hook.
1b. Lift up on the seat back pad and fold the back padding out of the
way. Pull forward on the bottom seat pad and storage cover, to locate
the LATCH storage compartment. Remove both of the LATCH Straps.
1c. Thread the LATCH Connectors behind the seat fabric and out
the side openings on the seat back, as shown.
1d. Repeat step 1a in REVERSE to close the LATCH Connector
Storage and replace all the seat pads.
Important: Make sure
the LATCH straps lay flat
against the seat back.
Important: The SuperCinch® LATCH
Tightener strap (Pull 2nd) and LATCH
Adjuster strap (Pull 1st) should be
extended to their full length.
Advertisement
Related Manuals for Chicco MyFit Zip Air
Summary of Contents for Chicco MyFit Zip Air
- Page 1 1a. Unbuckle the Chest Clip and lift the Zip-On Head Rest Pad up. This Remedy Kit is to be used when installing the MyFit Zip Air in Then unzip the side of the Seat Pad. Un-hook the elastic strap from the following configuration: the top hook.
- Page 2 STEP 2 STEP 3 Important: Make sure the red button on the LATCH button is facing out and there are no twists in the straps. CLICK! 2a. Press the button on the bottom of the Cup Holder and lift up to remove.
