IMPORTANT INSTRUCTIONS
AND OPERATING MANUAL
ELECTRIC HEATER
M1804
M225
ZBI-15SRLT/M18/M21
NO VENTING REQUIRED
Read and understand this entire owner's manual, including all safety
information before plugging in or using this appliance. Failure to do so
WARNING
could result in fire, electric shock, or serious personal injury.
Address: ROWAN ELECTRIC APPLIANCE LLC 28407 Ascent Way, Santa Clarita, CA 91350
Phone: 213-4467172 or 661-4358826
CERTIFIED UNDER CANDIAN AND AMERICAN NATIONAL STANDARDS:ETL
Advertisement
Summary of Contents for Zafro M1804
- Page 1 IMPORTANT INSTRUCTIONS AND OPERATING MANUAL ELECTRIC HEATER M1804 M225 ZBI-15SRLT/M18/M21 NO VENTING REQUIRED Read and understand this entire owner’s manual, including all safety information before plugging in or using this appliance. Failure to do so WARNING could result in fire, electric shock, or serious personal injury.
- Page 3 TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS..........................2 1.0 PACKING LIST................................4 1.1 DIMENSIONS................................ 5 2.0 ELECTRICAL INSTALLATION NOTES..........................6 2.1 GENERAL INSTRUCTIONS............................. 6 3.0 INSTALLATION INSTRUCTIONS........................... 7 3.1 UNPACKING AND TESTING APPLIANCE WALL......................7 3.2 GROUNDING APPLIANCE............................. 7 3.3 ASSEMBLY................................8 4.0 OPERATING INSTRUCTIONS............................
- Page 4 IMPORTANT SAFETY INSTRUCTION WARNING These instructions should be carefully read before installation and retained by the user. The booklet must be kept and delivered to the new user in case of disposal of the heater. The Manufacturer reserves the right to vary the features of the product without prior notice.
- Page 5 18. Always unplug appliance when not in use. 19. Do not operate this appliance with a damaged cord or plug after the appliance malfunctions, or has been dropped or damaged in any manner. Return appliance to authorized service facility for examination, electrical or mechanical adjustment, or repair.
- Page 6 1.0 PACKING LIST Description Quantity 1 pc Electric Fireplace 1 pc Installation and Operating Instructions 1 pc Remote Control (Battery included) ① ② ③...
- Page 7 1.1 DIMENSIONS M1804 M225...
- Page 8 LISTTING APPROVALS ZBI-15SRLT/M18/M21 Model Number Free standing This appliance has been tested in accordance with the ETL Description Standards for fixed and location-dedicated electric room appliance appliances in the United States and Canada. If you need assistance 120VAC Voltage during installation, please contact your local dealer.
- Page 9 Follow all National and local electrical codes. 1. The heater must not be recessed in the ceiling. There must be enough space around the top of the heater to ensure adequate ventilation. 2. The heater should be at least 60 cm away from any surrounding walls. 3.
- Page 10 3.3 ASSEMBLY ALWAYS unplug this fireplace heater before assembly or cleaning, or before relocating. Failure to do so could result in electric shock, fire, or personal injury. KEEP drapery and other furnishings at least 3ft /0.9m from the front and sides of the electric fireplace.
- Page 11 4.0 OPERATING INSTRUCTIONS Once the appliance has been plugged into a grounded electrical outlet, it is ready to operate. 4.1 MAIN POWER BUTTON The Main Power Button is located on the upper right of the fireplace as illustrated. Press indicator to turn on the appliance, press the other side to turn it off.
- Page 12 Turn the appliance ON/OFF. POWER NOTE: Make sure the main power switch on the top of fireplace is turned on before operating. Control Flame brightness. Flame Increase (+) 7 Settings: Press the flame brightness increase “+” Button or the flame Flame Decrease (-) brightness decrease “-”...
- Page 13 4.3 REMOVE CONTROL ◆Move the battery’s transparent insulating piece away before using. The battery must be recycled or disposed of properly. Check with your Local Authority or Retailer for recycling advice in your area. 5.0 TROUBLESHOOTING GUIDE SOLUTION PROBLEM 1. Main Power supply switch is Turn the main power supply switch to “ON”...
- Page 14 Contact us via Amazon Message or call customer 1. Flame element is not attached to the motor. serve Phone: 213-4467172or 661-4358826 . Flame are frozen Contact us via Amazon Message or call customer 2. Rotation motor is defective. serve Phone: 213-4467172 or 661-4358826. Contact us via Amazon Message or call customer 1.
- Page 15 Make sure the battery is properly installed. Move 1. The battery is not properly the battery’s transparent insulating piece away installed. before using. Aim the remote control at the receiver (middle of 2. Not pointing to the right the fireplace). position.
- Page 16 To remove finger prints or other marks, the partially reflective glass can be cleaned with a damp cloth. The partially reflective glass should be completely dried with a lint-free cloth to prevent water spots. To prevent scratching, do not use abrasive cleaners. 6.2 SCHEMATIC DIAGRAM 7.0 LIMITED WARRANTY This warrants to the original purchaser that this product is free from defects in material and workmanship as of...
- Page 17 caused from this insert being used for excessive periods of time; Damage caused by the insert being used in a commercial application; Damage from use as a primary heat source; Other misuse or abuse not specifically listed herein. This product is not intended to be used as a primary heat source. It is for supplemental heating purposes only.
- Page 18 Thank you for purchasing this product! If you have any questions about the product, such as missing parts, damaged products, product assembling, and operation, please contact us via Amazon Message or customer service number: 213-4467172 or 661-4358826 IMPORTANT Please call our customer service department for any consulting: 213-4467172 661-4358826...
