- Page 1 Dishwasher SMS4HVI01A [aus] Information for Use...
- Page 2 aus Table of contents Table of contents Table of contents 1 Safety .......... 3 8.7 Baking sheet spray head .. 2 1 1.1 General information .... 3 8.8 Basket heights ...... 2 2 1.2 Intended use...
- Page 3 Safety aus 1 15.4 Smart Start ...... 3 3 18.1 Removing the appliance .. 5 0 15.5 Remote Diagnostics .... 3 3 18.2 Protect appliance from frost ........... 5 0 15.6 Software update...
- Page 4 aus Safety 1.3 Restriction on user group This appliance may be used by children aged 8 or over and by people who have reduced physical, sensory or mental abilities or inadequate experience and/or knowledge, provided that they are supervised or have been instructed on how to use the appliance safely and have understood the resulting dangers.
- Page 5 Safety aus Cutting through the supply hose or immersing the Aqua-Stop valve in water is dangerous. Never immerse the plastic housing in water. The plastic housing on the supply hose contains an electric valve. Never cut through the supply hose. The supply hose contains electric power cables.
- Page 6 aus Safety Highly caustic alkaline or highly acidic cleaning agents in conjunc- tion with aluminium parts in the interior of the appliance may cause explosions. Never use highly caustic alkaline or highly acidic cleaning agents, in particular commercial or industrial products, in con- junction with aluminium parts (e.g.
- Page 7 Safety aus Never kink, crush or modify the power cord. 1.6 Damaged appliance WARNING ‒ Risk of electric shock! If the appliance or the power cord is damaged, this is dangerous. Never operate a damaged appliance. Never operate an appliance with a cracked or fractured surface. Never pull on the power cord to unplug the appliance.
- Page 8 aus Preventing material damage WARNING ‒ Risk of harm to health! Children can lock themselves in the appliance, thereby putting their lives at risk. With redundant appliances, unplug the power cord. Then cut through the cord and damage the lock on the appliance door beyond repair so that the appliance door will no longer close.
- Page 9 Environmental protection and saving energy aus Do not install the dishwasher un- 2.2 Safe use der a hob. ATTENTION Do not install the dishwasher near Escaping water vapour can damage heat sources, e.g. radiators, heat fitted units. storage tanks, ovens or other ap- When the programme ends, leave pliances that generate heat.
- Page 10 aus Installation and connection 3.3 Aqua sensor Further information documents Installation material The aqua sensor is an optical meas- Mains cable uring device (light barrier) which measures the turbidity of the washing 4.2 Installing and connecting water. You can save water with the the appliance aqua sensor.
- Page 11 Installation and connection aus Also check that there is no cover 4.5 Electrical connection in the drainage system preventing Connect your appliance to the power the wastewater from being dis- supply. charged. Connecting the appliance to the 4.4 Drinking water connection electricity supply Connect your appliance to a drinking Notes water connection.
- Page 12 aus Familiarising yourself with your appliance 5 Familiarising yourself with your appliance Familiarising yourself with your appliance 5.1 Appliance You can find an overview of the parts of your appliance here. Rating plate with E number and FD number Page 51 . Rating plate The data you need for Customer Service Page 51 .
- Page 13 Familiarising yourself with your appliance aus The lower spray arm washes the tableware in the bottom basket. Lower spray arm If the tableware has not been washed prop- erly, clean the spray arms. "Cleaning spray arms", Page 37 During the wash cycle tablets automatically fall out of the detergent dispenser into the Tablet collecting tray tablet collecting tray where they can fully...
- Page 14 aus Familiarising yourself with your appliance With some buttons you can perform different functions. 3 4 5 Page 28 Switching on the appliance Page 30 ON/OFF button and reset Switching off the appliance button Terminating the programme Page 30 Programme buttons Programmes Rinse aid system Rinse aid refill indicator...
- Page 15 Programmes aus The display shows information about the remaining running time or the basic settings. You can change the basic set- Display tings via the display and the setting buttons. "Changing basic settings", Page 32 1 Door handle Open the appliance door. 1 Symbols on the display Symbol...
- Page 16 aus Programmes Programme Consumption val- Programme se- quence 1) Duration in hrs:mins 2) Energy con- sumption in kWh 3) Water con- sumption in litres 1) 2:05 - 2:15 Tableware: Intensive: 2) 1.350 - Pots and pans, Pre-Rinse Pots / Pans 1.400 non-fragile Cleaning 70 °C 3) 10.5 - 13.5 tableware and...
- Page 17 Programmes aus Programme Consumption val- Programme se- quence 1) Duration in hrs:mins 2) Energy con- sumption in kWh 3) Water con- sumption in litres Level of soiling: Lightly adhering fresh food rem- nants 1) 1:00 Tableware: Time-optimised: 2) 1.200 Mixed table- Cleaning 65 °C Quick 1h 3) 10.0...
- Page 18 aus Additional functions When programmes have been down- Press the button for the relevant loaded and on delivery of the appli- additional function. ance, the name of the programme Press for 3 seconds. will be displayed in the app. The dis- The selected programme and the play alternately shows "APP"...
- Page 19 Features aus Symbol Additional func- tion 1 SpeedPerfect The run time is shortened by 15% to 75% depending on the rinse programme. The additional function can be activated be- fore the start of the programme and at any time when the programme is running. Energy and water consumption are in- creased.
- Page 20 aus Features 8.2 Etagere Use the cutlery shelf and space un- derneath for small cups and glasses or for large items of cutlery, e.g. cooking spoons or serving cutlery. Large plates up to a diameter of 31 cm can be arranged in the bottom basket as shown.
- Page 21 Features aus 1 Folding down prongs 8.6 Cutlery drawer If you do not need the prongs, fold Arrange cutlery in the cutlery drawer. them down. Push the lever forwards and fold down the prongs Arrange cutlery with the points and sharp edges downwards. To use the prongs again, fold them 8.7 Baking sheet spray head back up.
- Page 22 aus Before using for the first time Remove top basket. Removing baking sheet spray Insert the baking sheet spray head head in the holder and turn to the If you no longer require the baking right sheet spray head, remove it from the appliance.
- Page 23 Rinse aid system aus Set the amount of rinse aid to be Add rinse aid up to the max mark. Page 23 dispensed. Add detergent. Start the Programme with the highest cleaning temperature Page 15 without tableware. To remove any marks from water or other residues, we recommend you operate the appliance without tableware before using it for the...
- Page 24 aus Detergent 10.3 Switching the rinse aid enzymes. Enzymes break down starch and remove protein. Oxygen- system off based bleaching agents are generally If you find the rinse aid refill indicator used to remove coloured stains, e.g. irritating, e.g. when using combined tea or ketchup.
- Page 25 Detergent aus placement substances (3in1) and, Detergent Description depending on the combination (4in1, Sometimes liquid 5in1,...), additional components such detergent may as glass protection or stainless steel leak out despite cleaner. the detergent dis- Note: Follow the manufacturer's in- penser being structions for each detergent.
- Page 26 aus Tableware with dry hands and only ever place less than the amount of detergent them in a dry detergent dispenser. specified is usually sufficient. Even if the rinse aid refill indicator Close the lid of the detergent dis- lights up, washing programmes will penser.
- Page 27 Tableware aus Cause Recommendation The following tableware is not dish- Only put tableware in the dishwasher if washer-safe: it is marked as dishwasher-safe by the Items of cutlery and tableware manufacturer. made from wood Decorated glassware, antique and hand-crafted tableware Plastic parts not resistant to heat Tableware made from copper or tin Tableware soiled with ash, wax, lub- ricating grease or paint...
- Page 28 aus Basic operation To save energy and water, load to obstruct the lid of the deter- the machine with the number of gent dispenser. place settings specified (standard load with tableware and cutlery). For better washing and drying res- ults, position items with curves or recesses at an angle so water can run off.
- Page 29 Basic operation aus 13.2 Setting a programme 13.5 Starting the programme To adjust the washing programme to Press the soiling level of the tableware, se- The programme has ended when lect a suitable programme. the display shows "0h:00m". Requirement: The appliance door is Notes closed.
- Page 30 aus Basic settings 13.8 Interrupting programme Press for approx. 4 seconds. Note: When you open the appliance The programme is terminated and door once the appliance has heated the appliance is reset. All LEDs up, leave the door slightly ajar for a light up for approx. 1 minute. few minutes and then close it.
- Page 31 Basic settings aus Basic setting Display text Selection Description Note: Not suitable for delicate items of tableware. Switch Extra Dry on "d01" or off "d00". 1 Hot water A00 - A01 Set cold water or hot water connection. Only set the ap- pliance to hot water if this can be prepared with little en- ergy and a suitable installa-...
- Page 32 aus Home Connect Basic setting Display text Selection Description This basic setting is not avail- able until you have connected the appliance with the Home Connect app. "Home Connect ", Page 32 Factory setting Start with Restore changed settings to the factory settings. Confirm with The settings for initial start-up must be configured.
- Page 33 Home Connect aus 1 15.2 Home Connect settings 15.4 Smart Start Adapt Home Connect to your needs. Smart Start automatically determines You can find the Home Connect set- the optimal time for the programme tings in the basic settings for your ap- to start. pliance. Which settings the display You can use the Home Connect app shows will depend on whether to activate or deactivate the function.
- Page 34 aus Cleaning and servicing for optimisation, troubleshooting or 16.1 Cleaning the tub safety-relevant updating. WARNING The Home Connect app informs you Risk of harm to health! about available software updates. Using detergents containing chlorine may result in harm to health. 15.7 Data protection Never use detergents containing Please see the information on data chlorine.
- Page 35 Tip: You can get our tested and approved Dishwasher Care and Machine Cleaner for Dishwashers online at https://www.bosch-home.com/store or from customer service. Machine Care is a programme which removes various deposits in one washing cycle.
- Page 36 aus Cleaning and servicing Pour the machine cleaner into the Turn the coarse filter anticlockwise detergent dispenser until it is filled and remove the filter system completely. Check that no foreign objects Do not place any additional ma- fall into the sump. chine cleaner in the appliance in- terior.
- Page 37 Troubleshooting aus Re-assemble the filter system. Unscrew the upper spray arm Make sure that the locking catches and pull down to remove on the coarse filter click into posi- tion. Insert the filter system into the ap- pliance and turn the coarse filter clockwise.
- Page 38 aus Troubleshooting If the power cord or the appliance power cable of this appliance is damaged, it must be replaced with a special power cord or special appliance power cable, which is available from the manufacturer or its Customer Service. Fault Cause and troubleshooting Display "Check water A technical fault is present.
- Page 39 Troubleshooting aus Fault Cause and troubleshooting E:32-00 will light up The filters in the water connection of the supply or alternately or indicator AquaStop hose are blocked. for water supply lights Switch off the appliance. Pull out the mains plug. Turn off the water tap. Unscrew the water connection.
- Page 40 aus Troubleshooting Fault Cause and troubleshooting E:61-03 will light up alternately. Water is not drained. Not an appliance fault. Wastewater pump is blocked or the cover of the wastewater pump is loose. Clean the wastewater pump. "Clean wastewater pump", Page 49 Secure the cover of the wastewater pump so it clicks into position.
- Page 41 Troubleshooting aus Fault Cause and troubleshooting Tableware is not dry. No rinse aid used or dosage set too low. Page 23 . Add Rinse aid Set the amount of rinse aid to be dispensed. "Setting the amount of rinse aid", Page 23 Programme or programme option has no drying phase, or the drying phase is too brief.
- Page 42 aus Troubleshooting Fault Cause and troubleshooting Cutlery is not dry. Arrange cutlery individually where possible. Page 27 Avoid points of contact. Appliance interior still Not a fault. The condensation drying principle causes wet after wash cycle. water droplets in the tub – they are indeed desirable here.
- Page 43 Troubleshooting aus Fault Cause and troubleshooting Remnants of food on Tall narrow receptacles in corner areas are not rinsed tableware. adequately. Do not position tall narrow receptacles at too great an angle or in corner areas. Top baskets on right and left are not set to same height.
- Page 44 aus Troubleshooting Fault Cause and troubleshooting Stubborn white coat- Detergent substances are deposited there. These coat- ings are present on ings cannot generally be removed with chemicals. tableware, inside the Change your detergent. appliance or the door. Clean the appliance mechanically. Too little detergent is being used.
- Page 45 Troubleshooting aus Fault Cause and troubleshooting Plastic parts are dis- Tableware has been precleaned too intensely. The coloured. sensors chose a weaker programme. Stubborn soiling cannot be entirely removed. Only remove large remnants of food and do not prerinse tableware. Removable streaks Amount of rinse aid to be dispensed is set too high.
- Page 46 aus Troubleshooting Fault Cause and troubleshooting Detergent residue is Spray arms were blocked by tableware so detergent present in the deter- was not rinsed out. gent dispenser or the Check that the spray arms are not blocked and can tablet collecting tray. rotate freely.
- Page 47 Troubleshooting aus Fault Cause and troubleshooting All LEDs lit up or A software update is possibly installing. flashing. Wait until the software update has been installed. This process can take approx. 30 minutes. If the appliance is not ready to use after 30 minutes, perform a reset.
- Page 48 aus Troubleshooting Fault Cause and troubleshooting Appliance does not Appliance door is not closed properly. start. Close the appliance door. Programme starts You did not wait until programme ended. "Terminate programme", Page 30 automatically. Appliance stops dur- Appliance door is not closed properly. ing the programme or Close the appliance door.
- Page 49 Troubleshooting aus Fault Cause and troubleshooting Knocking or rattling Spray arm is striking tableware. noise. Arrange tableware so that the spray arms do not strike tableware. With a small load the water jets directly strike against the tub. Distribute the tableware evenly. Load the appliance with more tableware.
- Page 50 aus Transportation, storage and disposal Insert the pump cover and press 18.3 Transporting the appli- down ance To avoid damage to the appliance, empty it before transporting. Note: Always transport the appliance upright to prevent residual water get- ting into the machine's controls and damaging the appliance.
- Page 51 Customer Service aus Unplug the appliance from the Make a note of your appliance's de- mains. tails and the Customer Service tele- Cut through the power cord. phone number to find them again Dispose of the appliance in an en- quickly. vironmentally friendly manner.
- Page 52 BSH Hausgeräte GmbH hereby declares that the appliance with Home Connect functionality conforms to the essential requirements and other relevant provi- sions of Directive 2014/53/EU. A detailed RED Declaration of Conformity can be found online at www.bosch- home.com among the additional documents on the product page for your ap- pliance.
- Page 53 Declaration of Conformity aus 5-GHz band (5150–5350 MHz + 5470–5725 MHz): max. 180 mW UK (NI) 5 GHz WLAN (Wi-Fi): For indoor use only. 5 GHz WLAN (Wi-Fi): For indoor use only.
- Page 56 You'll find it here. Expert advice for your Bosch home appliances, help with problems or a repair from Bosch experts. Find out everything about the many ways Bosch can support you: www.bosch-home.com/service Contact data of all countries are listed in the attached service directory.
