Page 1: Setup, Use, And Care Guide
PLA-80 PERIPROBE ADAPTER PLA2-80 PRO2BE ADAPTER PZA-80 PROBE ZOOM ADAPTER Setup, Use, and Care Guide... - Page 2 About Probe Lens Adapter (PLA) Page 2 Copyright 2025, Gates Underwater Products, Inc. This manual and current revision is available in 8.5 x 11 size and full color at http://www.gateshousings.com Gates Underwater Products, Inc. 13685 Stowe Drive Suite A Poway, California 92064 USA Phone: +1-858.391.0052...
-
Page 3: Table Of Contents
About Probe Lens Adapter (PLA) Page 3 Table of Contents Setup, Use, and Care Guide ..........1 About Probe Lens Adapter (PLA) ........4 Warranty Disclaimer ............4 Unpacking the PLA ............5 Cautions ................7 PLA Assembly ..............8 Step 1: Mount the Lens ............. -
Page 4: About Probe Lens Adapter (Pla)
We warrant the PLA as an image acquisition tool for a period of 2 years. The Laowa Probe lenses are warranted by the original manufacturer, Venus Optics. Refer to their website for warranty details. If you have any questions about the setup, use and care of the PLA, contact Gates directly. -
Page 5: Unpacking The Pla
After you remove the PLA from its shipping container, carefully inspect it for missing parts or damage that may have occurred during shipment. If any discrepancies are discovered, please contact your Gates dealer immediately for assistance. Standard Configuration The PLA comes with the following standard items: •... - Page 6 3/32” Ball Driver Tool (for Lens Gear Drive) o Tube of silicone lubricant Housing specific configurations: Additional required items vary based upon Probe Lens, Gates housing model, and configuration. For example, Stackable Port Rings will be required to position the Adapter Cone in the optimal position for each type of Probe Lens.
-
Page 7: Cautions
Failure to do so can result in poor or non-operation of the PLA and may void your warranty. Contact Gates if you have questions about this manual or using the PLA. DEPTH RATING. -
Page 8: Pla Assembly
PLA Assembly Page 8 3: PLA Assembly The following instructions use the Gates DEEP WEAPON-RAPTOR and PRO RAPTOR housings as a model. The mounting process is the nearly identical for other PLAs and Gates Housings. Step 1: Mount the Lens Attach the lens to the camera. -
Page 9: Step 2: Install Flex Gears
PLA Assembly Page 9 Step 2: Install Flex Gears Position the Flex Gears on the focus and iris rings of the Laowa lens. Tighten screws with the 7/64” ball driver tool, and only enough to be secure. Do not overtighten. Position flex gears Do not overtighten... -
Page 10: Step 3: Install Lens Gear Drives
PLA Assembly Page 10 Step 3: Install Lens Gear Drives Install Lens Gear Drives per instructions in the housing’s SU&C Guide. Verify smooth operation. Position and install lens gear drives... -
Page 11: Step 4: Adapter Cone Positioning
Adapter Cone, and assure a seal by avoiding compromising features (such as engraving on the Probe Lens barrel). Here are examples of each type of Probe Lens Adapter, and the optimal position for each. PLA-80 Probe Lens Adapter Cone position Position PLA-80 Adapter Cone seal in this region... - Page 12 PLA Assembly Page 12 PLA2-80 Probe Lens Adapter Cone position CAUTION: Do not place Adapter Cone seal over barrel engraving. Position PLA2-80 Adapter Cone seal in this region. PZA-80 Probe Lens Adapter Cone position Probe Zoom 0° Direct Barrel CAUTION: Do not place Adapter Cone seal over barrel engraving.
- Page 13 PLA Assembly Page 13 PZA-80 Probe Lens Adapter Cone position Probe Zoom 35° and 90° Barrel CAUTION: Do not place Adapter Cone seal over barrel engraving. Position PZA-80 Adapter Cone seal in this region...
-
Page 14: Step 4: Install Port Rings
Rotate and Lock the port rings into position. More detailed instructions can be found in the SU&C guide for your housing. The required port ring stack varies based on the Probe Lens type and Gates housing model. Refer to previous section for guidance. -
Page 15: Step 5: Position The Internal Lock Collar
PLA Assembly Page 15 Step 5: Position the Internal Lock Collar Use silicone lubricant to lightly grease the surface of the o-ring on the lock collar. Position the collar with the o-ring facing out and then slide it as far back as possible onto the lens, taking care not to scratch the optical surface. -
Page 16: Step 6: Prepare Half Rings And Pla Adapter Cone
PLA Assembly Page 16 Step 6: Prepare Half Rings and PLA Adapter Cone Locate 2 half ring sections and place them in an easily accessible place near the front of the housing. Lubricate the o-ring on the PLA port adapter cone. Position the adapter cone over and past the lens’... -
Page 17: Step 7: Install Internal Half Rings
PLA Assembly Page 17 Step 7: Install Internal Half Rings Continue supporting the weight of the adapter cone with one hand. Place both half ring sections over the lens tube and then slide them into the recessed step inside the adapter cone. Fully seat half rings inside step Continue supporting... -
Page 18: Step 8: Secure Internal Lock Collar
PLA Assembly Page 18 Step 8: Secure Internal Lock Collar Continue supporting the weight of the adapter cone with one hand. Align the marker dot on the lock collar with the start position markings on the inside of the probe cone. Firmly press lock collar in to compress o-ring and then rotate it until the marker dot is aligned with the locked position. -
Page 19: Step 9: Secure The Adapter Cone
PLA Assembly Page 19 Step 9: Secure the Adapter Cone Rotate and lock the adapter cone onto the port ring stack, in the same manner as a stackable port ring. Rotate and lock adapter cone... -
Page 20: Step 10: Install Bore Seal O-Ring
PLA Assembly Page 20 Step 10: Install Bore Seal O-ring Lubricate the yellow o-ring (1) and gently stretch it over the end of the lens. The lens cover must be removed for this step. A small plastic bag may be used as a cover to prevent grease from being deposited on the glass lens face. -
Page 21: Step 11: Seat Half Rings
PLA Assembly Page 21 Step 11: Seat Half Rings Fully seat the half rings inside the recessed step. Fully seat half rings into the step... -
Page 22: Step 12: Secure External Lock Collar And Complete
Continue housing setup per the Housing SU&C Guide. Perform a functional check and vacuum test using the Gates Seal Check unit before diving. Thread lock collar... -
Page 23: Pla Disassembly
PLA Disassembly Page 23 4: PLA Disassembly To remove the PLA reverse the assembly steps. The only difference is the yellow barrel seal o-ring will not be removed until the adapter cone is rotated free of the port ring stack. -
Page 24: Additional Information
Proper care of your PLA is important to provide you reliable operation and long life. You’ll find all the guidelines in the “Housing Care and Maintenance” document included with your Gates housing. You can also find it on Gates web site at www.GatesHousings.com. -
Page 25: Customer Support
Customer Support Page 25 6: Customer Support Should you have any questions about the PLA and its operation, please contact Gates at the numbers below. Email: Customer.srvc@GatesHousings.com Web: www.GatesHousings.com Phone: 858.391.0052...
