Hitachi Advanced Server HA810
User Guide
This document is for the person who installs, administers, and troubleshoots servers and storage
systems. Hitachi Vantara assumes you are qualified in the servicing of computer equipment and
trained in recognizing hazards in products with hazardous energy levels.
MK-90HAS8000-00
December 2020
