Bard W24G4 Installation Instructions Manual

Hide thumbs Also See for W24G4:

page of 154

/ 154
Bookmarks

Quick Links

Download this manual

Literature Assembly

911-0799

Contains the following:

2100-034(G)

2100-479

2100-712(F)

2100-713(D)

2100-714

2110-1459(I)

7960-810

7960-420

User's Guide

Leak Test, Evacuation, Charging

Wall-Mount PKG A/C Manual

Multi-Tec A/C Install Instruct

Multi-Tec Quick Start Guide

Replacement Parts Manual

Supplemental 50HZ Instructions

Warranty

Need help?

Do you have a question about the W24G4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bard W24G4

Page 1 Literature Assembly 911-0799 Contains the following: 2100-034(G) User’s Guide 2100-479 Leak Test, Evacuation, Charging 2100-712(F) Wall-Mount PKG A/C Manual 2100-713(D) Multi-Tec A/C Install Instruct 2100-714 Multi-Tec Quick Start Guide 2110-1459(I) Replacement Parts Manual 7960-810 Supplemental 50HZ Instructions 7960-420 Warranty...
Page 3 USER’S APPLICATION GUIDE AND TECHNICAL PRODUCT OVERVIEW Manual: 2100-034G Supersedes: 2100-034F Date: 12-17-20 Bard Manufacturing Company, Inc. Bryan, Ohio 43506 www.bardhvac.com BARDHVAC.COM Climate Control Solutions...
Page 4 General Information The User's Application Guide covers a wide range of heating and cooling products manufactured by Bard Manufacturing Company. It is intended to be a general guide for care and operation of typical systems and covers the most important features you should be aware of and are responsible for as the user of the equipment.
Page 5 Heat Pumps and Heat Pumps and Heat Pumps The User's Application Guide and Technical Product Overview covers the following topics: • Documentation provided by Bard for proper use of your new product. • Unit installation guidelines. • Routine unit maintenance.
Page 6 Unit Literature Assembly – Documentation Provided with Your Unit Bard products are shipped with documentation that when used by a technician with cooling and heating knowledge, can ensure that your product is installed safely, performs optimally and achieves the longest life cycle possible.
Page 7 Unit Installation Installation plays a key part in unit functionality, performance and safety. Product securing and placement, duct design and supply/return location, electrical routing and condensate and defrost drainage all play key roles in making sure a unit will perform per the design specifications. WALL MOUNT Products –...
Page 8 WALL MOUNT Products – Clearances for Indoor Supply and Return Airflow The Bard unit should be placed in an area where the supply (leaving conditioned air) and return (unit air intake) air paths will be unrestricted. Avoid placing objects in the structure within 24" of the return (unit air intake) grille.
Page 9 Condensate Water Drainage: needs to be planned before installation. Your Unit condensate water exits the base new Bard WALL MOUNT product includes of the unit during cooling operation. provisions to allow condensate water to exit the bottom of the unit. If condensate water is to be...
Page 10 It is recommended to allow 15' (457.2 cm) in front of unit louver for proper condenser airflow. Always use common sense when installing products, follow unit clearances given in the installation instructions and contact local Bard distributors when additional knowledge is needed regarding unit clearances for proper unit functionality.
Page 11 I-TEC and Q-TEC Products – Clearances for Indoor Supply and Return Airflow The Bard unit should be placed in an area where the supply (leaving conditioned air) and return (unit air intake) air paths will be unrestricted. Avoid placing objects inside the room within 24" of the return (unit air intake) louvers or grille.
Page 12 This is collected in an evaporator pan and needs to be drained to an external drainage system. Your new Bard product includes provisions to allow condensate water to exit the unit and fittings will need to be field supplied to connect the unit drain to the building.
Page 13 Failure to do so may result in death, injury or product damage. A proper power supply to your new Bard unit is very important. Be sure to verify the following with a multi-meter or other power measuring device before applying power to your Bard product.
Page 14 Outdoor Unit Wall Mount Room Air Filters Wall mount filters are normally accessed from the outside of the building. Bard does offer a return air grille with a filter frame built-in for indoor filter access. The return air filter grille is not acceptable as the only source of filtration if vent options are installed in the wall mount unit.
Page 15 WALL MOUNT Products – Filters and Filter Servicing The built-in filter tray and room air filters in the wall mount are located in the middle of the cabinet below the indoor blowers. Units with vent options will have a washable screen behind the vent intake panel. Filter Door: The unit room air filter is located behind Vent Intake...
Page 16 The washable filters are used to remove dirt and dust from outdoor air that is entering the vent area. If at any time these filters are damaged, they must be replaced with Bard-approved filters. I-TEC Filter Locations:...
Page 17 Q-TEC Indoor Products – Filters and Filter Servicing The Q-TEC indoor air conditioners and heat pumps have two room air filters that must be replaced when servicing the unit. Filters play an important part in proper unit operation and prevent dirt and dust buildup inside the Q-TEC and the room the unit is installed in.
Page 18 Coils should be ordered with a corrosion protective coating. Contact Bard for coating options. 3. Frequent cleaning and waxing of the cabinet using a good automobile polish will help extend its original appearance and protect painted surfaces.
Page 19 All Products – Condenser Airflow W**A, W**H, T**H, T**S, W*RV Wall Mount Units: These units are called “blow through condenser airflow” units because they draw cool outdoor air from the sides and blow the warm condenser air exiting the coil through the front grille. C**H Wall Mount Units: These units are called “draw through condenser airflow”...
Page 20 Unit Operation Air-to-Air Cooling Products (Air Conditioners) The cooling mode operates similar to a refrigerator, removing heat from inside the conditioned space and rejecting it outside of the space being controlled. There are three main parts of the system: 1. The evaporator (indoor) coil where cold refrigerant absorbs heat from the air, which circulates from the conditioned space through the machine and is returned to the space at a lower temperature and with some of the humidity (moisture) removed.
Page 21 terminates, the reversing valve will shift back to heating mode and the outdoor fan will restart. There is typically a large puff of steam emitted as the fan restarts. When the heat pump shifts from cool to heating mode, from heating to cooling mode and especially during defrost cycles, there will be a pressure transfer sound heard as the reversing valve redirects the flow of refrigerant.
Page 22 Ventilation Options (Air-to-Air or Water-to-Air Systems) All Bard systems are available with factory-installed vent options. Most units can have ventilation field installed after unit installation.
Page 23 Helpful Hints and Good Operating Practices The following information will help you enjoy the full comfort and benefits of your Bard cooling and heating system, maximize the performance and efficiency and help extend the life of your system.
Page 25 SERVICING PROCEDURE R-410A LEAK TEST EVACUATION CHARGING Bard Manufacturing Company, Inc. Manual No.: 2100-479 Supersedes: NEW Bryan, Ohio 43506 File: Volume I, Tab 1 Since 1914...Moving ahead, just as planned. Date: 03-08-07 Manual 2100-479 Page 1 of 11...
Page 26 CONTENTS General Troubleshooting the Mechanical System Recovery Equipment Rated for R-410A ....3 Air Conditioning & Heat Pump - Cooling .....9 Leak Detectors ............3 Gauge Manifold ............3 Low Suction — Low Head Pressure ......9 High Suction — Low Head Pressure ......9 Attaching Gauge Manifold ........3 Low Suction —...
Page 27 GENERAL GAUGE MANIFOLD WARNING WARNING The oils used with R-410A refrigerant are hydroscopic and absorb water from the Gauge manifold must be suitable for use atmosphere readily. Do not leave systems with R-410A refrigerant and POE oils. open to the atmosphere for more than 5 minutes.
Page 28 3. Close drum valve and disconnect from center port. ATTACHING MANIFOLD HOSE TO Release nitrogen or CO2 into the atmosphere through SCHRADER VALVE suction line of gauge manifold. 4. Correct any leaks and recheck. When leaks, if any, WARNING have been repaired, system is ready to be evacuated and charged.
Page 29 R-410A System Charging CHARGING THE SYSTEM BY WEIGHT Even though R-410A has a very small fractionation potential, 1. Connect manifold as instructed. it cannot be ignored completely when charging. To avoid fractionation, charging of an air conditioner or heat pump 2.
Page 30 FIGURE 1 TYPICAL AIR CONDITIONING SYSTEM COOLING CYCLE MIS-369 Manual 2100-479 Page 6 of 11...
Page 31 FIGURE 2 TYPICAL HEAT PUMP SYSTEM COOLING CYCLE MIS-368 Manual 2100-479 Page 7 of 11...
Page 32 WARNING To speed refrigerant flow, it may be necessary to place refrigerant drum in a pan of warm water (not greater than 130ºF). Remember to either consider the total weight of the pan of water or remove the drum for weighing frequently to keep track of the charging process.
Page 33 roubleshooTing The echanical ysTeM AIR CONDITIONING AND HEAT PUMP — COOLING LOW SUCTION — LOW HEAD LOW SUCTION — HIGH HEAD PRESSURE PRESSURE 1. Restricted airflow over indoor coil. 1. Partial restriction and then overcharged. 2. Defective indoor fan motor. HIGH SUCTION — HIGH HEAD 3.
Page 34 Manual 2100-479 Manual 2100-479 Page 10 of 11 Page 10 of 11...
Page 35 Manual 2100-479 Manual 2100-479 Page 11 of 11 Page 11 of 11...
Page 37 IT IS THE RESPONSIBILITY OF INSTALLER TO KNOW AND UNDERSTAND ALL OF THESE REQUIREMENTS. FAILURE TO DO SO COULD CREATE A HAZARD RESULTING IN PROPERTY DAMAGE, BODILY INJURY, OR DEATH. Bard Manufacturing Company, Inc. Manual No.: 2100-721F Bryan, Ohio 43506 Supersedes: 2100-721E...
Page 38 CONTENTS Page Page 19. Manifold Pressure Adjustment ......29 Getting Other Information and Publications ...4 20. Checking Gas Input Rate ........ 29 Wall Mount Gas/Electric General Information ..5 21. Standard Orifice Sizing and High W**G Series Model Nomenclature ..... 5 Altitude Derate ..........
Page 39 Table 11B Natural Gas Orifice Tables – W42-60G ... 33 Units with Economizers ....... 24 Figure 12 Low Voltage Wiring – Thermostat Using Table 12 W24G4 Indoor Blower Performance ..46 Separate Temperature and Humidity Table 13 W30G4 Indoor Blower Performance ..47 Controllers ......... 25 Table 14 W36G4 Indoor Blower Performance ..
Page 40 Getting Other Information and Publications For more information, contact these publishers: These publications can help when installing the furnace. They can usually be found at the local library or purchased directly from the publisher. Be sure to ACCA Air Conditioning Contractors of America consult the current edition of each standard.
Page 41 WALL MOUNT GAS/ELECTRIC GENERAL INFORMATION Model Number Nomenclature – REVISION MODEL COLOR VENT CONTROL OPTIONS Wall Mount (See table X – Beige (See table page 6) GAS/ELECTRIC below) 1 – White VOLTAGE 4 – Gray COOLING 230/208-60-1 – 8 – Bronze COIL OPTIONS CAPACITY 230/208-60-3...
Page 42 Air Conditioning Module Options Factory Installed Field Installed     Code Part  CMA-45 (WG4D Units) • CMA-46 (WG4 Units) • Field Only SK111 or CMC-15 STD – Standard equipment.  CCM Compressor control module has adjustable 30 second to 5 minute delay-on-break timer. On initial power up, or any time the power is interrupted, the delay-on-make will be 2 minutes plus 10% of the delay-on-break setting.
Page 43 Manual 2100-721F Page 7 of 55...
Page 44 Manual 2100-721F Page 8 of 55...
Page 45 Manual 2100-721F Page 9 of 55...
Page 46 CAUTION During the initial firing of the burners there will probably be some amount of smoke issued to the circulating air stream as the result of residual oil burning off of the heat exchanger tubes. This oil is required during the forming process of the stainless steel heat exchanger tubes to facilitate the bending.
Page 47 Any grille that meets with the 5/8" louver criteria may material overhang projects above the unit (see be used. It is recommended that Bard Return Air Grille Figures 3A and 3B). If a combustible wall, use a or Return Filter Grille be installed when no return minimum of Figure 1 “A”...
Page 48 3. Locate and mark lag bolt locations and bottom mounting bracket location. 4. Mount bottom mounting bracket. 5. Hook top rain flashing under back bend of top. Top rain flashing is shipped secured to the right side of the back. 6.
Page 49 Manual 2100-721F Page 13 of 55...
Page 50 Manual 2100-721F Page 14 of 55...
Page 51 FIGURE 3A Combustible Clearance for W24G, W30G and W36G Models FIGURE 3B Combustible Clearance for W42G, W48G and W60G Models WARNING A minimum of 1" clearance must be maintained between the supply air duct and combustible materials. This is required for the first 3' of ducting. It is important to insure that the one 1"...
Page 52 FIGURE 4 Wall Mounting Instructions FIGURE 5 Wall Mounting Instructions Manual 2100-721F Page 16 of 55...
Page 53 FIGURE 6 Common Wall Mounting Installations Manual 2100-721F Page 17 of 55...
Page 54 TABLE 2 9. Clearances Minimum Installation Clearances Minimum clearances, as specified in Table 2, must be maintained from adjacent structures to provide Outlet Duct adequate fire protection, adequate combustion air and 1" first 3' (from combustible materials) room for service personnel. While minimum clearances are acceptable for safety Vent Terminal 17"*...
Page 55 10. Vent Terminal and Combustion Air 11. Optional Vertical Venting Inlet Hood With the optional vertical venting kit (VVK-5), this unit may be vented vertically through a roof or overhang. The vent terminal is shipped in the burner The kit includes a stainless steel transition drain tee, compartment (see Figure 7).
Page 56 12. Vent Resizing Instructions FIGURE 9 Fresh Air Damper When an existing furnace is removed from a venting system servicing other appliances, the venting system is likely to be too large to properly vent the remaining attached appliances. The following steps shall be followed with each of the appliances remaining connected to the common venting system, placed in operation one at a time while the other appliances remaining connected to the...
Page 57 This means that the field wiring used must be sized to separate devices which are field installed and located, carry that amount of current. All models are suitable shall conform with the temperature limitation for only for connection with copper wire. Each unit and/or Type T wire {63°...
Page 58 NOTE: The voltage should be measured at the field Unit Shutdown Feature (Standard on All Models) power connection point in the unit and while The RT terminal is the 24VAC transformer output, the unit is operating at full load (maximum and the R terminal is the 24VAC hot terminal for the amperage operating condition).
Page 59 Occupancy Sensor, BACnet If the unit is being installed with any ventilation package, a Bard LAC kit must be installed. Failure to 2 stage Cool; 2 stage Heat Programmable/Non-Programmable Elec- utilize an LAC with any air conditioner can cause coil...
Page 60 #8403-084 UNIT CONTROL PANEL UNIT LOW VOLTAGE B/W1 TERM. STRIP FACTORY INSTALLED JUMPER Optional CO2 Controller VENT ORANGE Bard Part #8403-096 BROWN/WHITE PACKAGE RED/WHITE 24VAC WIRING BLUE PLUG BLACK/WHITE C02 OUT TEMP-OUT SET SWITCH ON THERMOSTAT TO "GAS-OIL" CONFIGURE THERMOSTAT FOR HEAT/COOL MUST INSTALL JUMPER FOR 8403-057 OR OTHER THERMOSTAT THAT DOES NOT HAVE OCCUPANCY OUTPUT.
Page 61 RC Y2 (TH522OD1151) or T6 Pro 8403-090 UNIT CONTROL PANEL UNIT LOW VOLTAGE B/W1 TERM. STRIP FACTORY INSTALLED JUMPER Electronic Humidistat Bard part # 8403-047 YELLOW (H200-10-21-10) Mechanical Humidistat U/DEH U/DEH BARD PART 8403-038 Bard part # (H600A 1014) #8403-100 (H6062A1000) SET SWITCH ON THERMOSTAT TO "GAS-OIL"...
Page 62 FIGURE 13 Low Voltage Wiring JIFM Economizer Low Voltage Wiring Diagram 8403-058 (TH5220D1151) Thermostat YO/D W1/E part #8403-060 UNIT CONTROL PANEL UNIT LOW B/W1 VOLTAGE FACTORY INSTALLED JUMPER YELLOW/RED PINK WIRES YELLOW FROM BLUE PLUG PURPLE RED/WHITE BLACK/WHITE Must be energized to enable minimum position. NOTE: Economizer Control Default Setting is 10V (100%).
Page 63 FIGURE 14 Gas Pipe Connection W24G – W36G W42G – W60G Manual 2100-721F Page 27 of 55...
Page 64 18. Gas Supply and Piping 8. Refer to Table 9 for gas pipe sizes for natural gas. If more than one appliance is supplied from a General Recommendations single line size, capacity must equal or exceed the 1. Be sure the gas line complies with the local codes combined input to all appliances, and the branch and ordinances, or in their absence with the lines feeding the individual appliances properly...
Page 65 5. Slowly open equipment shut-off valve in gas supply PROPANE (LP) GAS CONVERSION line just ahead of furnace. Start furnace following “Operating Instructions” on front door. This unit may be converted in the field for 6. Slowly open 1/8" NPT manual shut-off valve use with propane (LP) gas.
Page 66 Natural Gas Input Rate Example: Natural gas heating value (BTU/cu. ft.) can vary If the gas water heater, dryer, two range burner significantly. Before starting natural gas input check, pilots and one oven pilot were left on, allow: obtain gas heating value at the location from local Water heater pilot 1000 BTU per hour supplier.
Page 67 21. Standard Orifice Sizing and High It is the installer’s responsibility to see that the furnace input rate is adjusted properly. Derating must Altitude Derate be achieved by reducing the size of the main burner This furnace is shipped with fixed gas orifices for use orifices.
Page 68 TABLE 11A Natural Gas Orifice Tables for Models W24G, W30G and W36G 6,001' to 8,000' 8,001' to 10,000' Up to 6,000' No Requires Pressure Switch Factory Standard Gas Heat* Value Requires Pressure Switch Changes Except Change and Orifice Input BTU/Cu. Ft. Change and Orifice Change for BTU Content Change Based on BTU...
Page 69 TABLE 11B Natural Gas Orifice Tables for Models W42G, W48G and W60G 6,001’ to 8,000’ 8,001’ to 10,000’ Up to 6,000’ No Requires Pressure Switch Factory Standard Gas Heat* Value Requires Pressure Switch Changes Except Change and Orifice Input BTU/Cu. Ft. Change and Orifice Change for BTU Content Change Based on BTU...
Page 70 22. Conversion of Gas Input BTUH from tip in center of plenum to ensure proper temperature measurement. High to Low Rating 6. Place second thermometer in return air duct All the derated WG series units are produced with approximately 2' from furnace. Locate thermometer maximum BTUH input orifices installed.
Page 71 FIGURE 16 Access Internal Filter Through Upper Service Door FILTER FILTER SERVICE DOOR MIS-3237 Manual 2100-721F Page 35 of 55...
Page 72 25. Compressor Control Module Test Mode By rapidly rotating the potentiometer (POT) clockwise The compressor control module is standard on models (see Figure 17), all timing functions will be removed covered by this manual. for testing. Features The conditions needed for the unit to enter test mode Delay-on-Make Timer are as follows: POT must start at a time less than or Short Cycle Protection/Delay-on-Break...
Page 73 FIGURE 17 8201-171 COMPRESSOR CONTROL MODULE High Pressure Switch Compressor Contactor Output 18-30 VAC Input Alarm Output Y Input from Thermostat Common and High Pressure Switch 8201-171 Troubleshooting Light Delay-on-Break Time Adjustment Potentiometer Low Pressure Switch Brownout Ignore Time DIP Switches* * Turn on only one switch for that specific "Ignore Time"...
Page 74 27. Lighting and Shutdown Instructions FIGURE 18 Lighting and Shutdown Instruction Label   BEND & PEEL “HERE” TO REMOVE LABEL LINER FOR YOUR SAFETY READ BEFORE OPERATING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
Page 75 FIGURE 19 28. Service Agency Procedures Top View of Gas Control CAUTION Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. WARNING Follow these procedures before inspecting MIS-165 furnace.
Page 76 Routine Inspection Annual Maintenance 1. Inspect the physical support of the unit annually to Routine inspection and maintenance procedures are the responsibility of the user and are outlined below. make sure it is securely fastened to the building. Also look for any obvious signs of deterioration. 1.
Page 77 is needed. FIGURE 20 Motor Connections FIGURE 10 LINE POWER GROUND LINE POWER ↓ ↓ L2 LINE EARTH L1 LINE POWER GROUND POWER NOTE: MOTOR IS CONSTANTLY POWERED BY LINE VOLTAGE or minus 10% of the nominal line power VAC is acceptable.
Page 78 FIGURE 21 FIGURE 11 Motor Connections 24VAC Common 24VAC "R" Signal through thermostat output. Speed Tap 1: Balanced Climate Speed Speed Tap 2: Cool Speed Speed Tap 3: Cool High Speed Speed Tap 4: Heat Speed Speed Tap 5: Heat High Speed 24VAC Common 24VAC "R"...
Page 79 32. Sequence of Operation – Heating 33. Sequence of Operation – Cooling On a call for heat from the thermostat, the induced On a call for cooling from the room thermostat, the draft blower is energized. Once sufficient draft is blower relay will be energized as well as the compressor contactor.
Page 80 34. Setting Unit Airflow • Remove the black wire from the unused terminal and then remove the red wire from the heat All models have multiple speed direct drive blower terminal. motors. If supply and return ducts are connected to the •...
Page 81 Each speed tap terminal block below the furnace control board. is programmed by Bard at the factory to different motor torque settings (see Figure 25). NOTE: Be sure to adjust the system static or blower TROUBLESHOOTING GE X13-SERIES ECM2.3...
Page 82 TABLE 12 W24G4 Indoor Blower Performance @ 230 and 460 VOLTS Recommended W24G cooling airflow range at rated 800 CFM @ 0.10 ESP (WC) is 700 - 910 CFM Factory set on Rated speed for cooling and Medium speed for heating.
Page 83 TABLE 13 W30G4 Indoor Blower Performance @ 230 AND 460 VOLTS Recommended W30G cooling airflow range at rated 900 CFM @ 0.15 ESP (WC) is 750 - 1150 CFM Factory set on Rated speed for cooling and Medium speed for heating. COOLING MODE MANUAL FAN and HEATING MODE Inches...
Page 84 TABLE 14 W36G4 Indoor Blower Performance @ 230 AND 460 VOLTS Recommended W36G cooling airflow range at rated 1100 CFM @ 0.10 ESP (WC) is 940 - 1250 CFM Factory set on Rated speed for cooling and Medium speed for heating. COOLING MODE MANUAL FAN and HEATING MODE Inches...
Page 85 TABLE 15 W42G4 Indoor Blower Performance @ 230 AND 460 VOLTS Recommended W42G cooling airflow range at rated 1300 CFM @ .15 ESP (WC) is 1030 - 1480 CFM Factory set on Rated speed for cooling and Medium speed for heating. COOLING MODE MANUAL FAN and HEATING MODE Inches...
Page 86 TABLE 16 W48G4 Indoor Blower Performance @ 230 AND 460 VOLTS Recommended W48G cooling airflow range at rated 1450 CFM @ .20 ESP (WC) is 1150 - 1680 CFM Factory set on Rated speed for cooling and Medium speed for heating. COOLING MODE MANUAL FAN and HEATING MODE Inches...
Page 87 TABLE 17 W60G4 Indoor Blower Performance @ 230 AND 460 VOLTS Recommended W60G cooling airflow range at rated 1650 CFM @ .20 ESP (WC) is 1360 - 1850 CFM Factory set on Rated speed for cooling and Medium speed for heating. COOLING MODE MANUAL FAN and HEATING MODE Inches...
Page 88 TABLE 18 Integrated Furnace and Blower Control Operation IGNITION SEQUENCE CONTROL Ignition Source 24 VAC DSI Flame Sensing Remote Timings - Prepurge 15 seconds - Postpurge 30 seconds (0 if cycle terminated before valve “on”) - Inter-trial purge 15 seconds - Pressure switch proving period 60 seconds - Trials for ignition...
Page 89 465.3 493.6 523.2 553.8 80° DB Low Side 128.0 131.1 134.0 136.8 139.4 142.0 144.4 146.7 148.8 150.8 152.7 W24G4 67° WB High Side 305.6 326.7 348.9 372.3 396.8 422.4 449.2 477.2 506.3 536.6 568.0 85° DB Low Side 132.5 135.7...
Page 90 36. R-410A Refrigerant Charge 38. Low-NOx Burner Assembly “N” Suffix Models Only – This unit was charged at the factory with the quantity U.S. Installations Only of refrigerant listed on the serial plate. AHRI capacity and efficiency ratings were determined by testing with Natural Gas Models Only this refrigerant charge quantity.
Page 91 INDEX Wiring Diagrams Unit Basic Model No. Wiring Diagram W24G4-A 4085-177 W24G4-B 4085-277 W24G4-C 4085-400 W30G4-A 4085-177 W30G4-B 4085-277 W30G4-C 4085-400 W36G4-A 4085-177 W36G4-B 4085-277 W36G4-C 4085-400 W42G4-A 4085-177 W42G4-B 4085-277 W42G4-C 4085-400 W48G4-A 4085-177 W48G4-B 4085-277 W48G4-C 4085-400 W60G4-A...
Page 93 INSTALLATION INSTRUCTIONS Bard Air Conditioning System MULTI-TEC LC6000-200 ® W18-36A/LB Supervisory Wall-Mount Controller Air Conditioner Bard Manufacturing Company, Inc. Manual: 2100-713D Bryan, Ohio 43506 Supersedes: 2100-713C www.bardhvac.com Date: 10-22-21 Page 1 of 44...
Page 94 CONTENTS Figure 12 Typical LC6000-200 Component Location ..20 General Information ............3 Figure 13 LC6000 Fused Power Supply Terminal ..21 List of Necessary Materials/Tools ......6 Figure 14 Remote Indoor Temperature/Humidity Site Preparation ............7 Sensor Installation ........22 Model Identification ..........7 Figure 15 Additional Remote Sensor Installation ..
Page 95 (one sensor per zone) will need to be purchased and installed in the additional zones. One additional temperature-only sensor (Bard P/N 8301-058) may also be used in Zone 1 but will also need to be purchased separately. Additional temperature/humidity sensors require field-supplied 5-wire 18 gauge shielded cable.
Page 96 Ventilating Systems ....ANSI/NFPA 90A unit for PGD or th-Tune operation. The th-Tune and Standard for Warm Air Heating TEC-EYE diagnostic tool are available as a kit (Bard and Air Conditioning Systems ....ANSI/NFPA 90B P/N 8620-264). Load Calculation for Residential Winter General and Summer Air Conditioning .....
Page 97 ANSI Z535.5 Definitions: DANGER: Indicate[s] a hazardous situation which, if not avoided, will result in death or serious injury. The signal word “DANGER” is to be limited to the most extreme situations. DANGER [signs] should not be used for property damage hazards unless personal injury risk appropriate to these levels is also involved.
Page 98 LIST OF NECESSARY MATERIALS/TOOLS Additional hardware and miscellaneous supplies are needed for installation. These items are field supplied and must be sourced before installation. This list also includes tools needed for installation. List of Materials/Tools • Personal protective equipment/safety devices/anti- •...
Page 99 Each installation See Specifications Sheets S3595 or S3610. is unique and may require special accommodations and modifications. Although Bard Manufacturing follows a Clearance to Combustibles long-established tradition of manufacturing equipment using industry standard dimensions for building...
Page 100 FIGURE 2 Dimensions of Basic Unit for Architectural and Installation Requirements (Nominal) SUPPLY RETURN WIDTH DEPTH HEIGHT MODEL W18*B 33.300 17.125 74.563 7.88 19.88 11.88 19.88 35.00 10.88 29.75 20.56 30.75 32.06 33.25 31.00 2.63 34.13 26.06 10.55 4.19 12.00 9.00 W24*B W30*B...
Page 101 WALL-MOUNT UNIT MOUNTING Mounting the Units 5. If desired, hook top rain flashing (attached to front- right of supply flange for shipping) under back bend of top. WARNING 6. Position unit in opening and secure with fasteners sufficient for the application such as 5/16" lag/ anchor/carriage bolts;...
Page 102 Manual 2100-713D Page 10 of 44...
Page 103 Manual 2100-713D Page 11 of 44...
Page 104 FIGURE 5 Electric Heat Clearance FIGURE 6 Wall Mounting Instructions WALL STRUCTURE See FIGURE 2 – Mounting Instructions FACTORY SUPPLIED RAIN FLASHING. MOUNT ON UNIT BEFORE INSTALLATION SUPPLY AIR SUPPLY AIR SUPPLY AIR DUCT OPENING OPENING RETURN AIR RETURN AIR RETURN AIR OPENING OPENING...
Page 105 FIGURE 7 Wall Mounting Instructions SEE UNIT DIMENSIONS, FIGURE 2, SEE UNIT DIMENSIONS, FIGURE 1.2, FOR ACTUAL DIMENSIONS. FOR ACTUAL DIMENSIONS E + 1.000 ATTACH TO TOP PLATE OF WALL 1.000 1.000" CLEARANCE ALL AROUND DUCT SUPPLY DUCT OPENING INTERIOR FINISHED WALL OVER FRAME 1.000"...
Page 106 FIGURE 8 Common Wall Mounting Installations Non-Ducted Installations Ducted Installations Unit is Unit is Ceiling Ceiling sealed to sealed to wall. wall. Supply Air Duct Adjustable Supply Grille Optional Dropped Ceiling Wall Wall Mount Mount Fixed Blade Unit Unit Fixed Blade Return Grille Return Grille Indoor Area Indoor Area...
Page 107 3/17/2014 3/17/2014 DATE insulation grades of wiring material. All wiring must conform to NEC and all local codes. SCALE DRAWN BY Bard Mfg. Co. Bryan, Ohio 3/17/2014 ADDED FRENCH VERSION 11182 BD SD RP CHECKED APPROVED The unit rating plate and Tables 1, 2 and 3 list fuse...
Page 108 TABLE 1A Electrical Specifications − W**ABP Series − 60Hz Units Single Circuit Multiple Circuit   Maximum   Rated   Minimum Field  External Fuse Field Power Ground Model Volts Maximum Field  Circuit Power Minimum Wire Size Wire Size External Power...
Page 109 TABLE 1B Electrical Specifications − W**LBP Series − 60Hz Units Single Circuit Multiple Circuit   Maximum   Rated   Minimum Field  External Fuse Field Power Ground Maximum Field Model Volts  Circuit Minimum Power Wire Size Wire Size External Power...
Page 110 TABLE 3A Electrical Specifications − W**ABP Series − 50Hz Units Single Circuit Operating No. Field Rated Volts & Model Voltage Power   Phase Range Circuits Minimum Circuit Maximum External Ampacity Fuse or Ckt. Brkr. W24ABPD00, D0Z 240/220-1 254-198 W24ABPF00, F0Z 415/380-3 ...
Page 111 Once the first of the Bard To turn the unit on or off with TEC-EYE: MULTI-TEC wall-mount units is installed, orphan mode 1.
Page 112 LC6000 CONTROLLER INSTALLATION FIGURE 12 Typical LC6000-200 Component Location Transformer RJ11 Cable to Display Control Board Ethernet Cable Connection USB Male A to Micro Male Four Fused B Cable Power Supply Terminals Emergency Off Alarm Jumper Emergency Vent Alarm Jumper Generator Run Alarm Jumper Terminal Block...
Page 113 IMPORTANT: When working with circuit board connecting wires to the terminal block, confirm that the components, Bard recommends the use of fuse in each of the four fuse holders is in the proper an anti-static wrist strap to prevent static position (active) as shown in Figure 13.
Page 114 Installing Remote Indoor Temperature/Humidity Sensor(s) One remote indoor temperature/humidity sensor and 35' of 18 gauge 5-conductor shielded cable is included with the controller. This sensor must be installed for proper operation. Mount the temperature/humidity sensor in a location least likely to be affected by open doors, rack-mounted fans, radiant heat sources, etc. Locating the sensor between both return grilles is often the best location, but every installation is unique.
Page 115 For proper operation, the remote indoor temperature/humidity sensor (and any additional sensors) must be configured properly with the controller as shown in Step 2 on page 22. An additional remote indoor temperature- only sensor can be purchased and installed in Zone 1. If the site in which the LC6000 controller will be used has more than one zone (maximum three zones per LC6000), additional remote temperature/humidity sensors (one per zone) will need to be purchased and installed in the additional zones.
Page 116 Installing Optional Outdoor Temperature/Humidity Sensor One optional outdoor temperature/humidity sensor (8301-090) can be installed. Follow the manufacturer's mounting instructions. Use 18 gauge 5-conductor shielded cable to connect to controller. The maximum cable length to connect the temperature/humidity sensor to the LC6000 is 98'. FIGURE 16 Remote Outdoor Temperature/Humidity Sensor Installation Connect wires from the 18 gauge shielded cable to terminals #65, #66, #67, #70 and #71.
Page 117 Emergency Off, Emergency Ventilation and Generator Run Connections The LC6000-200 controller is shipped with emergency off, emergency ventilation and generator run contacts. There are factory-installed jumpers across terminals #6 and #7 (emergency off), #8 and #9 (emergency ventilation) and #10 and #11 (generator run). Remove the factory-installed jumpers before making the connections. FIGURE 17 LC6000-200 Series Connection for Emergency Off, Emergency Ventilation and Generator Run (If Applicable) Generator Run*...
Page 118 Communication Wiring Connect the communication wiring from the wall-mount units to the controller in the manner shown in Figures 18, 19 or 20. The daisy chain does not need to follow the addressing order. The communication wire should be 2-wire, 18 gauge shielded cable with drain.
Page 119 FIGURE 20 Placement of Communication Wire Filters (Daisy Chain and Alternate Methods) Daisy Chain Wiring Place filter here Place filter here (end unit) LC6000 ... up to 14 units Unit 1 Unit 2 Unit 3 Unit 4 Unit 5 Alternate Wiring Place filter here Place filter here (end unit)
Page 120 The steps outlined on the following pages show how to connect the communication wiring using the daisy chain method shown in Figure 18. If using the alternate method (as shown in Figure 19), the connections to the controller and each wall-mount unit will be the same but the filters need to be placed in the positions shown in Figure 20. FIGURE 21 Communication Wiring: Termination at the Controller Using the field-provided shielded cable, make a small service loop after entering the controller and attach the provided...
Page 121 FIGURE 22 Communication Wiring: Termination at the First Wall-Mount Unit Wall-Mount Unit 1 R+T+ / R-T- RS485 PLAN Control Board  From LC6000 Controller From the controller, extend the shielded cable through a separate conduit and route to the provided terminal block next to the wall-mount control board.
Page 122 FIGURE 23 Communication Wiring: Termination at Additional Wall-Mount Units Wall-Mount Unit 2 – 14 R+T+ / R-T- RS485 PLAN Control Board  From Wall-Mount Route the cable from the first wall-mount unit to the Unit 1 RS485 terminal block of the second wall-mount unit. If this is the last unit to be connected, make a small service loop and attach EMI filter as shown.
Page 123 Supply Wiring The LC6000 controller is powered by 120, 208 or 240 volts from the shelter. Field-supplied supply wiring should be minimum 16 gauge, maximum 14 gauge (see Figure 24). A reliable earth ground must be connected in addition to any grounding from conduit. Grounding bolts and nuts are included with the controller for this purpose; a 2 hole grounding lug must be field supplied.
Page 124 Bard Guard Alarm Signal Common Signal for Outdoor Temperature Sensor Humidifier 2 Ground for Outdoor Temperature Sensor Common Ground for Bard Guard Alarm Signal Humidifier 3 Orange Power Connector Common 24 VAC+ 24 VAC Supply Emergency Off Alarm Orange Power Connector...
Page 125 FIGURE 26 LC6000-200 Wiring Diagram TB 61 YELLOW LC6000 G YELLOW BLUE TB 64 TERMINAL BLOCK G0 BLUE (L1) 120V IN WHITE 120V IN 120V/208V/230VAC (L1) 208V IN 208V IN TRANSFORMER (L1) 230V IN 230V IN ORANGE 24VAC (L2 OR N) COMMON IN COMMON IN BLACK GREEN...
Page 126 The LC6000 controller and TEC-EYE hand-held information on using the TEC-EYE. diagnostic tool will both be used to set up the Bard air conditioning system (the TEC-EYE is only used to set up The TEC-EYE connects to the wall-mount unit control the wall-mount units).
Page 127 To change these settings: version has been installed. Current software versions and installation instructions are 1) Press MENU key to access the Main Menu available on the Bard website at http://www. screen. bardhvac.com/software-download/ 2) Press UP or DOWN keys and ENTER key to enter USER password 2000.
Page 128 5) Press ENTER key to scroll to Run Test Enable 3. Clear Unit Alarm Logs on Each Unit parameter (see Figure 30). Units may have alarms logged due to testing. Unit 6) Press UP or DOWN key to change value to ON. alarm logs must be cleared at time of installation.
Page 129 3) Press the UP or DOWN keys to scroll to the Additional combination sensors may be purchased Settings menu; press ENTER key. or alternatively, temperature-only sensors may be purchased instead. The LC is capable of utilizing 4) Press UP or DOWN keys to scroll to Date/Time five temperature sensors and four humidity sensors.
Page 130 To enable/disable Zone 2 Indoor Humidity: 6) Press UP or DOWN key to change value to ON to enable sensor (or change value to OFF to 1) Press MENU key to go to the Main Menu disable sensor). screen. To enable/disable Zone 1 Indoor Temperature: 2) Press UP or DOWN keys and ENTER key to enter USER password 2000.
Page 131 FIGURE 38 6) Press UP or DOWN key to change value to ON Enable/Disable Zone 1 Remote Temperature Sensor to enable sensor (or change value to OFF to disable sensor). FIGURE 40 Enable/Disable Zone 3 Remote Temperature Sensor To enable/disable Zone 2 Remote Temperature: 1) Press MENU key to go to the Main Menu screen.
Page 132 4) Press UP or DOWN keys to scroll to Outdoor 7. Verify Units Are Online Air Temp C12. Once a unit is uniquely addressed, communication 5) Press ENTER key to scroll to Enable (see can be verified at the LC controller. Figure 42).
Page 133 FIGURE 44 10. Complete Installation Selecting Economizer Type Once all the installation steps have been completed, all alarms and alarm logs have been cleared and system verification and run test results were satisfactory, the installation can now be considered “complete". Additional programming information can be found in MULTI-TEC Service Instructions 2100-712 and LC6000 Service Instructions 2100-669.
Page 134 ADDITIONAL INFORMATION Menu Screens and Password Levels Parameter Config: Engineer (9254) Alarm Export: User (2000) MULTI-TEC Wall-Mount Units Logout: Used to log out of the current password System Config: User (2000) level. Entering back into the menu requires Adv Sys Config: Technician (1313) password.
Page 135 TABLE 6 TABLE 7 Wall-Mount Unit Status Messages LC6000 Status Messages Message Description Message Description Unit disabled due to faulty The LC6000 is ready and functioning Invalid Model # model number. properly. Unit is not currently communicating Orphan Mode The LC6000 is being turned off by the with an LC6000 or th_Tune device.
Page 136 Remote Indoor Temperature/Humidity Sensor Orientation Current versions of the remote indoor temperature/ humidity sensor need to be installed with the shielded cable wires entering the bottom of the back of the sensor to connect to the sensor terminals (see Figure 47).
Page 138  Exploded View ..........8 Important  Usage List ........... 8 Freecooling Components  Contact the installing and/or local Bard distributor for all parts requirements. Make sure to have the  Exploded View ..........9  Usage List ........... 9 complete model and serial number available from the unit rating plates.
Page 139 CABINET COMPONENTS SEXP-946 B Manual 2110-1459I Page 2 of 11...
Page 140 BOP-3 Blank Off Plate 5252-033 Bard Nameplate  E terior cabinet parts are manufactured with various paint color options. To ensure the proper paint color is received, include the complete model and serial number of the unit for which cabinet parts are being ordered.
Page 141 FUNCTIONAL COMPONENTS SEXP-945 Manual 2110-1459I Page 4 of 11...
Page 142 FUNCTIONAL COMPONENTS Dwg No. Part Number Description S900-364-001 Blower Assembly S900-365-001 Blower Assembly 900-364-002 Blower Assembly 900-365-002 Blower Assembly 917-0355 Evaporator Coil w/Distributor Assy. 917-0356 Evaporator Coil – Coated w/Distributor Assy. 917-0357 Evaporator Coil w/Distributor Assy. 917-0358 Evaporator Coil – Coated w/Distributor Assy. 800-0456 Distributor Assembly 800-0479...
Page 143 CONTROL PANEL SEXP-883 C Manual 2110-1459I Page 6 of 11...
Page 144 Replacement part will have a letter attached to the end of the part number to designate software version (Example: 8301-096-002A). A software upgrade of all PLCs onsite (units and controllers) should accompany any PLC replacement. Latest revisions of software, change log and instructions are available on the Bard website at http://www.bardhvac.com/software-download/ Circuit breakers listed are for units without electric heat, “0Z”...
Page 145 BLOWER ASSEMBLY SEXP-944 Dwg No. Part Number Description S8106-068-0150 Programmed Blower Motor & Control (230/208V) S8106-068-0152 Programmed Blower Motor & Control (230/208V) S8106-069-0151 Programmed Blower Motor & Control (460V) S8106-069-0153 Programmed Blower Motor & Control (460V) C8106-068-0150 Programmed Control Only (230/208V) C8106-068-0152 Programmed Control Only (230/208V) C8106-069-0151...
Page 146 FREECOOLING COMPONENTS SEXP-859 A Dwg. No. Part Number Description 137-738 Lower Front Partition 137-745 Lower Rear Fill S101-979 Right Side S137-865 Upper Rear Partition S101-978 Left Side S105-1344 Blade Seal Angle S139-324 Blade S137-867 Upper Front Partition S137-740 Lower Rear Partition 141-430 Blade Support 8602-044...
Page 147 FREECOOLING AIR HOOD SEXP-752A Dwg. No. Part Number Description Hooded Front Door 115-284-*  115-291 Hooded Front Door 115-290  Hooded Front Door 113-538-* Bottom Divider Bracket  113-568 Bottom Divider Bracket Bottom Divider Bracket 113-571  S127-495-* Hood Bottom ...
Page 148 FREECOOLING DAMPER MOTOR WASHER SEXP-879 Dwg. No. Part Number Description 141-466 Actuator Support Plate 8602-067 Direct Coupled Actuator 8602-008 Ball Joint 8602-068 Belimo Actuator Crank Arm 1/2" 1012-174 1/4" - 20x3 - 1/4 Hex Cap Screws 1012-201 1/4-20 Steel Keps Hex Nut Zinc 141-464 Actuator Support Bar 113-655...
Page 150 Adjustment Factors when more than three conductors are in a raceway. IMPORTANT: While this electrical data is presented as a guide, it is important to electrically connect properly sized fuses and conductor wires in accordance with all existing local codes. Bard Manufacturing Company, Inc. Manual:...
Page 151 OUTDOOR FAN MOTOR – 50 HZ Models W42AC-E, W42AC-F, W48AC-E, W48AC-F, W60AC-E and W60AC-F have a condenser fan motor with a red and black speed tap. These units are shipped from the factory with the red lead connected. At no time is the black lead to be connected for 50HZ application.
Page 153 If you can not show us the actual date of purchase, the time periods in this warranty will start on the date that we shipped your Bard product from our factory.
Page 154  Factory-coated coils have a “5” year warranty in corrosive environments that are listed as approved. Internet Resources Recognized as a leader in the HVAC industry, Bard combines quality products and outstanding service with innovation and technological advances to deliver high- performance heating and cooling products around the world. Please visit www.bardhvac.com...
