- Page 1 Camera Hub G5 Pro (PoE) User Manual...
- Page 2 Product Introduction Camera Hub G5 Pro (PoE) supports 24/7 all-around use. With a video resolution of over 4 million pixels, a lens with a FOV of 133° (diagonal) , a large aperture of F1.0, and a 1/1.8"large-image sensor, it can maintain the output of color images in extremely dark environments.
- Page 3 Indicator Light Microphone Lens Spotlight PIR Sensor Tightening Adjustment Screw Adjustable Bracket Wall Mounted Bracket Fastening Screws USB-C Power Port Speaker Rear Cover Removal Screw Rear Cover Screw Hole Button Ethernet Cable 1/4 "Bracket Screw Hole Button Operation Press and Hold for 10s: Reset the Network and Unbind the Device Quick Press 10 Times: Restore Factory Settings...
- Page 4 Device Installation Select Installation Position Table placement, wall mounting, ceiling mounting can be selected for this product, and the instructions are as follows: Table Placement: The camera can be placed on a flat tabletop. After the product is successfully connected to the App, its tilt angle and left and right rotation angle can be manually adjusted based on real-time images, aiming the lens at the position that needs to be photographed.
- Page 5 2. Loosen the fastening screws of the wall mounted bracket, take out the bracket, attach it to the selected installation position on the wall, and mark the punching points. 3. Use a Ø6 mm drill bit to drill holes according to the marked positions, with a hole drilling depth ≥...
- Page 6 4. Use the tool to hammer the 4 expansion plugs into the drilled holes, ensuring a flat surface. 5. Use the self-tapping screws from the accessory pack to secure the bracket to the wall. 6. Insert the camera along with the other parts of the bracket into the groove of the wall mount bracket as shown below.
- Page 7 7. Take out the waterproof accessory RJ45 from the box and connect the network cable according to steps 1 and 2 as follows. 8. After successfully adding the camera to the App, manually adjust the pitch angle or left and right rotation angle of the bracket based on real-time video, and aim the lens at the position that needs to be photographed.
- Page 8 Router PoE Network Switch Router...
- Page 9 1. Download App Search for "Aqara Home" in the Apple App Store, Google Play, Xiaomi GetApps, Huawei App Gallery, or scan the following QR code to download the Aqara Home App. 2.Add Product to Aqara Home Please bind the camera to Aqara Home or HomeKit before installing it. Refer to the...
- Page 10 LAN as the camera. • During the network setup, it is necessary to scan the Aqara pairing QR code on the product or manual cover, or enter an 8-digit pairing code. Please follow the prompts on the App to complete the relevant operations.
- Page 11 The product has Zigbee hub feature. Please bind the child device according to Zigbee Child Device User Manual. 5.Other Functions For more device functions, please log in to the Aqara Home App to explore. Description of Indicator Lights Indicator Light Status...
- Page 12 User Information Use of the Works with Apple badge means that the accessory has been designed to work specifically with the technology marked in the badge and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliant safety and regulatory standards.
- Page 13 7. Please select an adapter with a minimum output parameter of 5V 2A to use with the product. Online Customer Service: www.aqara.com/support Manufacturer: Lumi United Technology Co., Ltd. Address: Room 801-804, Building 1, Chongwen Park, Nanshan iPark, No. 3370, Liuxian Avenue, Fuguang Community, Taoyuan Residential District, Nanshan District, Shenzhen, China.
- Page 14 User Manual Installation Video 模切走位≤±0.5mm Search for the device to be added Searching for Devices... Camera Hub G5 Pro (PoE) Camera Hub G5 Aqara Home App Pro (PoE) xxxx 色相正确、 印迹牢固、 xxxx Camera Hub G5 Pro (PoE) 套印准确、 各色套印 Router 不露杂色，...
- Page 15 šādā interneta adresē: at the following internet address: https://www.aqara.com/DoC/ (1) This device may not cause interference. https://www.aqara.com/DoC/ 1. See toode ei ole mänguasi, palun hoidke lapsed sellest tootest eemal.
