- Page 1 Tumble dryer WQB246DNBY [en] User manual and installation instructions...
-
Page 2: Table Of Contents
en Table of contents You can find additional information and explanations online. Scan the QR code on the title page. Table of contents Table of contents 1 Safety .......... 3 10.1 Preparing the laundry .... 2 4 1.1 General information... -
Page 3: Safety
Safety en 14.7 Intelligent programme recom- 17.2 Condensation container fil- mendation ........ 3 1 ter .......... 3 6 14.8 Remote diagnostics .... 3 2 18 Troubleshooting ...... 3 6 14.9 Data protection ...... 3 2 19 Transportation, storage and 15 Basic settings... -
Page 4: Restriction On User Group
en Safety 1.3 Restriction on user group This appliance may be used by children aged 8 or over and by people who have reduced physical, sensory or mental abilities or inadequate experience and/or knowledge, provided that they are supervised or have been instructed on how to use the appliance safely and have understood the resulting dangers. - Page 5 Safety en Never let the power cord come into contact with sharp points or edges. Never kink, crush or modify the power cord. WARNING ‒ Risk of fire! It is dangerous to use an extended power cord and non-approved adapters. Do not use extension cables or multiple socket strips. Only use adapters and power cords approved by the manufac- turer.
-
Page 6: Safe Use
en Safety If hoses and power cords have been laid incorrectly, this causes a tripping hazard. Lay hoses and power cords in such a way that there is no risk of tripping. If the appliance is moved by holding onto protruding components, such as the appliance door, the parts may break off. - Page 7 Safety en WARNING ‒ Risk of suffocation! Children may breathe in or swallow small parts, causing them to suffocate. Keep small parts away from children. Do not let children play with small parts. WARNING ‒ Risk of explosion! If there is coal dust or flour in the air around the appliance, this may cause an explosion.
-
Page 8: Safe Cleaning And Maintenance
en Safety Unwashed laundry that has come into contact with solvents, oil, wax, wax remover, paint, grease or stain remover may ignite when drying is in progress. Do not place laundry in this appliance to be dried if the laundry has not been washed first. Rinse the laundry thoroughly with warm water and detergent be- fore drying it in the machine. -
Page 9: Preventing Material Damage
Preventing material damage en If the power cord of this appliance is damaged, it must be re- placed by the manufacturer, the manufacturer's Customer Ser- vice or a similarly qualified person in order to prevent any risk. An ingress of moisture can cause an electric shock. Before cleaning, pull out the mains plug or switch off the fuse in the fuse box. -
Page 10: Environmental Protection And Saving Energy
en Environmental protection and saving energy Foam and foam rubber may deform Do not exceed the programme's or melt during the drying process. maximum load capacity. Pro- Page 21 Do not dry laundry that contains grammes foam or foam rubber. After drying, clean the fluff filter. "Cleaning the fluff filter", Unsuitable cleaning products may Page 27... -
Page 11: Contents Of Package
Installation and connection en Remove any accessories from the If residual water in the appliance drum. freezes, this may cause damage to Close the door. the appliance. Do not install or operate this appli- 4.2 Contents of package ance anywhere that is liable to ex- perience frost or outdoors. -
Page 12: Water Outlet Hose
en Installation and connection Against a wall water outlet hose properly to the connecting piece. Requirements The appliance and the accessory Page 10 have been unpacked. The appliance is installed at the in- stallation location. Pull out the condensation hose from the connecting piece. Do not trap the hoses and power cord between the wall and the appli- ance. -
Page 13: Aligning The Appliance
Installation and connection en Push the water outlet hose as far away quickly and eliminate any as it will go into the connecting blockages. piece. Drainage into a Secure the con- siphon. nection point with a (12-22 mm) hose clamp. Secure the water outlet hose with a hose guide at a height of at least... -
Page 14: Reversing The Door
en Installation and connection To align the appliance, turn the ap- 4.6 Reversing the door pliance feet. Check that the appli- Note: You can find more information ance is level using a spirit level. about changing the door direction online. Scan the QR code on the title page. -
Page 15: Familiarising Yourself With Your Appliance
Familiarising yourself with your appliance en 5 Familiarising yourself with your appliance Familiarising yourself with your appliance 5.1 Appliance You can find an overview of the parts of your appliance here. On certain models, specific details such as the colour and shape may differ from those pictured. -
Page 16: Control Panel
en Display 5.2 Control panel You can use the control panel to configure all functions of your appliance and to obtain information about the operating status. ATTENTION Page 21 Programmes Pressing on the display with force Programme selector may cause damage. Page 25 Do not apply heavy pressure on ... - Page 17 Display en If a software update is available, you can find further information in the Home Connect app. Example: Display Indicator Description 0:40 1 Expected programme duration or programme time re- maining in hours and minutes. 1 Recommendation for the maximum load capacity for the selected program in kg.
-
Page 18: Buttons
en Buttons Indicator Description Settings that are not available on the appliance have been set via the Home Connect app. You can find more information in the Home Connect app. Programme status: Crease-reduction function Programme status: Pause Programme status: Programme end 7 Buttons Buttons Below is an overview of the buttons and their setting options. Note: Additional functions may be available as a result of software updates. - Page 19 Buttons en Button Selection Description off, the childproof lock re- mains activated. "Childproof lock", Page 30 Multiple selection To change a setting, press the lection button until the dis- play shows the required setting. Basic Settings Multiple selection "Basic settings", Page 32 Favourite Store Press the button for ap- Adjust...
- Page 20 en Buttons Button Selection Description Once the programme has ended, the drum moves the laundry at regular in- tervals for 120 minutes to prevent creasing. Speed Perfect Activate Activate or deactivate a Deactivate shorter programme dura- tion. Note: Energy consump- tion and noise emissions increase.
-
Page 21: Programmes
Programmes en Button Selection Description Note: The washing ma- chine must be compatible with Home Connect. The washing machine and dryer must be connected to your home network and registered in your Home Connect app. Remote Start Activate Activate or deactivate re- Page 31 Deactivate mote start. - Page 22 en Programmes Programme Description Max. load (kg) Easy-Care Dry items made of synthetic materials or blended fabrics. Dry items made of cotton and synthetics. Bed Linen Dry duvet covers, pillowcases and sheets made of cotton. Note: The drum movement is optimised for drying large items of laundry.
-
Page 23: Timed Programmes
Accessories en Programme Description Max. load (kg) Towels Dry hard-wearing, heat-resistant towels and dressing gowns made of cotton or linen. Silent Dry Dry hard-wearing, heat-resistant fabrics made of cotton or linen. Suitable for quiet drying. App programs Select additional programmes directly via –... -
Page 24: Laundry
en Laundry Order number Connection kit To save space, stack the WTZ27510 appliance on a suitable washing machine of the same width and depth and that is from the same manufacturer. Connection kit with pull- To save space, stack the WTZ27500 out worktop appliance on a suitable washing machine of the... -
Page 25: Care Symbols On The Care La
Basic operation en Load the laundry unfolded into the 11.2 Setting a programme drum Press the required programme. Spin the laundry before drying Page 21 Dry woollen items, sports shoes and soft toys in the wool basket Wool basket 10.2 Care symbols on the care labels Drying care symbols Symbol... -
Page 26: Opening The Door
en Basic operation 11.4 Opening the door Press The display shows the programme Grip under the door handle and duration or the programme end pull on the door. time. After the programme has ended, the display shows: "End" . Note: When "Hot" is shown on the display, the appliance cools the laun- dry. -
Page 27: Fluff Filter
Basic operation en 11.11 Fluff filter Remove the fluff from the recess. During drying, fluff from the laundry is collected in the fluff filter. The fluff fil- ter protects the appliance from fluff. Cleaning the fluff filter If the drying programme has finished or the display shows a notification while the appliance is in operation, clean the fluff filter after the pro-... -
Page 28: Condensation Container
en Basic operation cleaning, pour the contents of the If you connect the water outlet hose, container through a filter, e.g. a you do not have to regularly empty coffee filter. the condensation container. "Emptying the condensation con- Dispose of the coffee filter with the tainer", Page 28 household waste in order to pre- vent the water from being contam-... -
Page 29: Dryness Level
Dryness level en Empty the condensation container. Dryness Description level For multi-layered, thick laundry that does not dry readily. For normal, single- layered laundry. For normal, single- layered laundry. The laundry is still slightly damp after the Check the condensation container programme ends. -
Page 30: Childproof Lock
en Childproof lock Press and hold Cupboard Dry The Home Connect services are not Cupboard Dry Plus or Iron Dry available in every country. The avail- for approx. 3 seconds. ability of the Home Connect function The display shows "0", "1", "2" or depends on the availability of the "3". -
Page 31: Deactivating Wi-Fi On The Ap
Home Connect en 14.2 Deactivating Wi-Fi on the 14.5 Resetting the appliance appliance network settings Press and hold Remote Start Press and hold Remote Start for approx. 3 seconds. for approx. 3 seconds. Press Remote Start repeatedly Press Remote Start repeatedly until the display shows "on". until the display shows "rES". -
Page 32: Intelligent Programme Recom
en Basic settings Intelligent programme recom- ted to the Internet, your appliance will transmit the following types of data to mendation the Home Connect server (initial re- Requirements gistration): Your washing machine has the Unique appliance identification Home Connect function. (consisting of appliance codes as Your washing machine and your well as the MAC address of the in- dryer must be connected to your... -
Page 33: Tings
Appliance care en If a software update is available, you Use the programme selector to se- can find further information in the lect the required basic setting. Page 32 Home Connect app. Adjust the basic setting: To change the value, press To reset the appliance to the factory settings, press and hold for approx. 3 seconds. -
Page 34: Running The Basic Appliance
en Appliance care Put the appliance into standby Press Page 26 mode. The appliance care programme Page 27 . Clean the fluff filter starts and a signal tone sounds. Empty the condensation container. "End" appears on the display and Page 28 a signal tone sounds once the ap- ... -
Page 35: Cleaning And Servicing
Cleaning and servicing en Press 17 Cleaning and servi- The appliance care programme Cleaning and servicing cing starts and a signal tone sounds. After around 3 hours, the appli- To keep your appliance working effi- ance pauses the appliance care ciently for a long time, it is important programme and the remaining to clean and maintain it carefully. -
Page 36: Condensation Container Fil
en Troubleshooting 17.2 Condensation container Clean the filter under warm, run- ning water. filter Note: Collect the cleaning water in During drying, fluff from the laundry a container, e.g. a bucket. After gets into the condensation. The filter cleaning, pour the contents of the in the condensation container pro- container through a filter, e.g. - Page 37 Troubleshooting en Fault Cause and troubleshooting The display goes out Energy-saving mode is active flashes. Press All other error codes. Malfunction To restart the appliance, press and hold for ap- proximately 5 seconds. If the fault occurs again, disconnect the appliance from the power supply for at least 30 seconds. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box.
- Page 38 en Troubleshooting Fault Cause and troubleshooting Home Connect is not Different causes are possible. Page 31 working properly. Reset the appliance network settings. Page 30 Set up Home Connect again. Go to www.home-connect.com . The programme does Childproof lock is activated. Page 30 not start. Deactivate the childproof lock.
- Page 39 Troubleshooting en Fault Cause and troubleshooting The laundry is too The load is too large. damp. Observe the programme's maximum load capacity. Page 21 After the end of the programme, warm laundry feels damper than it actually is. Remove the laundry from the drum as soon as the drying programme has finished.
-
Page 40: Transportation, Storage And Disposal
en Transportation, storage and disposal Fault Cause and troubleshooting Condensation collects Not a fault. The remaining volume of condensation may in the condensation remain in the condensation container. container despite the No action required. water outlet hose be- Water outlet hose is not connected correctly. ing connected. -
Page 41: Product Number (E-Nr.), Pro- Duction Number (Fd) And Consecutive Numbering
Consumption values en least 10 years from the date on service contacts and warranty condi- which your appliance was placed on tions or on our website. the market within the European Eco- 20.1 Product number (E-Nr.), nomic Area. production number (FD) Note: Under the terms of the manu- and consecutive number- facturer's warranty the use of Cus- ing (Z-Nr.) - Page 42 en Consumption values Programme Final Load Spin Initial Pro- Energy mois- (kg) speed mois- gramm con- ture (rpm) ture e dura- sump- level level tion tion (h:min) (kWh/ cycle) Cottons + Cup- -3.0 1400 4:42 1.47 board Dry Plus Cottons + Cup- -3.0 1400 3:35...
-
Page 43: Technical Data
Technical data en Programme Final Load Spin Initial Pro- Energy mois- (kg) speed mois- gramm con- ture (rpm) ture e dura- sump- level level tion tion (h:min) (kWh/ cycle) Cottons + Iron Dry 12.0 1400 1:44 0.49 Cottons + Iron Dry 12.0 1000 3:12... -
Page 44: Information Regarding Free
en Technical data Please send your request to oss- Maximum: request@bshg.com or BSH Hausger- 35 °C äte GmbH, Carl-Wery-Str.34, 81739 Length of the 145 cm Munich, Germany. power cord Subject: „OSSREQUEST“ This product contains light sources The cost of performing your request from energy efficiency class F. These will be charged to you. -
Page 45: Statement Of Compliance For Great Britain
BSH Hausgeräte GmbH hereby declares that the appliance with Home Connect functionality conforms to the essential requirements and other relevant provi- sions of Directive 2014/53/EU. A detailed RED Declaration of Conformity can be found online at www.bosch- home.com among the additional documents on the product page for your ap- pliance. - Page 46 en Declaration of Conformity Name and address of manufacturer BSH Hausgeräte GmbH, Carl-Wery- Strasse 34, 81739 München, Ger- many This statement of compliance is pre- pared by the manufacturer. The manufacturer, BSH Hausgeräte GmbH deems that it has complied with provision 5.1-1 of ETSI EN 303 645 v2.1.1 and, where relevant, provision 5.1-2 of ETSI EN 303 645 v2.1.1;...
- Page 48 You'll find it here. Expert advice for your Bosch home appliances, help with problems or a repair from Bosch experts. Find out everything about the many ways Bosch can support you: www.bosch-home.com/service Contact data of all countries are listed in the attached service directory.
