- Page 1 INSTRUCTION MANUAL #88-83021 4K Action Camera with WiFi Record & Share The Action! WARNING: WARNING: CHOKING HAZARD — Small parts. Cancer and Reproductive Harm - www.P65Warnings.ca.gov. Not for children under 3 years. 2021 US/AUS...
- Page 2 WELCOME 2021...
- Page 3 This product is a high-definition digital motion video recording device tailored to market demand. It has a variety of industry-leading features including video recording, photo shooting, audio recording, video display and rechargeable battery, which makes it perfect for vehicle data recording, photo-shooting, outdoor sports, deep-water probing. 2021...
- Page 4 About this Instruction Manual Please read the safety instructions and the operating instructions carefully before use. Keep these instructions for renewed use at a later date. When the device is sold or given to someone else, the instruction manual must be provided to the new owner/user of the product. Read these safety instructions before using your device and store them for possible future reference.
- Page 5 16) In case of overheating, smoke, or unpleasant smell in the process of charging, unplug your device immediately to prevent a fire. 17) If the charging cord is damaged, have it repaired by the manufacturer, its service or a similarly qualified person in order to avoid any hazard.
- Page 6 General Warnings • Risk of choking! — Keep packaging material, like plastic bags and rubber bands, out of the reach of children, as these materials pose a choking hazard. This product contains small parts that could be swallowed by children. •...
- Page 7 Notes on Cleaning Turn off the camera. Clean the eyepieces and/or lenses only with a soft, lint-free cloth, (e.g. microfibre cloth). To avoid scratching the lenses, use only gentle pressure with the cleaning cloth. Only use a dry cloth to clean the exterior of the device. To avoid damaging the electronics, do not use any cleaning fluid.
- Page 8 FCC ID: 2ASJU88-83021 CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 9 Supplier’s Declaration of Conformity 47 CFR § 2.1077 Compliance Information Unique Identifier Trade Name: Explore One Model No.: 88-83021 Responsible Party – U.S. Contact Information US Company Name: Explore Scientific, LLC. Address: 1010 S. 48th Street, AR, 72762 Telephone number or internet contact information: 866.252.3811 FCC Compliance Statement This device complies with Part 15 of the FCC Rules.
- Page 10 CONTENTS 2021...
- Page 11 4K Camera Waterproof Case Flat Adhesive Mounts Handle Bar/Pole Mount Frame Housing Mount Straps Long Thumb Screw Quick Release Buckle Pivot Mounts Short Thumb Screw USB Cable Tripod Floating Handle MicroFlash Card and Adapter 2021...
- Page 12 INSTRUCTIONS Product Features 1. A waterproof casing that allows you to film fascinating water sports; waterproof up to 30 metres under water 2. 2 in (50.8mm) screen that displays and replays fascinating videos recorded. 3. Support storage cards up to 64GB maximum. 4.
- Page 13 Microphone Up/WiFi MicroFlash Slot Button Down Micro Button USB Port Operating 1. Inserting MicroFlash card Note: For best performance, please choose a branded MicroFlash card and format it on your computer before use. No-name cards are not guaranteed to work flawlessly. Insert a MicroFlash card with the label facing the screen.
- Page 14 INSTRUCTIONS 2. Charging A. Connected to a computer or power adapter via USB cable for charging. B. Charging of the action camera can be done even when it’s powered off. C. When it is charging, the red indicator light will glow, and when charging is complete, it will turn off.
- Page 15 5. How to record videos and configure recording setting 5.1. Video Recording Turn the camera on. You will start with the video recording mode. Insert a MicroFlash card and start recording by pressing “OK”. Press “OK” again if you want to stop the recording. 5.2.
- Page 16 INSTRUCTIONS 6. Connecting to WiFi To connect the camera to an Android or Apple iOS smart device follow these steps: 1. Download the XDV app from the application store on your smart device and install it. 2. Turn on the camera and press the WiFi button on the side of the device. The WiFi logo will appear on the screen.
- Page 17 Status Light WiFi Button WiFi signal not stable? WiFi signal susceptible to interference, make sure the phone is not held too far away from the camera to prevent loss of signal. Unable to connect to WiFi? First, make sure your smart device’s WiFi is turned on. Press the power button on the camera and press the WiFi button on the side of the device.
- Page 18 INSTRUCTIONS How to Open and Close the Waterproof Case How to Open: Press and hold down the switch (1) and then use the arrow (2) to open the clamp (3). 2021...
- Page 19 How to Close: Press the case door all the way down (1) and then snap the clamp to the hinge (2). Now, simply press the clamp down (3) to close. 2021...
- Page 20 INSTRUCTIONS Base Adhesive Mounting Base Mount Example 4K Camera Waterproof Quick Flat Case Release Adhesive Buckle Mount 4K Camera Frame Pivot Quick Flat Housing Mount Mount Release Adhesive Buckle Mount 2021...
- Page 21 Helmet Mounting Helmet Mount Example 4K Camera Waterproof Quick Flat Straps Case Release Adhesive Buckle Mount 4K Camera Frame Quick Flat Straps Housing Mount Release Adhesive Buckle Mount 2021...
- Page 22 INSTRUCTIONS Pole Mounting Pole/Bicycle Mount Example 4K Camera Waterproof Pivot Handle Bar/ Case Mount Pole Mount 4K Camera Frame Pivot Handle Bar/ Housing Mount Mounts Pole Mount 2021...
- Page 23 Tripod Example Frame Tripod Mounting Housing Mount Tripod Mounting 4K Camera Tripod Waterproof Quick Flat Case Release Buckle Adhesive Mount Floating Handle Example 4K Camera Waterproof Floating Handle Case 2021...
- Page 24 INSTRUCTIONS Technical Data Display 2.0 (50.8 mm) inch display Lens 140° wide angle Waterproof case Up to 30 m (100 ft) Language options English/Traditional Chinese/Simplified Chinese/Russian/Portuguese/Spanish/ Japanese/German/French/Polish/ Italian Resolution of photos 20 M(by interpolation) 16 M(by interpolation) 12 M(by interpolation) Resolution of videos 4K @ 30FPS (by interpolation) 2.7K @ 30FPS (by interpolation)
- Page 25 Video format Video compression format H.264 Storage Micro Flash card up to 64 GB Shooting mode Self-timer (3s/5s/10s/20s) Auto(3s/10s/15s/20s/30s) Burst Photo(3P/S, 5P/S, 10P/S) Frequency of optical source 50Hz/60Hz USB interface USB 2.0 Rated voltage DC 5 V Battery capacity Li-ion 3.7V 750 mAh Recording time About 90 minutes (at 4K)
- Page 26 2021...
- Page 27 2021...
- Page 28 ITM./ART. 1537751 USA / AUS #88-83021 ©2021 Explore Scientific, LLC. 1010 S 48th Street, Springdale, AR 72762 All rights reserved. explorescientificusa.com | 866.252.3811 Made in China. V052021HIPO 2021...
