Philips BDP2700 Service Manual
Philips BDP2700 Service Manual

Philips BDP2700 Service Manual

Blu-ray disc player
Hide thumbs Also See for BDP2700:

Advertisement

Quick Links

Blu-ray Disc Player
©
Copyright 2010 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without
the prior permission of Philips.
Published by HT- SL WK1031 BG AVM Printed in The Netherlands Subject to modification
Version 0.0
Version 1.1
TABLE OF CONTENTS
Location of PCB Boards ..................................................1-1
Technical Specifi cations ....................................................... 1-2
Safety Instruction, Warning & Notes ..................................... 1-3
Mechanical and Dismantling Instructions ................................2
Software Version & Upgrades, Region Code Change .............3
Trouble Shooting Chart ...........................................................4
Set Wiring Diagram .................................................................5
Electrical Diagrams and PCB layouts ......................................6
Set Mechanical Exploded view & Parts List ............................7
Revision List ............................................................................8
BDP2700
/12/05/51/79/93/98
Page
CLASS 1
LASER PRODUCT
314178535531
©

Advertisement

loading
Need help?

Need help?

Do you have a question about the BDP2700 and is the answer not in the manual?

Questions and answers

Summary of Contents for Philips BDP2700

  • Page 1 LASER PRODUCT © Copyright 2010 Philips Consumer Electronics B.V. Eindhoven, The Netherlands All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.
  • Page 2 LOCATION OF PCBS BD LOADER AV JACK BOARD MAIN BOARD POWER BOARD FRONT CABINET ASS’Y VERSION VARIATIONS Type /Versions: BDP2700 Service policy Board in used: MAIN BOARD POWER BOARD AV BOARD FRONT CABINET ASS’Y BD LOADER * TIPS : C -- Component Lever Repair.
  • Page 3 • Specifications are indicative (subject to change). Technical Specifications For on-line product support please use the following website: http://www.p4c.philips.com/cgi-bin/dcbint/cpproduct_selector.pl Here is product information available, as well as getting started, user manuals, frequently asked questions and software & drivers. Directions for Use You can download this information from the following websites: http://www.philips.com/support...
  • Page 4 Make sure that, • Use only lead-free soldering tin Philips SAC305 with order during repair, you are connected with the same potential as code 0622 149 00106. If lead-free solder paste is required, the mass of the set by a wristband with resistance.
  • Page 5 1 - 4 Safety Instructions, Warnings, Notes, and Abbreviation List 2.3.5 Alternative BOM identification Abbreviation List It should be noted that on the European Service website, 0/6/12 SCART switch control signal on A/V “Alternative BOM” is referred to as “Design variant”. board.
  • Page 6 Electro Magnetic Interference LORE LOcal REgression approximation EPLD Erasable Programmable Logic Device noise reduction Europe LG.Philips LCD (supplier) EXTernal (source), entering the set by Loudspeaker SCART or by cinches (jacks) LVDS Low Voltage Differential Signalling Fast BLanking: DC signal Mbps...
  • Page 7 4.406250 MHz and 4.250000 MHz Sound Intermediate Frequency SMPS Switched Mode Power Supply System on Chip Sync On Green SOPS Self Oscillating Power Supply S/PDIF Sony Philips Digital InterFace SRAM Static RAM Service Reference Protocol Small Signal Board STBY STand-BY SVGA 800x600 (4:3)
  • Page 8 Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. The following guidelines show how to dismantle the player. Step1: Remove 6 screws around the Top Cover, and then remove the Top Cover (Figure 1). Figure 1 Step2: If it is necessary to dismantle Loader or Front Panel, the Front door should be removed first.
  • Page 9 Mechanical and Dismantling Instructions Detailed information please refer to the model set. Dismantling Instruction Step3: If the tray can’t open in normal way, you can make it through the instruction as below (Figure 3). Note: Make sure to operate gently otherwise the guider would be damaged. Figure 3 Step4: Dismantling Front Panel, disconnect the connectors (J501, USB400), need release 2 snaps of Front Panel and 2 snaps of bottom cabinet , then gently pull the Panel out from the set.
  • Page 10 Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. Step5: Dismantling Loader, disconnect the 3 connectors (HA800, HA901, HA900) aiming in the below figure, and remove 4 screws that connects the loader and the bottom cabinet. (Figure 4-5) Figure 5 Step6: Dismantling Main Board , first disconnect the connector (J1), and then remove 3 screws.
  • Page 11 Trouble shooting chart No display on LED, and buttons do not work No display on LED, and buttons do not work Check every supply voltage on main board is Refer to Power supply board part normal Check the front board Check the front board U135’s pin signals VCLK,VD, VSTB (JP2:pin5,6,7)
  • Page 12 Trouble shooting chart No audio output No audio output Check if XP2 conect Fix XP2 in AV board ok or not from the AV board to mainboard Check whether the audio signal Check the U8 power supply is right from the U8’9,10,11,12 Replace the U915 Check whether the audio signal is right from the...
  • Page 13 Trouble shooting chart Remote control does not work Remote control does not work Check whether the remote Replace the battery for remote controller’s battery controller exhausted or not. Check the REM302 power Check the VCC net no front board supply OK,REM302 PIN3 is about 5V Replace REM302...
  • Page 14 Trouble shooting chart Can’t read disc or can’t open the disk door Can’t read disc or can’t open the disk door Check whether Check the connection o 4pin cable from the DVD loader running is main board normal Check 45pin 9pin cable from main board Fix the connection the 45pin cable or...
  • Page 15 No video display No Video display Check if XP2 fix ok or not from AV board to Fix XP2 in AV board mainboard Check R948 is on in Fix R948 main board Check if L452 is on Add L452 Check If R616 is on Add R616 Replace the main board...
  • Page 16 Trouble shooting chart Can not connect to network Can not connect to network Check LFE8634(U553) is on Fix U553 in mainboard In mainboard Check R557,R558,R559,R560,R Fix all the resistor 561 is on in main board Check if the P400 is ok Change P400 Or not...
  • Page 17 COAX L.R,CVBS BDP2700 WIRING DIAGRAM AV BOARD RJ45 HDMI AV 220 LFE8634 Signal manage(45PIN) EXTERNAL DAC 45PIN CVBS/COAX OPU SONY 460 NAND FLASH 2Gbit MTK8550 DBAG LOADER ASA L9332E+SONY 460 R2A30209SP(MOTOR MAIN BOARD DDR3 1Gbit/1333 DRIVE) TPC1391G4(MOTOR DRIVE) TRAVERSE 9PIN DDR3 1Gbit/1333 DC-DC/1.5V/1.1V/3.3V/1.2V...
  • Page 18 +5VSTANBY R334 R334 R335 R335 R336 R336 4.7K 4.7K 4.7K 4.7K 4.7K 4.7K R328 R328 TO Main Board U135 U135 LED2 LED2 ET6202 ET6202 GRID[1:7] GRID1 GRID1 9PIN/2.0mm/140mm 9PIN/2.0mm/140mm GRID1 GRID2 R337 R337 DI/O GRID1 GRID2 VCLK R338 R338 GRID2 GRID3 GRID2 GRID3...
  • Page 19 CY504 CY504 1000P/250Vac 1000P/250Vac C501 C501 C505 C505 102/100V 102/100V R511A R511A R511B R511B R511C R511C R511D R511D 222/1KV 222/1KV R503 R503 D505 D505 D507 D507 +12V R512 R512 RL207 RL207 RL207 RL207 R545 R545 CE501 CE501 150K 150K 150K 150K 150K 150K...
  • Page 20 SPDIF ASPDIF 180/1% 180/1% C613 C613 R609 R609 0.1uF/25V 0.1uF/25V LOUT1 R610 R610 500R 500R ROUT1 C615 C615 100/1% 100/1% 330pF/50V/X7R 330pF/50V/X7R CVBSO R608 R608 RCA-1 RCA-1 7PIN/2.0mm 7PIN/2.0mm ASPDIF FE_GND FE_GND FE_GND SPDIF OUTOUT VIDEO BUFFER IMPEDANCE J601 J601 R616 0R R616 0R ROUT1...
  • Page 21 1.1V POWER VCC1 VCC1 12V_P behind of Caps R930 R930 1.1V RESET# RESET# (7) 0.1uF/25V 0.1uF/25V 12V_P 12V_P FB706 FB706 FB10/2A FB10/2A Close to DC-DC FB707 FB707 FB10/2A FB10/2A R926 R926 0.1uF/25V 0.1uF/25V 10uF/10V 10uF/10V C925 C925 R922 R922 4.7uF/16V 4.7uF/16V 22uF/10V 22uF/10V...
  • Page 22 IC 1.5V POWER C U100A U100A U104 U104 1.5V A_DQ0 A_RA0 MAIN POWER 1.5V A_DQ7 A_RA1 A_DQ1 A_RA2 C142 C142 C118 C118 A_DQ6 A_RA3 CE100 CE100 0.1uF/25V 0.1uF/25V 0.1uF/25V 0.1uF/25V AB20 A_DQ3 A_RA4 220uF/16V 220uF/16V DVCC18_IO_1 A_DQ5 A_RA5 AB21 DVCC18_IO_1 A_DQ0 A_DQ2 A_RA6...
  • Page 23 IC 1.1V POWER C U100B U100B 1.1V U203 U203 MAIN POWER B_DQ0 B_RA0 1.1V B_DQ6 B_RA1 B_DQ3 B_RA2 C207 C207 C206 C206 CE205 CE205 B_DQ5 B_RA3 470uF/16V 470uF/16V 0.01uF/25V 0.01uF/25V 0.1uF/25V 0.1uF/25V DVCC10_K B_DQ1 B_RA4 DVCC10_K B_DQ0 B_DQ4 B_RA5 DVCC10_K RDQ0_B B_DQ1 B_DQ2...
  • Page 24 AUDIO I2S AOSDATA3 AOSDATA3 AOSDATA2 AOSDATA2 AOSDATA1 HDMI AOSDATA1 AOSDATA0 IC VIDEO MODULE POWER C AOSDATA0 U100C U100C POWER AOLRCK AOLRCK 3.3V AOBCK AOBCK 1.2V AOMCLK AOMCLK R343 R343 AVDD33_VDACY AVDD12_HDMI R350 R350 AOMCLK_R AOMCLK_R C303 C303 C304 C304 AOBCK_R AOBCK_R 0.1uF/25V 0.1uF/25V...
  • Page 25 HW TRAPPING NFWEN NAND NFWEN U100E U100E 3.3V NFREN NFREN 3.3V NFCEN FLASH NFCEN 3.3V NFCEN2 DVCC33_IO_6 NFCEN2 DVCC33_IO VDD3.3_USB R449 R449 AMUTE DVCC33_IO AVDD33_USB_1P AMUTE (5,7) U400 U400 NFCLE DVCC33_IO_2 AVDD33_USB_2P NFCLE DVCC33_IO_3 C401 C401 C402 C402 NFALE NFALE DVCC33_IO_3 0.01uF/25V 0.01uF/25V...
  • Page 26 HW Trapping Pin U100D U100D 3.3V 3.3V_STBY GPIO8 R522 R522 RESET# Default value as below: GPIO8 RESET# GPIO8 (else system will enter test mode) R509 R509 VCC3IO_STB LCDRD FAST_EJECT DVCC33_IO_STB ETCOL TP513 TP513 FAST_EJECT (10) --------------------------------------------------------------------- ETTXEN DVCC33_IO_STB ETCRS TP515 TP515 TP514 TP514...
  • Page 27 ASPDIF ASPDIF ASPDIF VCC3 VCC3 R958 R958 NC/0R NC/0R LOUT1 GND5 GND5 ROUT1 R948 R948 CVBS R950 R950 LOUT1 LOUT1 R949 R949 R959 R959 ROUT1 ROUT1 R951 R951 0R/NC 0R/NC ASPDIF ASPDIF 10PIN/2.0mm 10PIN/2.0mm Tuesday, June 01, 2010 HN R&D Size:...
  • Page 28 AUDIO CNT 12V_P DA_VDD REFA R175 R175 5.6K/1% 5.6K/1% AMUTE AMUTE (5,7) DAC_RST# C121 C121 R138 R138 DAC_RST# DAC_CS# 680pF/50V/NP0 680pF/50V/NP0 DAC_CS# CLOSED TO AKM4385 -12VA C939 C939 C130 C130 R179 R179 5.6K/1% 5.6K/1% 10uF 10uF HA700 HA700 0.1uF/25V 0.1uF/25V C152 C152 R176...
  • Page 29 MOTOR DRIVER GAINSW2 GAINSW2 (11) MUTE2 MUTE2 (11) 3.3V MUTE1 RS232 MUTE1 (11) SONY 460 TRAYPWM TRAYPWM (11) URXD DMSO GIO9 DMSO (11) GIO9 UTXD FOSO FOSO (11) HA800 HA800 TRSO TRSO (11) TLSO TLSO (11) FOC1- U100F U100F CON801 CON801 A1.2V FOC1+...
  • Page 30 1.COLLIMATOR DRIVER TI1391 2.GIO9 FB902/FB901 MOTOR DRIVER MOTOR MOTOR GAINSW2 GAINSW2 (10) MUTE2 MUTE2 (10) MUTE1 POWER U900 U900 DRIVER MUTE1 (10) DMSO V14REF MVCC SPIN FMSO2 TRAYPWM TRAYPWM SL1IN LOIN TRAYPWM (10) DMSO FMSO FOSO Sensorless DMSO (10) SL2IN FOIN C916 C916...
