- Page 1 DOUBLE SIDE BURNER/GRIDDLE GDSBE1-30 & BFGC-30 Models Insulated jacket BGB30-IJS INSTALLATION GUIDE US CA 592076B 06.25...
-
Page 2: Safety And Warnings
SAFETY AND WARNINGS To reduce the risk of fire, electrical shock, injury to persons, or damage when using the appliance, follow the important safety instructions listed below: WARNING! Hot Surface Hazard Failure to follow this advice may result in burns and scalds or serious injury. •... - Page 3 SAFETY AND WARNINGS WARNING! WARNING! Hot Surface Hazard Cut Hazard Failure to follow this advice may result in Failure to use caution could result in injury. burns and scalds or serious injury. • Take care: some edges are sharp. • Use only dry pot-holders; moist or damp pot- holders on hot surfaces may cause burns from WARNING steam.
- Page 4 SAFETY AND WARNINGS To reduce the risk of fire, injury to persons or damage when using the appliance, follow WARNING! the important safety instructions listed below. Read all the guidance before using the appliance. Do not use an outdoor cooking gas appliance for purposes other than Fire Hazard intended.
- Page 5 SAFETY AND WARNINGS Fire Gas Requirements Have an ABC rated fire extinguisher accessible – never attempt to extinguish a grease Do not change the regulator/hose assembly from that supplied with the unit or attempt fire with water or other liquids. to use a Type 1 equipped regulator/hose assembly with a standard 510 POL cylinder/ Never leave the product unattended when in use.
- Page 6 SAFETY AND WARNINGS INSTALLATION REQUIREMENTS FOR NATURAL GAS LP Cylinder Hazards Natural gas Installation and connection Installation must conform with local codes or with the National Fuel Gas Code ANSI Check with your local gas utility company or local codes for instructions on installing Z223.1 or the CSA-B149.2 Propane Installation Code.
-
Page 7: Product Dimensions
PRODUCT DIMENSIONS FRONT PROFILE GDSBE1-30 & BFGC-30 MODELS PRODUCT DIMENSIONS INCHES A Overall height (excluding burners and pan supports) 10 1/2 B Overall width C Overall depth (excluding dials) 26 7/8 D Depth of chassis 22 5/8 E Width of chassis (including support brackets) 27 13/16 F Height below countertop 9 15/16... -
Page 8: Cutout Dimensions
The enclosure should have ventilation holes to prevent gas build-up in the event of a leak. Refer to ANSI Z21.58 • Use only the DCS insulated jacket which has specifically been designed and tested for this purpose. Standard for Outdoor Cooking Gas Appliances, Section 1.7 Enclosures For Self Contained LP-Gas Supply Systems. - Page 9 CLEARANCES Clearances to non-combustible construction Material which is not capable of being ignited and burned, such as materials consisting entirely of, or a combination of, steel, iron, brick tile, concrete, slate, and plaster. The side burner/griddle is designed for easy placement into built- in masonry enclosures.
- Page 10 If the side burner/griddle is to be placed into a combustible enclosure, an approved insulated jacket is necessary. Insulated jackets are available from your dealer. Use only the DCS insulated jacket which has specifically been designed and tested for this purpose.
-
Page 11: Electrical Connection
If all dials are turned , all halos will dim. Multiple DCS Series 9 products may be linked together to allow for cross-product halo illumination. To allow for this functionality, an approved DCS kit is required and can be purchased separately TO OUTLET from your local DCS dealer. -
Page 12: Gas Requirements
GAS CONNECTION GAS REQUIREMENTS NATURAL GAS CONNECTION Verify the type of gas supply to be used, either natural or LP, and make sure the marking Connection: 1/2” NPT male with 3/8” flare adapter Operating pressure: 4.0” W.C. on the appliance rating plate agrees with that of the supply. The rating plate is located on Supply pressure: 5”... - Page 13 GAS CONNECTION CART LP CONNECTION BUILT-IN LP CONNECTION If the double side burner/griddle is to be installed in a built-in application, then the side Units set for use with LP gas come equipped with a high capacity hose/regulator assembly burner/griddle must be installed in accordance with the built–in installation guidelines and for connection to a standard 20 lb.
-
Page 14: Leak Testing
LEAK TESTING A complete gas tightness check must be performed at the installation site. Periodically check Testing for leaks the whole system for leaks, or immediately if the smell of gas is present. Removing the valve panel Prepare soap solution by combining one part liquid detergent and one part water. -
Page 15: Low Flame Adjustment
CHANGING THE GAS CYLINDER LOW FLAME ADJUSTMENT Inspect the gas connection hose every time you change the gas cylinder. Replace hose if there The valves on the double side burner/griddle unit feature an adjustable low setting. Due to are any signs of damage. fluctuations in gas pressure, or heating value you may feel it necessary to increase or decrease gas flow in the low position. - Page 16 Securing side burner/griddle to cart or mounted on a freestanding cart. If the unit is to be placed onto a freestanding cart, an approved DCS cart is required and can be purchased separately from your local DCS dealer. CAD1-30E freestanding cart part number: 71525...
-
Page 17: Installer Checklist
INSTALLER CHECKLIST IMPORTANT! Read all installation instructions in this manual to see if the unit has been correctly installed. Ensure that installation has been completed correctly before use. Ensure that: specified clearances are maintained to combustibles flame has been adjusted proper enclosure ventilation has been verified each burner lights satisfactorily - individually or with adjacent burner lit all internal packaging and any adhesive residue is removed... - Page 18 Under our policy of continuous product improvement, these specifications may change at any time. For current details about model and specification availability in your country, please go to our website or contact your local DCS dealer. 592076B 06.25...
