Hawking HOW2R1 Datasheet

Hi-Gain Outdoor
™
Dual Radio Smart Repeater
Unleash your Wireless Network with the Hawking Hi-Gain
Radio Smart Repeater, HOW2R1. The HOW2R1 outdoor smart repeater connects and repeats your
existing wireless network with up to 64X the power output and 8X the distance of a standard Wireless-G
device. Similar to the Hawking's HW2R1 Smart Repeater with dual radio design, the HOW2R1 Outdoor
Smart Repeater is engineered with two powerful Wi-Fi radios, one radio is dedicated to receiving signals
from a wireless source, access point or router, and the other radio is used to rebroadcasting wireless
signals throughout your surroundings. To further enhance its wireless range and coverage, the WiFi
receiving radio is connected to an 11dBi directional antenna, integrated internally in the HOW2R1. In
addition, two external 5dBi antennas are connected to the rebroadcasting WiFi radio to effectively
elimnates wireless deadspots inside and outside of your home or office.
This powerful repeater is not only robustly design to withstand outdoor environment, it also packed with wireless security features,
such as MAC access control, IEEE 802.11x authentication, WPA, WPA2, hidden ESSID, and the basic WEP encryption. With data
transfer rate of up to 300Mbps, the HOW2R1 is an ideal solution for High Performance Wireless Solution, extending your wireless
signals for your home or your business, or providing wireless access to RV parks or Marine docks. The possibilities are endless.
Features
 Connects and repeats any 2.4GHz 802.11b/g/n Wireless Network
• Eliminate Wireless Dead Spots inside and outside your Home or Office with high power output of up to 200mW
 Increase your wireless distance of up to 8X and power output of up to 64X compared to a standard wireless 802.11g network*
 Engineered with two WiFi radios - one receiving radio and one rebroadcasting radio
 Built-in 11dBi Directional Antenna is dedicated to receiving wireless signals
 Two 5dBi external Omni-Directional Antennas are dedicated to rebroadcasting wireless signals
• Easy Setup: Install and Configure in less than 1 Minute
• Heavy duty, waterproof design
System Requirements:
• One computer (Mac or PC) with an available CD or DVD-Rom drive
• Internet Web Browser (Internet Explorer, Safari, etc.)
• A Wired or Wireless networking adapter (i.e. Airport card, built-in Ethernet adapter, etc.)
• A Wireless Internet connection (such as a HotSpot, etc.)
* Actual distance and data output power may vary depending on your networking environment.
W W i i rel re l e e ss-300 ss -300N N
PACKAGE CONTENTS:
 One Hi-Gain
™ Outdoor Wireless-N Dual Radio Smart Repeater
 Two 5dBi Hi-Gain Outdoor Omni-Directional Antennas
 One Power over Ethernet DC Injector
 L-shape Antennas Connector
 One Waterproof Gasket Kit for RJ-45
 Power Cable and Power Transformer
 Ethernet Cable
 Wall & Pole Mounting Kit
 Setup CD-Rom
Outdoor 2.4GHz Wireless-300N Dual
™
Dual Radio Wireless Repeater
HOW2R1
MODEL:
