  • Page 1 Wired Remote Control Instructions UI DUCT 9-12-18 and warnings...
  • Page 2 Thank you for purchasing this product. Before using the unit, carefully read this manual and keep it for future reference. - This manual provides a detailed description of the precautions that you must pay attention to during use. ST.007776/003 UI DUCT 9-12-18...
  • Page 3 6. Installation method..............................12 7. Remote control specifications..........................14 8. Safety precautions..............................15 9. Wired remote control pushbutton panel......................16 10. Remote control lcd display........................... 18 11. Basic functions............................... 19 ST.007776/003 UI DUCT 9-12-18...
  • Page 4 To dispose of the device, refer to waste electrical and electronic equipment collection centres or contact the dealer that you purchased it from. Discharged batteries must be taken out of the remote controls and disposed of separately in compliance with local regulations. ST.007776/003 UI DUCT 9-12-18...
  • Page 5 If installed on top of it First recessed in the wall, must be shorter Corrugated connection pipe than 15 m. Phillips screwdriver To be used with Philips screws Small flat-headed screwdriver To be used to remove the top cover ST.007776/003 UI DUCT 9-12-18...
  • Page 6 3. The shielded extension cable of the wired remote control must be connected to a reliable earth contact by means of the terminal lug. 4. Do not try to make the extension cable longer by cutting and/or splicing it. . REMOTE CONTROL DIMENSIONS. ST.007776/003 UI DUCT 9-12-18...
  • Page 7 Giunto a lo, 5p Wire coupling, 5 poles Infrared Receiver Tubo a infrarossi Cavo schermato a 5-pole shielded ESEGUIRE 5 conduttori cable Indoor unit main board Scheda principale dell'unità interna Indoor unit Unità interna Fig. 2 ST.007776/003 UI DUCT 9-12-18...
  • Page 8 • The earthing terminal lug (located at the end of the extension cable, indoor unit side) must be appropriately earthed. • Connect the ferrite supplied in the DUCT indoor unit between the display panel and the connection with the extension cord, wrapping it twice around the connection cable. ST.007776/003 UI DUCT 9-12-18...
  • Page 9 Mastice Sealant Mastice Bend Sifone the cable Bend the Sifone cable Fig. 4 WARNING: • To prevent water from penetrating into the wall-mounted wired remote control, use a sealant to seal the cable connectors during installation. ST.007776/003 UI DUCT 9-12-18...
  • Page 10 Lower side cable outlet Uscita cavo del lato inferiore Fig. 1 Drill a hole for the Praticare un foro wire outlet per l'uscita del lo Fig.5 Cablaggio della scatola di Cablaggio attraverso il muro commutazione incorporato ST.007776/003 UI DUCT 9-12-18...
  • Page 11 Cablaggio attraverso il muro commutazione incorporato Foro di cablaggio Foro a muro e foro di cablaggio Cable passage hole Wall hole diameter: Ø2 cm Diametro del foro a muro: Φ2 cm Fig. 6 Remove precut zone ST.007776/003 UI DUCT 9-12-18...
  • Page 12 Bottom cover Flat-headed screwdriver Cacciavite a testa dritta Fig. 8 NOTE: The PCB is installed in the upper part of the remote control. Be careful not to damage the board when opening with a screwdriver. ST.007776/003 UI DUCT 9-12-18...
  • Page 13 Screw 4x25 (for fixing to the wall) Screws M4x25 (for electrical box) Fig. 10 NOTE: Install the wired remote control on a flat surface. Pay attention not to deform the back cover or to over-tighten the screws. ST.007776/003 UI DUCT 9-12-18...
  • Page 14 3. Reconnect the upper panel of the remote control. Fig.11 NOTE: Be careful not to pinch/cut the wires below when closing the panel. . REMOTE CONTROL SPECIFICATIONS. Model KJR-120L/F-E Rated Voltage Operating temperature 0°C ~ 43°C ST.007776/003 UI DUCT 9-12-18...
  • Page 15 Otherwise, electric shocks could occur. • Use the cables supplied in the box to connect the wired remote control. Oth- erwise, electric leakage or overheating could occur and cause a fire. ST.007776/003 UI DUCT 9-12-18...
  • Page 16 . WIRED REMOTE CONTROL PUSHBUTTON PANEL. ST.007776/003 UI DUCT 9-12-18...
  • Page 17 Medium High WARNING: • DO NOT remove the cover or touch the internal parts of the remote control. • DO NOT press the remote control buttons with pointed objects. ST.007776/003 UI DUCT 9-12-18...
  • Page 18 Rotazione SU e GIÙ certain models) elettrico (su alcuni modelli) (on certain models) certain models) (freschezza) (su alcuni modelli) (su alcuni modelli) Swing right and left Rotazione a destra e a sinistra (on certain models) (su alcuni modelli) ST.007776/003 UI DUCT 9-12-18...
  • Page 19 1. Press the MODE button to select AUTO mode. 2. Press the UP ( ) in DOWN ( ) buttons to set the desired temperature. NOTE: In AUTO mode, fan speed is set automatically and cannot be changed. ST.007776/003 UI DUCT 9-12-18...
  • Page 20 2. Press the UP ( ) in DOWN ( ) buttons to set the desired temperature. 3. Press the FAN SPEED button to select the speed of the fan. NOTE: The temperature cannot be adjusted in FAN mode. ST.007776/003 UI DUCT 9-12-18...
  • Page 21 DRY function. 1. Press the MODE button to select DRY mode. 2. Press the UP ( ) in DOWN ( ) buttons to set the desired temperature. NOTE: FAN SPEED cannot be used in DRY mode. ST.007776/003 UI DUCT 9-12-18...
  • Page 22 1. Press the FUNC. key, scroll the functions and select the flashing icon and then confirm. 5. To disable it, press the FUNC. key, scroll the functions and select the flashing icon and then confirm. Pulsante FUNC. FUNC. (FUNZIONE) (FUNCTION) button ST.007776/003 UI DUCT 9-12-18...
  • Page 23 SLEEP function ( The SLEEP function is used to reduce energy consumption while sleeping (and the same temperature settings are not required). The SLEEP function is not available in FAN and DRY modes. ST.007776/003 UI DUCT 9-12-18...
  • Page 24 0, or to switch the remote control off and back on. Example: air conditioner switch on setting after 2.5 hours: NOTE: Number 2.5h indicates the amount of time starting from the current hour at which the air conditioner will switch on. ST.007776/003 UI DUCT 9-12-18...
  • Page 25 30 minutes, up to a maximum of 10 hours. Beyond 10 hours, and up to 24 hours, the time is postponed by 60 minutes at every press. (For example, pressing the key 5 times sets the time at 2.5 hours, pressing 10 times at 5 hours). ST.007776/003 UI DUCT 9-12-18...
  • Page 26 For example, if the current timer reads 1PM with the above settings, the unit will switch on in 2.5 hours (3:30PM) and will switch off 3:30PM Current time 2:00PM 3:00PM at 6PM. 2.5 hours after 5 hours after ST.007776/003 UI DUCT 9-12-18...
  • Page 27 ST.007776/003 UI DUCT 9-12-18...
  • Page 28 Immergas S.p.a. 42041 Brescello (RE) - Italy Tel. 0522.689011 immergas.com This instruction booklet is made of ecological paper...
