Splendide Tumble Dryer Use and Care Guide
Operating Instructions
• The START button begins drying a selected program (see Start and Programs).
• The HEAT button selects drying temperature (see Start and Programs).
◦ IN: HIGH heat.
◦ OUT: LOW heat.
• The PROGRAMS knob sets the program: rotate it clockwise, never counter-clockwise, until the indicator is pointing
to the program you want to select (see Start and Programs). The programs knob will advance to the '0' position
after the program ends.
Start and Programs
Choosing program
• Plug dryer into a grounded 3 prong outlet.
• Sort your laundry according to fabric type (see Laundry).
• Open the door and make sure the filter is clean and in place (see Maintenance).
https://knowledge.tiffinmotorhomes.com/Owner_Hub/Byway/Byway_Component_Manuals/2024_Byway_Component_Manual...
Updated: Thu, 17 Jul 2025 04:40:52 GMT
Powered by
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Splendide and is the answer not in the manual?

Questions and answers

Summary of Contents for Tiffin Motorhomes Splendide

  • Page 1 Splendide Tumble Dryer Use and Care Guide Operating Instructions • The START button begins drying a selected program (see Start and Programs). • The HEAT button selects drying temperature (see Start and Programs). ◦ IN: HIGH heat. ◦ OUT: LOW heat.
  • Page 2 • Load the machine and make sure that the items are not in the way of the door seal. Close the door. • Choose the drying program by checking the Programs table (see Programs) as well as the indications for each type of fabric (see Laundry).
  • Page 3 Easy Iron Program Easy Iron is a short 10 minute program (8 minutes of heat followed by a 2 minute Air Fluff period) which fluffs the fibers of clothing that have been left in the same position/location for an extended period of time. The cycle relaxes the fibers and makes them easier to iron and fold.
  • Page 4 What not to tumble dry in your dryer: • • Articles that contain rubber or rubber-like materials or plastic film (pillows, cushions, or PVC rainwear), any other flammable objects or objects that contain flammable substances (towels soiled with hair spray). •...
  • Page 5 Jeans 700 g 1 lb 6 oz 10 Diapers 1000 g 2 lb 3 oz Cotton 300 g 10 oz Shirt Other 200 g 7 oz T-Shirt 125 g 4 oz Household Items Duvet cover Cotton 1500 g 3 lb 5 oz (Double) Other 1000 g...
  • Page 6 Sample Dry Loads Sample Load 1: RV Sheet Set • Wash Cycle: Regular Cotton Heavy Duty • Dry Time: 70-90 minutes (add 15 min. for std. sheets) • 1 Flat Sheet (90”x102” / all 230 thread count) • 1 Fitted Sheet (60”x80”) •...

  • Page 7: Cleaning And Maintenance

    Cleaning & Maintenance When you should switch off the electricity Unplug the dryer when not using it, when cleaning it and during maintenance activities. Clean the filter after each cycle The filter is an important part of your dryer: it accumulates lint and fluff that is formed while drying. Small items could also become trapped in the filter.

  • Page 8: Troubleshooting

    2. Clean the filter and replace it correctly. Ensure the filter is fully located flush into the tumble dryer trim. Check the drum after each cycle Turn the drum manually in order to remove small items (handkerchiefs) that could have been left behind. Cleaning the drum Do not use abrasives, steel wool or stainless steel cleaning agents to clean the drum.
  • Page 9 • The START button has not been pressed (see Start and Programs). Its taking a long time to dry. • The filter has not been cleaned (see Maintenance). • The temperature setting is not ideal for the type of fabric you are drying (see Start and Programs, and see Laundry). •...
