- Page 1 Digital Digital Remote Remote Pressure/Vacuum Pressure/Vacuum Gauge Gauge User Guide User Guide...
- Page 2 To view the highest, lowest, or normal readings: .................. 7 To clear MIN/MAX: ............................8 Changing the Displayed Units of Measure ....................8 Battery Replacement ........................9 Specifications ..........................10 Warranty ............................12 ©2006 Hickok Inc. All rights reserved. Printed in the United States of America.
- Page 3 Safety Information Before using this equipment, carefully read, understand and follow instructions and safety messages on equipment and in this guide. The guide cannot anticipate or provide advice and cautions for all situations encountered by technicians. With this in mind, always follow and refer to the manuals provided by the manufacturer or the vehicle or equipment being tested or used for all information and testing procedures whenever diagnosing, repairing or operating such vehicle or equipment.
- Page 4 Safety Information Fuel vapors are toxic and explosive, which can cause severe injury or death. • Use proper ventilation to avoid breathing fuel vapors. • If the skin is directly exposed, wash the area immediately and change any clothes that have become wet with fuel.
- Page 5 Safety Information Pressure reading of any system should only be performed by properly trained technicians. • To avoid injury or damage, always relieve system pressure prior to connecting or disconnecting the tester. • When connecting the tester to adapters and hose fittings, do not over tighten the connection.
- Page 6 Instructions Turning the Gauge On and OFF Press and release the ON/OFF button to power the unit on or off. DISPLAY • The gauge powers up in the same units of measurement UNITS MODE ON/OFF last selected. • The gauge automatically powers off after 2 minutes if the pressure is less than 0.7 PSI (or equivalent) and is not PSI/inHg/ NORMAL/...
- Page 7 Instructions Setting the Gauge to Zero The gauge must be set to zero for the following situations: Important! • Before you begin using the digital pressure gauge for the first time. Failure to complete this procedure can result in • The gauge does not read zero with no pressure or vacuum applied. inaccurate readings.
- Page 8 Instructions Using the DISPLAY MODE Function In certain applications, it may be necessary to view only the highest or lowest values. Using the DISPLAY MODE function provides a way to select these readings. To view the highest, lowest, or normal readings: While taking a pressure reading, press and release the DISPLAY MODE button to toggle the display between the highest only, lowest only, or normal readings.
- Page 9 Instructions To clear MIN/MAX: The MIN/MAX is automatically cleared (reset) when you turn it off. You can also clear the MIN/MAX by doing the following when the gauge is on: Press and hold the DISPLAY MODE button for three seconds during a MIN/MAX measurement.
- Page 10 Battery Replacement Replace the battery when the low battery symbol appears in the display (except when setting the gauge to zero). Accuracy of the gauge may be affected during low battery conditions, therefore it is important to replace the batteries. The gauge uses two CR2032 3 volt lithium coin cell batteries.
- Page 11 Specifi cations Working Pressure PSI minimum: -14.7 (-29.9 inHg) PSI maximum: See gauge face for maximum pressure rating. Accuracy ±1% of full scale over the full working pressure range Operating Temperature Range Gauge: 32°F to 158°F (0°C to 70°C) LCD Screen: At low temperatures the LCD screen may react slowly to rapidly changing values or segments may be missing.
- Page 12 Specifi cations Cable Length: 12-feet Batteries Type: CR2032, 3 volt lithium coin cell Quantity: Battery Life (typical): 50 hours of continuous use, less if the backlight is used frequently. Compatibility: Gasoline, oil, ethanol (E85 and E100)
- Page 13 Warranty Subject to the conditions that follow and are noted below, this product is warranted to be free from defects in material and workmanship, under proper use and in accordance with the manufacturer’s written recommendation and specifications, for a period designated below on all products: •...
- Page 14 Warranty receipt) and that the manufacturer will make every attempt to return ship the product within one business day from receipt of the returned product, freight prepaid. In addition, all maintenance procedures, as outlined by the product manuals, should be followed for the warranty to be kept in force.
- Page 15 E-mail: support@hickok-inc.com you to return any equipment, be sure to repaircenter@hickok-inc.com include these items: Service address: Hickok Inc. • a written description of the Automotive Group problem; 1716 Carrollton Avenue • the name and telephone number of Dock E your contact person;...
- Page 16 02491-053 02491-053...
