Asko D3120 Quick Start Manual

Quick Start Guide

We know you're excited about owning an ASKO dishwasher and you're anxious to get started, so here's a brief summary of the operation
procedures. The page references in this Guide refer to the Use and Care Guide. To get the most out of your dishwasher's features, we
recommend that you read this guide and the Use and Care Guide before using the dishwasher.
Your ASKO dishwasher has a button-operated control panel, as illustrated below. To select a wash program or option, simply press the
appropriate button. After you have selected the desired wash program and options, press Start/
Program button
Program indicator
Temperature
To select a program, simply press the program button until the indicator light behind the desired program glows. The programs are
described below:
Heavy Wash (160° F or 130° F)
For the heaviest soiled loads, such as pots, pans, casseroles, etc.
Normal Wash (130° F or 140° F)
For normally soiled loads, such as plates, glasses, bowls, and lightly soiled pans.
Quick (85° F or 120° F)
For lightly soiled loads that are washed immediately after use. This program is good for delicate items, such as fine china
and crystal, but you should set the temperature to low and dry the dishes without heat.
Rinse and hold
To rinse dishes that you plan to wash later that day.
To select an option, simply press the appropriate option button. The options are described below.
Temperature
The dishwasher has two temperature options for each wash program, as shown above. When this button is set on the high
temperature, the main wash is heated to the higher temperature for the selected program. If it is set to low, the main wash
is heated to the lower temperature. The indicator light will glow only when the high temperature is selected.
Drying
This option speeds up the drying process by raising the temperature in the final rinse to 160° F to heat the dishes and tank
before the drying cycle begins. The indicator light will glow only when this option is activated.
Once you have selected the wash program and temperature and drying options, press this button to start the dishwasher. (Make sure
the door is securely closed.) The indicator light around the button will glow progressively as the program goes through each cycle. When
the program is complete, the lights will glow all the way around the button.
lights
button
Drying
button
.
Stop
Start/Stop button
Program progression
indicator lights
