- Page 1 Users’ Manual SDI 16-Screen Multiview MVP9116 VAR 2.0...
- Page 2 Precautions To ensure the reliability, use and safety of the equipment, please observe the following when installing, using and maintaining: Before the device is powered on, it is necessary to check to ensure that the chassis is well grounded to prevent electrostatic discharge from the chassis and endanger the equipment and personal safety, and to provide good shielding effect.
- Page 3 Contents 1. Product introduction ......................1 1.1. Product overview ...................... 1 1.2. Main Functions ......................1 1.3. Product Parameters ....................2 1.4. Standard list ......................3 2. Operation and Function Description ................... 3 2.1. Equipment operation ....................3 2.2. Multiview mode description ..................4 2.2.1.
- Page 4 1. Product introduction 1.1. Product overview This is a professional-grade SDI multiview that supports 16-channel SDI signal input and 16-channel SDI output and 1-channel HDMI output. You can use the front panel keyboard to change the display resolution to 1080i50 / 60, 1080p25 / 30 or more. The device is a multi-screen splitter with 16 matrix switching functions.
- Page 5 1.3. Product Parameters Product name SDI 16-Screen Multiview Input signal SDI HD serial digital video signal Bit rate 143Mbps~2.97Gbps Connector BNC complies with IEC169-8 standard Reflection loss >15dB 5MHz~3GHz SDI Input Signal amplitude 800mV±10% impedance 75Ω 100m Belden 1694A HD equilibrium 200m Belden 8281A HD Output signal...
- Page 6 1.4. Standard list Multiview main part AC power cord x1 Control software x1 User Manual x1 2. Operation and Function Description 2.1. Equipment operation Note: please use the following installation sequence. If the installation sequence is not followed correctly, the equipment may not work or work normally。...
- Page 7 2.2. Multiview mode description 1-screen mode 2.2.1. -screen mode 2.2.2. -screen mode 2.2.3.
- Page 8 -screen mode 2.2.4. -screen mode 2.2.5. -screen mode 2.2.6.
- Page 9 -screen mode 2.2.7. -screen mode 2.2.8. -screen mode 2.2.9.
- Page 10 2.3. Key board operating instructions 2.3.1. Channel switching operation The switching operation can be carried out according to the connected input signal and the window number of multiple pictures. In X out y (such as switching the second channel signal to the fifth channel display, in + 2 + out + 5), or one channel can be switched to multi-channel display at the same time, in 2 out 1, 2, 3, 4...
- Page 11 2.3.7. Time code switch Press the SET key to switch the time code display or hide of all channels. 2.3.8. Knob Control the LCD menu of the front panel. 2.4. Description of screen character setting control software Run the EXE file to set whether serial port communication or network port communication can be set in sanning.
- Page 12 Note: the input field supports a maximum of 10 characters. 2.4.3. AUDIO module Click the AUDIO icon to enter the module. Under this module, you can change the audio column status of each window. You can also change the audio source channel. You can select the audio of any one of the 16 input channels as the output audio, or you can select the audio channel of this channel of audio.
- Page 13 the font color and background color in turn.。 2.4.5. CONTROLS module Click the CONTROLS icon to enter the module, which has the following functions: 1) Output resolution, switching output resolution; 2) Frame status, open and close the frame of the screen; 3) Audio column status, open and close the audio column;...
- Page 14 2.5. Menu usage and LCD display instructions 2.5.1. Startup LCD status display After power on, you can see the internal temperature, channel status and time of the chassis on the LCD panel. As shown below 2.5.2. Menu interface Press the knob on the front panel to enter the main menu interface, as shown in the following figure...
- Page 15 2.5.2.1. How to use the knob 1) Rotate clockwise to select downward. 2) Counterclockwise is the up selection. 3) When selected, the font background is blue. 4) Press to confirm. 2.5.2.2. System settings Select the system menu and press the knob to enter the system setting interface, as shown in the following figure System settings include language settings, LCD screen brightness settings, backlight time, reset settings and call scenarios.
- Page 16 your own use. 4) Reset setting: this option returns to the factory setting. After setting, all previous settings will be cleared. 5) Call scenario: two groups of scenarios saved by customs clearance software settings can be called here. 2.5.2.3. Network settings Select the network and press the knob to enter the network setting interface.
- Page 17 shown in the following figure Display settings: 1) Item selection can operate the settings of corresponding functions 2) Under UMD, you can set the opening or closing of the window, font color and background color 3) Setting method: Custom font color and background color: rotate the knob to select the channel and press the knob →...
- Page 18 The audio setting option can select which input signal audio is currently output, or select the audio channel of each window. Setting steps: ① Turn the knob to output audio selection and select the window to output audio. ② Turn the knob to the sound column setting and select the window to be set. ③...
- Page 19 Devicewell for repair, and the freight shall be borne by the user and paid in advance. If the user returns the goods for any reason, all the freight, insurance premium, customs duty and other taxes and other expenses incurred shall be borne by the user.
- Page 20 3. Repair the damage or failure caused by the use of parts not produced or provided by devicewell; 4. Carry out maintenance and repair for products modified or assembled with other products (the time required for maintenance and repair or maintenance difficulty will be increased after product modification or assembly).
