  • Page 1 ThinkEdge SE30 User Guide...
  • Page 2 Seventh Edition (March 2024) © Copyright Lenovo 2021, 2024. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...
  • Page 3 Z hook kit ....Change the display language of UEFI BIOS ..Rear Wi-Fi antenna... . © Copyright Lenovo 2021, 2024...
  • Page 4 Self-help resources ... . . trademarks ....65 Call Lenovo ....ThinkEdge SE30 User Guide...
  • Page 5 • Depending on the version of operating systems and programs, some user interface instructions might not be applicable to your computer. • Documentation content is subject to change without notice. Lenovo makes constant improvements on the documentation of your computer, including this User Guide. To get the latest documentation, go to: https://smartsupport.lenovo.com...
  • Page 6 ThinkEdge SE30 User Guide...
  • Page 7 Power, and then select Shut down. The indicator in the power button shows the system status of your computer. • On: The computer is starting up or working. • Off: The computer is off or in hibernation mode. © Copyright Lenovo 2021, 2024...
  • Page 8 Connect to a local area network (LAN). When the yellow indicator is on, the computer is connected to a LAN. When the green/orange indicator blinks, data is being transmitted. ® You also can use this connector if your computer supports Intel vPro technology. ThinkEdge SE30 User Guide...
  • Page 9 Wireless WAN antenna slot Used to install the wireless WAN antenna cable connector that is available on some models. The wireless WAN antenna is installed on the wireless WAN antenna cable connector. Left Description Description Item Item ® Wi-Fi antenna slot* Wireless WAN antenna slot * for selected models ®...
  • Page 10 Right Description Item Reserved antenna slot* * for selected models Reserved antenna slot Reserved to install the LoRa antenna that is available only on some models. Bottom Description Item ® VESA threaded holes ThinkEdge SE30 User Guide...
  • Page 11 Connect the matched Z hook kit, DIN rail bracket kit, power adapter bracket kit, or VESA mount bracket kit with the screws (M3 x 4 mm x 3 pcs) provided by Lenovo when you install the computer on a wall or other non-flammable mounting surface.
  • Page 12 The integrated graphics card supports the following: • DisplayPort out connector* Video features • HDMI out connector* • USB-C (Thunderbolt 4) connector The integrated audio card supports the following: • Headset connector Audio features • Internal speaker* ThinkEdge SE30 User Guide...
  • Page 13 • Connect to USB-C accessories to help expand your • USB-C (3.2 Gen 2) connector computer functionality. To purchase USB-C accessories, go to https://www.lenovo.com/accessories • USB-C (Thunderbolt 4) connector • Operating environment Note: The operating environment is not applicable for hardware accessories. The operating temperature of various accessories depends on the corresponding accessory temperature specification.
  • Page 14 Using the computer in a lower operating temperature might result in irreparable damage to your computer. Relative humidity: • Operating: 95% (non-condensing) at 40°C (104°F) • Storage: 10%-90% (non-condensing) at 60°C (140°F) ThinkEdge SE30 User Guide...
  • Page 15 Learn the basics of Win10 IoT Enterprise 2021 LTSC and start working with it right away. For more information about Win10 IoT Enterprise 2021 LTSC, see the following: • Use Windows Search. • Microsoft support Web site: © Copyright Lenovo 2021, 2024...
  • Page 16 Turn off the computer and disconnect the power adapter. b. Remove the bottom cover. See “Bottom cover” on page 53. c. Remove the M.2 solid-state drive from the M.2 solid-state drive slot 1, if any. See “M.2 solid-state drives” on page 55. ThinkEdge SE30 User Guide...
  • Page 17 d. Install the nano-SIM card. Pay attention to the orientation of the card and ensure that it is seated correctly. 2. Reinstall all removed parts. 3. Install the wireless WAN antennas. See “Wireless WAN antenna” on page 52. Pay attention to the silk print number of each wireless WAN antenna and ensure that it matches the silk print number of the corresponding wireless WAN antenna slot.
  • Page 18 Use the software development kit (SDK) Lenovo provides a software development kit (SDK) for your computer. You can use the SDK to develop functions based on your needs. For example, you can collect signals and transfer data with sensors and relay modules connected to the serial connectors and DI/DO connectors on the IO expansion box.
  • Page 19 Note: You are responsible for evaluating, selecting, and implementing the locking device and security feature. Lenovo makes no comments, judgments, or warranties about the function, quality, or performance of the locking device and security feature. You can purchase computer locks from Lenovo.
  • Page 20 You should record your passwords and store them in a safe place. If you forget the passwords, contact a Lenovo-authorized service provider to have the passwords removed. Note: If the hard disk password is forgotten, Lenovo cannot remove the password or recover data from the storage drive.
  • Page 21 Use Computrace Agent software embedded in firmware (for selected models) The Computrace Agent software is an IT asset management and computer theft recovery solution. The software detects if changes have been made on the computer, such as hardware, software, or the computer call-in location.
  • Page 22 Use Intel BIOS guard ® The Intel BIOS Guard module cryptographically verifies all BIOS updates. This hardware-based security helps prevent software and malware attacks on the computers BIOS. ThinkEdge SE30 User Guide...
  • Page 23 UEFI BIOS supports three or four display languages: English, French, simplified Chinese, and Russian (for selected models). To change the display language of UEFI BIOS: 1. Select Main ➙ Language and press Enter. 2. Set the display language as desired. © Copyright Lenovo 2021, 2024...
  • Page 24 • If the storage device is an external device other than a disc, connect the storage device to the computer. 2. Restart the computer. When the logo screen is displayed, press F12 or Fn+F12. 3. Select the storage device as desired and press Enter. ThinkEdge SE30 User Guide...
  • Page 25 5. Press F10 or Fn+F10 to save the changes and exit. Enable or disable the ErP LPS compliance mode Lenovo computers meet the eco-design requirements of the ErP regulation. For more information, go to: https://www.lenovo.com/us/en/compliance/eco-declaration You can enable the ErP LPS compliance mode to reduce the consumption of electricity when the computer is off.
  • Page 26 When you install a new program, device driver, or hardware component, you might need to update UEFI BIOS. You can update the BIOS from your operating system or a flash update disc (supported only on selected models). Download and install the latest UEFI BIOS update package from the Lenovo Support Web site: 1. Go to https://pcsupport.lenovo.com 2.
  • Page 27 4. Move the jumper from the standard position to the maintenance position. 5. Reconnect the power cords for the computer and the monitor to electrical outlets. 6. Turn on the computer and the monitor. When the computer beeps, the recovery process begins. 7.
  • Page 28 ThinkEdge SE30 User Guide...
  • Page 29 3. See “Troubleshooting” on page 23 to resolve the problem you are experiencing and recover your operating system. 4. If the problem persists, contact Lenovo. See Chapter 7 “Help and support” on page 61. Troubleshooting Use the troubleshooting information to find solutions to problems that have definite symptoms.
  • Page 30 – Ensure that the Optane memory is not removed. – Ensure that the Optane memory is not damaged. Check the Optane memory using diagnostic tools. The computer beeps multiple times before Ensure that no keys are stuck. the operating system starts up. ThinkEdge SE30 User Guide...
  • Page 31 Audio problems Problem Solution • If you are using powered external speakers that have an On/Off control, ensure that: – The On/Off control is set to the On position. – The speaker power cable is connected to a properly grounded, functional ac electrical outlet.
  • Page 32 4. Right-click each Wi-Fi device, and then click Enable device. • Enable the Wi-Fi feature in Windows Settings. 1. Open the Start menu. 2. Click Settings ➙ Network & Internet ➙ Wi-Fi. 3. Enable the Wi-Fi feature. • Update or reinstall the Wi-Fi driver. ThinkEdge SE30 User Guide...
  • Page 33 Problem Solution • Enable the Bluetooth feature in UEFI BIOS. • Enable all Bluetooth devices. 1. Right-click the Start button to open the Start context menu. 2. Click Device Manager. Type the administrator password or provide confirmation if prompted. 3. Expand Bluetooth to display all Bluetooth devices. Right-click each Bluetooth device, and then click Enable device.
  • Page 34 Uninstall/ Change or Uninstall. • Right-click a blank area on the taskbar and open Task Manager. The free memory space is insufficient. Then, end some tasks you are not performing. • Install additional memory modules. ThinkEdge SE30 User Guide...
  • Page 35 Storage drive problems Problem Solution • Ensure that the signal cables and power cables for all the storage drives are connected correctly. • Ensure that the computer is configured correctly to support the storage drives. Some or all storage drives are missing from –...
  • Page 36 1. Open the Start menu, and then click Settings ➙ Update & security ➙ Recovery. 2. In the Advanced startup section, click Restart now ➙ Troubleshoot ➙ Advanced options. 3. Select a preferred option, and then follow the on-screen instructions. ThinkEdge SE30 User Guide...
  • Page 37 Windows recovery programs are damaged. If you did not create a recovery USB drive as a precautionary measure, you can contact Lenovo Customer Support Center and purchase one from Lenovo. For a list of the Lenovo Support phone numbers for your country or region, go to: https://pcsupport.lenovo.com/supportphonelist Create a recovery USB drive Attention: The creation process deletes anything stored on the USB drive.
  • Page 38 • From Windows Update: Note: The device drivers provided by Windows Update might not be tested by Lenovo. It is recommended that you get device drivers from Lenovo. 1. Open the Start menu.
  • Page 39 If you intend on installing the CRU, Lenovo will ship the CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You might be required to return the defective part that is replaced by the CRU.
  • Page 40 For access, do the following: 1. Remove any media from the drives and turn off all connected devices and the computer. 2. Disconnect all power cords from electrical outlets and disconnect all cables from the computer. Removal steps ThinkEdge SE30 User Guide...
  • Page 41 IO expansion box Note: After you install the IO expansion box to the computer, you can still mount the IO expansion box and the computer together to the wall by using a matched DIN rail bracket, power adapter bracket kit, or a VESA mount bracket.
  • Page 42 2. Disconnect all power cords from electrical outlets and disconnect all cables from the computer. Replacement steps Attention: Use the screws (M3 x 4 mm x 3 pcs) provided by Lenovo to avoid any unpredictable damage to your computer. ThinkEdge SE30 User Guide...
  • Page 43 Note: The shipped plastic expansion bolts might not be applicable if you need to install the DIN rail to a hard surface such as the metal workbench. Chapter 6 CRU replacement...
  • Page 44 The replacement steps also apply to the computer with an IO expansion box installed. See “IO expansion box” on page 35. ThinkEdge SE30 User Guide...
  • Page 45 2. Disconnect all power cords from electrical outlets and disconnect all cables from the computer. Replacement steps Attention: Use the screws (M3 x 4 mm x 3 pcs) provided by Lenovo to avoid any unpredictable damage to your computer. Chapter 6...
  • Page 46 ThinkEdge SE30 User Guide...
  • Page 47 Chapter 6 CRU replacement...
  • Page 48 ThinkEdge SE30 User Guide...
  • Page 49 The replacement steps also apply to the computer with an IO expansion box installed. See “IO expansion box” on page 35. Power adapter bracket kit Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. Chapter 6 CRU replacement...
  • Page 50 For access, do the following: 1. Remove any media from the drives and turn off all connected devices and the computer. 2. Disconnect all power cords from electrical outlets and disconnect all cables from the computer. Replacement steps ThinkEdge SE30 User Guide...
  • Page 51 Remove the power cord from the power adapter. See “Power adapter and power cord” on page 34. Chapter 6 CRU replacement...
  • Page 52 ThinkEdge SE30 User Guide...
  • Page 53 Chapter 6 CRU replacement...
  • Page 54 Install the power cord to the power adapter. ThinkEdge SE30 User Guide...
  • Page 55 Chapter 6 CRU replacement...
  • Page 56 1. Remove any media from the drives and turn off all connected devices and the computer. 2. Disconnect all power cords from electrical outlets and disconnect all cables from the computer. Replacement steps Note: When installing the Z hook kit, fasten the screws correctly to ensure that the computer is stable. ThinkEdge SE30 User Guide...
  • Page 57 Rear Wi-Fi antenna Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. Avoid contact with the hot computer. During operation, the computer becomes hot enough to burn the skin. Before you touch the computer, turn off the computer, disconnect power, and wait approximately 30 minutes for the computer to cool.
  • Page 58 For access, do the following: 1. Remove any media from the drives and turn off all connected devices and the computer. 2. Disconnect all power cords from electrical outlets and disconnect all cables from the computer. ThinkEdge SE30 User Guide...
  • Page 59 Replacement steps Note: Pay attention to the silk print number of each wireless WAN antenna and ensure that it matches the silk print number of the corresponding wireless WAN antenna slot. For the location of wireless WAN antenna slots, see Chapter 1 “Meet your computer” on page 1. Bottom cover Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions.
  • Page 60 4. Remove the bracket, if any. See “DIN rail bracket kit” on page 36, “Physical lock kit and VESA mount bracket kit” on page 39, and “Power adapter bracket kit” on page 43. 5. Turn over the computer so that the bottom cover is facing up. Replacement steps ThinkEdge SE30 User Guide...
  • Page 61 M.2 solid-state drives Prerequisite Before you start, read Generic Safety and Compliance Notices, and print the following instructions. Avoid contact with the hot computer. During operation, the computer becomes hot enough to burn the skin. Before you touch the computer, turn off the computer, disconnect power, and wait approximately 30 minutes for the computer to cool.
  • Page 62 Note: After installing the new M.2 solid-state drive, ensure that you attach the new thermal pad to the new M.2 solid-state drive. • Type 2 2280: Note: A thermal pad might cover the M.2 solid-state drive. To access the M.2 solid-state drive, peel off the thermal pad first. ThinkEdge SE30 User Guide...
  • Page 63 The following information is only for the computer with user-installable modules. Ensure that you use only a Lenovo-authorized wireless module specifically tested for this computer model. Otherwise, the computer will generate an error-code beep sequence when you turn on the computer.
  • Page 64 Wi-Fi card if you have removed one. • Ensure that you connect the gray cable to the connector labeled 1 (auxiliary) and the black cable to connector labeled 2 (main) on the card. ThinkEdge SE30 User Guide...
  • Page 65 The following information is only for the computer with user-installable modules. Ensure that you use only a Lenovo-authorized wireless module specifically tested for this computer model. Otherwise, the computer will generate an error-code beep sequence when you turn on the computer.
  • Page 66 Blue, the light gray cable to the connector labeled White Gray, and the dark gray cable to connector labeled Black Gray on the card. • After installing the new wireless WAN card, ensure that you attach the new thermal pad to the new wireless WAN card. ThinkEdge SE30 User Guide...
  • Page 67 Windows help information • Microsoft support Web site: https://support.microsoft.com Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Prepare the following before you contact Lenovo: 1.
  • Page 68 • Lenovo hardware repair - If the problem is determined to be caused by Lenovo hardware under warranty, trained service personnel are available to provide the applicable level of service.
  • Page 69 Safety and Compliance Notices at https://support.lenovo.com/docs/generic_notices Purchase accessories Lenovo has a number of hardware accessories and upgrades to help expand the capabilities of your computer. Options include memory modules, storage devices, network cards, power adapters, keyboards, mice, and more. To shop at Lenovo, go to https://www.lenovo.com/accessories...
  • Page 70 ThinkEdge SE30 User Guide...
  • Page 71 Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
  • Page 72 Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
