Installation Data
Installation and
Operation Manual
K-1100
Levolor
by Jandy
®
Electronic Water Leveler
Models K-1100, LX2, K-2300, and LEV110CK/2G
FOR YOUR SAFETY - This product must be installed and serviced by a professional pool/
spa service technician. The procedures in this manual must be followed exactly. Failure to
follow warning notices and instructions may result in property damage, serious injury, or
death. Improper installation or operation will void the warranty.
LX2
WARNING
K-2300
LEV110CK/2G
Advertisement
Related Manuals for Jandy Levolor K-1100
Summary of Contents for Jandy Levolor K-1100
- Page 1 Installation and Operation Manual K-2300 K-1100 LEV110CK/2G Levolor by Jandy ® Electronic Water Leveler Models K-1100, LX2, K-2300, and LEV110CK/2G WARNING FOR YOUR SAFETY - This product must be installed and serviced by a professional pool/ spa service technician. The procedures in this manual must be followed exactly. Failure to follow warning notices and instructions may result in property damage, serious injury, or death.
- Page 2 Page 2...
- Page 3 Page 3 Table of Contents Section 1. Safety Information ...... 4 Section 2. System Description ....5 2.1 Electrical Specifications .......5 Wiring Diagrams ..........6 Section 3. Installation Instructions ... 10 Materials and Tools ........10 Installing the Control Box ......10 Changing Wiring for 110 Volt Operation ... 11 Grounding ..........
- Page 4 Page 4 Section 1. Safety Information IMPORTANT SAFETY INSTRUCTIONS PERTAINING TO A RISK OF PROPERTY DAMAGE OR INJURY TO PERSONS READ AND FOLLOW ALL INSTRUCTIONS When installing and using this equipment, basic safety precautions should always be followed, including the following: WARNING FOR YOUR SAFETY.
- Page 5 Page 5 Section 2. System Description Fill Line Levolor Models K-1100, LEV110CK/2G, and LX2 ® are computer-controlled devices that detect a low water condition and automatically replace the water to a pre- set level. They can be used in all pools and spas. The LEV110CK/2G is designed for use in large commercial applications.
- Page 6 Page 6 Wiring Diagrams This section contains wiring diagrams for the K-1100, K-2300, and LEV110CK/2G, along with detailed views of the factory-direct wiring for 220 VAC and the modified wiring for 110 VAC. The section also contains a wiring diagram for the LX2, along with detailed views of the factory-direct wiring for the 220 VAC and 110 VAC units.
- Page 7 Page 7 220 Volt Transformer Operation Line 2 Line 1 Ground Figure 4. K-1100, K-2300, and LEV110CK/2G Factory Wiring for 220 Volt Operation 110 Volt Transformer Operation Neutral Line Ground Figure 5. K-1100, K-2300, and LEV110CK/2G Modified Wiring for 110 Volt Operation...
- Page 8 Page 8 Front Inside View Back Inside View 24 VAC Connect to Transformer Case Blue Solenoid Transformer Enclosure Connect to Valve Wires Black Orange Sensor Wires Black Green High Power ½" Conduit Blue Wires Valve ½" Conduit to Solenoid Valve Orange Wires to Sensor...
- Page 9 Page 9 Five (5) Status Lights Red Wires to Filling Valve II Blue Wires to Filling Valve I Black Wire to Power (24 VAC) Yellow Wire with Red Stripe to Sensor II Yellow Wire to Sensor Common Yellow Wire with Blue Stripe to Sensor I Black Wire to Power (24 VAC) Transformer Green Wire (Ground)
- Page 10 Page 10 Section 3. Installation Instructions Installing the Control Box NOTE When installing a Levolor on a spa (less than Materials and Tools 300 sq ft of surface area), turn the flow control down to reduce the flow rate of the valve. Installation Materials Supplied for Levolor Models K-1100, LX2, or...
- Page 11 Page 11 Connect the 24 VAC water solenoid valve to Changing Wiring for 110 Volt the 18-gauge solid-core burial cable using the Operation supplied grease-filled wire nuts. WARNING Connect the other end according to the model Potentially high voltages in the Levolor control box ®...
- Page 12 Page 12 Installing the Sensor NOTE If using a dual style sensor, cut off and discard the sensor you are not planning to use. See Figure 12. Skim Style Slip Style CAUTION Important Safety Instructions. Sensor wires must be continuous and not spliced. Solder all low voltage wire connections when possible and Figure 12.
- Page 13 Page 13 Sensor Probes Anti-siphon Valve House Levolor ® Control Box Irrigation System Check Valve Return Pool Figure 15. Skim (Half-moon) Sensor in Skimmer Installation in Exisiting Pool Installation Diagrams This section shows diagrams of skim (half-moon) style and slip style sensor installations and details. They are: - Skim (Half-moon) Sensor in Skimmer Installation in Existing Pool - Slip Sensor in Static Pipe Installation in New Pool - Slip Sensor Detail...
- Page 14 Page 14 9" Deck Lid ½" Conduit Connection 1" PVC Cut 6" Conduit to Sensor PVC Cut to Length Control System at To Length Control Box 1" Coupling Sensor Terminate Sensor at Minimum Operating Level 2" Static Line Vented at Top by Drilling Hole in It Slip Sensor Coupling...
- Page 15 Page 15 Levolor Electronic Water Leveler ® 24 VAC 1 ½" to Return Line 110 / 220 VAC Solenoid Valve From City Water Supply 1" Brass "Y" Strainer Via DBL CHK VLV Operating Equip Room Floor Level Water Level Operating Water Level 2"...
- Page 16 Page 16 Section 4. Operation Power Light Sensor Light Fill Light K-1100, LEV110CK/2G, and LX2 The controllers for the K-1100 and LEV110CK/2G (See Figure 22) and the LX2 (See Figure 23) each have three (3) lights. Refer to the figures and Table 1. Power Light Sensor Light Filling Light Power...
- Page 17 Page 17 K-2300 The Sensor II light turns yellow when water is not touching the Sensor II tips. Twenty seconds later, the The controller for the K-2300 has five (5) lights. See Filling II light turns green, indicating that Valve II is Figure 24 and refer to Table 2.
- Page 18 Page 18 Fill Time before Lockout Model K-1100 and LX2: For the K-1100 and LX2 the factory-set Fill time before Jumper Safety Lockout occurs is 20 minutes. The Fill time can Cables be modified by cutting the jumpers as follows: Cut Jumper Fill Time Period Either A or B...
- Page 19 Page 19 Section 5. Troubleshooting b. Model K-2300: Disconnect Valve I from the blue wires in the control box and disconnect Valve II from the red wires in the control box. Manual Valve Override Restore power to the control box and observe the There is a manual ON/OFF lever located just below the operation.
- Page 20 Page 20 Fill Will Not Turn OFF This is a troubleshooting flow chart for the K-1100, LX2, and LEV110CK/2G. Use it when the Fill function will not turn off. Fill Will Not Turn OFF Possible Issues: Is fill Is fill light 1.
- Page 21 Page 21 Fill Will Not Turn ON This is a troubleshooting flow chart for models K-1100, LX2, and LEV110CK/2G. Use it when the Fill function will not turn on. Fill Will Not Turn ON Is power Does unit have power? light on? Lockout sequence has taken effect.
- Page 22 To order or purchase parts for the Levolor products, ® contact your nearest Jandy dealer or distributor. See the Jandy website at www.jandy.com for the nearest service center. For further assistance, contact Customer Service at Zodiac Pool Systems, Inc. at (800)-822-7933.
- Page 23 Page 23 Description Model No. Order Part No. Dual Style (Skimmer or Static Pipe Install) Dual Style Sensor w/50 ft K-1100, LX2, K-2300 S2046A S2046C Dual Style Sensor w/100 ft K-1100, LX2, K-2300 S2046E Dual Style Sensor w/150 ft K-1100, LX2, K-2300 Dual Style Sensor w/200 ft K-1100, LX2, K-2300 S2046G...
- Page 24 Limited Warranty Zodiac Pool Systems, Inc. (“Zodiac”) warrants all Baracuda®, Jandy®, Nature2® and Polaris® brand products to be free from manufacturing defects in materials and workmanship for a period of one (1) year from the date of retail purchase, with the following exceptions: 1.
