- Page 1 *** USER’S MANUAL *** FCC ID : RLS-STAVL0358...
- Page 2 Federal Communications Commission (FCC) Warning THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT INTERFERECE RECEIVED, INCLUDING INTERFERENCE THAT CAUSE...
-
Page 3: Federal Communications Commission (Fcc) Statement
Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: Install Sim Card
® IntelliTrac X Series Hardware Installation Guide 1. Install SIM Card To install the SIM card: Press the yellow button to eject the SIM card holder. Before insert the SIM card, make sure the PIN code has been disabled. Insert the SIM card. Check that it fit into place correctly. - Page 5 2. Install GPS and GSM Antennas Connect GPS antenna to the GPS connector. The optimum location for the GPS antenna is on the roof of the vehicle. The covert and GPS antenna are directional, make sure they are facing up and laying as flat as possible.
- Page 6 (1) General Installation (Without immobilizer installed) Connect Ground(-Black) and BAT(+Red) wires to the battery of vehicle. (2) With immobilizer installed Connect Ground (-Black) and BAT (+Red) to the battery of vehicle. Connect Ignition Key (Pink) to the IGNITION wire. Copyright © 2003 Systems & Technology Corporation...
- Page 7 4. Install Immobilizer Relay (Optional) (1) If the wireless relay terminal is same as car original fuel pump (or ignition, or starter) relay terminal, please just unplug the car original relay, then plug in the wireless relay. (2) If the wireless relay terminal is different with car original fuel pump (or ignition, or starter) relay terminal : Please plug the wireless relay into the spare relay socket, then a.
- Page 8 5. Install Input Cable Power Input Output Input Connector 1 : Input1 2 : Input2/ACC 3 : Input3 4 : Input4 5 : Input5 6 : Input6 7 : Input7 8 : Input8 9 : Analog Input1 10 : Analog Input2 11 : Vout +5V 12 : Ground The Input number 1, 2, 3, 4 are positive triggered inputs and Input number 5, 6, 7, 8 are negative triggered...
- Page 9 Positive Trigger: Negative Trigger: Copyright © 2003 Systems & Technology Corporation...
- Page 10 6. Install Output Cable Power Input Output Output Connector 1 : Output1 2 : Output2 3 : Output3 4 : Output4 5 : Output5 6 : Output6 7 : Output7 8 : Output7 (via relay) 9 : External Output Power 10 : Ground The output number 1, 2, 7 are positive triggered outputs and output number 3, 4, 5, 6 are negative triggered outputs.
- Page 11 7. LED Indicators Status Description There are 4 LEDs in front panel. When you power on the unit, these 4 LEDs will become blinking. After blinking several times, IntelliTrac X8 will start the modem which is inside the unit. In this time, the ERR led light is still bright.
- Page 12 90 ms On / 3 secs Off Logged to network. No call in progress. Voice/Data call connected ERR LED Status Function The device is ready The device is not ready Copyright © 2003 Systems & Technology Corporation...
-
Page 13: Unit Configuration
8. Unit Configuration Connect the download cable between IntelliTrac unit and PC serial interface and use IntelliTrac InstallWizard program to configure a new IntelliTrac unit. Please refer to the InstallWizard User Manual for more detail information. Copyright © 2003 Systems & Technology Corporation...
