To ensure optimal performance and longevity of your THE BOSS Foam Cannon, regular maintenance is
essential. We recommend keeping spare parts on hand for quick and easy replacements when needed.
Stocking the following parts will help minimize downtime and keep your foam cannon operating at its best:
Description
THE BOSS Foam Cannon Rebuild Kit
Sure-Flow Metering Tips, Set of 6 | Pink
Sure-Flow Metering Tips, Set of 6 | Aqua
Sure-Flow Metering Tips, Set of 6 | Purple
CHALLENGE
DESCRIPTION
Poor Foam
Thin, watery
Output
foam
THE BOSS
Foam Cannon
Troubleshooting Guide
LIKELY SOURCE
Sure-Flow
Metering Tip
(17) Clogged
Stainless-Steel
Mesh Pill (4)
Clogged
™
Item#
BFKIT
B3006PNKTIP
B3006AQATIP
B3006PURTIP
SOLUTION
1. Remove Sure-Flow Metering Tip (17) from
Stainless-Steel Pick-Up Ball (13), soak in hot water, then
gently agitate insertion end with a soft bristle brush. Rinse
clean then reinsert tip into pick-up ball.
2. If issue persists, replace Sure-Flow Metering Tip (17)
with new tip. Replacement tips available for purchase
separately (Item# B3006 – Sure-Flow Metering Tips, Set
of 6) in Pink, Aqua, and Purple.
1. Press Nozzle Retainer Pin (1) out of black Nozzle
Adjuster (2) with pick or small flathead screwdriver and
set in a secure location. It may require a light tap of a small
mallet.
2. Remove Nozzle Adjuster (2) from cannon barrel and set
aside.
3. Using a 22mm box wrench or adjustable wrench carefully
remove the Fan-Jet Assembly (3) from the Secondary
Manifold (6) by firmly turning counterclockwise. This may
require additional torque. Should this present a challenge,
soak manifold assembly in hot water for 5 minutes.
Additional opposing force may be required, applying a
24mm wrench or suitable adjustable wrench on the
Secondary Manifold (6).
4. Once the Fan-Jet Assembly (3) is removed, rest on
workbench and carefully insert small flathead screwdriver
through the Fan-Jet (3a) side and press out the
Stainless-Steel Mesh Pill (4) from the barrel end. Another
option is to insert a j-hook pick on the opposing side and
remove the pill by pulling it out.
5. Inspect the mesh pill for corrosion, soap scum, or other
visible wear and clean or replace as necessary. Should
foaming performance be diminished, the mesh pill will most
certainly require replacement. Insert cleaned pill, or new
Stainless-Steel Mesh Pill (4) from rebuild kit and firmly
seat it into position by applying pressure with small flathead
screwdriver.
6. Reinstall in reverse order.
ITEM# BF302
Advertisement
Related Manuals for Griots Garage THE BOSS BF302
Summary of Contents for Griots Garage THE BOSS BF302
- Page 1 ITEM# BF302 THE BOSS ™ Foam Cannon Troubleshooting Guide To ensure optimal performance and longevity of your THE BOSS Foam Cannon, regular maintenance is essential. We recommend keeping spare parts on hand for quick and easy replacements when needed. Stocking the following parts will help minimize downtime and keep your foam cannon operating at its best: Description Item# THE BOSS Foam Cannon Rebuild Kit...
- Page 2 CHALLENGE DESCRIPTION LIKELY SOURCE SOLUTION Poor water 1. Hard water not only reduces foam output but can clog, quality corrode, and permanently damage equipment over time. Rely on a soft water source or install a deionizing system in-line before the pressure washer. 1.
- Page 3 CHALLENGE DESCRIPTION LIKELY SOURCE SOLUTION Sudsy water Secondary 1. Press Nozzle Retainer Pin (1) out of black Nozzle leaking from Nitrile O-Ring Adjuster (2) with pick or small flathead screwdriver and Nozzle Adjuster (5) failure set in a secure location. It may require a light tap of a small mallet.
- Page 4 CHALLENGE DESCRIPTION LIKELY SOURCE SOLUTION Insufficient Foam Larger Foam 1. THE BOSS Foam Cannon comes with the 1.25 Foam Cannon Jet (9) Cannon Jet (9) is Cannon Jet (9) pre-installed. This is ideal for most orifice size required gas-powered pressure washers or units exceeding 4000 causing backup CU (Cleaning Units = gpm x psi).
- Page 5 CHALLENGE CHALLENGE DESCRIPTION LIKELY SOURCE SOLUTION Sure-Flow The Sure-Flow Silicone Retainer 1. Attempt to reinsert Sure-Flow Metering Tip (17) until its Metering Tip Metering Tip Tube (16) has fully seated into the Silicone Retainer Tube (16) at the end Falls Out (17) has become become of the Stainless-Steel Pick-Up Ball (13).
- Page 6 PARTS BREAKOUT Description Nozzle Retainer Pin Nozzle Adjuster Fan-Jet Assembly Fan-Jet Fan-Jet Housing Stainless-Steel Mesh Pill Secondary Nitrile O-Ring Secondary Manifold Primary Nitrile O-Ring Primary Manifold Foam Cannon Jet, 1.1 or 1.25 Stainless-Steel Quick Connect Coupler Plug Dual-Threaded Cap Silicone Pick-Up Tube Stainless-Steel Pick-Up Ball Foam Cannon Jar Detergent Dial...
