Page 1 ARL02754U1 AC750 Wireless Dual Band Gigabit Router REV1.0.0 1910020727...
Page 2: Fcc Rf Radiation Exposure Statement
FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 3: Ce Mark Warning
CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. National Restrictions This device is intended for home and office use in all EU countries (and other countries following the EU directive 1999/5/EC) without any limitation except for the countries mentioned below: Country Restriction...
Page 5: Table Of Contents
CONTENTS Package Contents ..................... 1 Chapter 1. Introduction ..................2 1.1 Overview of the Router ....................2 1.2 Conventions ........................3 1.3 Main Features ....................... 3 1.4 Panel Layout ......................... 4 1.4.1 The Front Panel ....................4 1.4.2 The Rear Panel ....................5 Chapter 2.
Page 6 4.7 Wireless 5GHz ......................50 4.7.1 Basic Settings ....................50 4.7.2 WPS ........................ 53 4.7.3 Wireless Security .................... 55 4.7.4 Wireless MAC Filtering ................... 59 4.7.5 Wireless Advanced ..................61 4.7.6 Wireless Statistics ................... 62 4.8 Guest Network ......................63 4.9 DHCP ..........................
Page 7 4.13.2 Advanced Security ..................4.13.3 Local Management ..................4.13.4 Remote Management ..................4.14 Parent Control ......................4.15 Access Control ......................4.15.1 Rule ......................... 4.15.2 Host ......................... 4.15.3 Target ......................4.15.4 Schedule .......................1 4.16 Advanced Routing ....................1 4.16.1 Static Route List ....................1 4.16.2 System Routing Table ...................
Page 8 4.20.1 IPv6 Status ....................4.20.2 IPv6 WAN ...................... 4.20.3 IPv6 LAN ....................... 4.21 System Tools ......................4.21.1 Time Settings ....................4.21.2 Diagnostic ..................... 4.21.3 Firmware Upgrade ..................1 4.21.4 Factory Defaults ....................1 4.21.5 Backup & Restore ..................1 4.21.6 Reboot ......................1 4.21.7 Password ......................1 4.21.8 System Log ....................1 4.21.9 Statistics ......................1 4.22 Logout ........................1 27...
Page 9: Package Contents
Package Contents The following items should be found in your package: ARL02754U1 AC750 Wireless Dual Band Gigabit Router  DC Power Adapter for ARL02754U1 AC750 Wireless Dual Band Gigabit Router  Quick Installation Guide  Resource CD for ARL02754U1 AC750 Wireless Dual Band Gigabit Router, including: ...
Page 10: Chapter 1. Introduction
Before installing the router, please look through this guide to know all the router’s functions. Conventions The router or ARL02754U1 mentioned in this guide stands for ARL02754U1 AC750 Wireless Dual Band Gigabit Router without any explanation. - 2 -...
Page 11: Main Features
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Main Features Complies with IEEE 802.11ac.  One 10/100/1000M Auto-Negotiation RJ45 WAN port, four 10/100/1000M Auto-Negotiation  RJ45 LAN ports, supporting Auto MDI/MDIX. Provides USB ports supporting storage/FTP/Media.  Provides WPA/WPA2, WPA-PSK/WPA2-PSK authentication, TKIP/AES encryption security.
Page 12 ARL02754U1 AC750 Wireless Dual Band Gigabit Router The wireless function is disabled. (Wireless) The wireless function is enabled. The router is working on 2.4GHz or 5GHz or both radio band. No device is connected to the LAN ports. (Ethernet) At least one device has connected to the LAN ports.
Page 13: The Rear Panel
ARL02754U1 AC750 Wireless Dual Band Gigabit Router 1.4.2 The Rear Panel Figure 1-2 Rear Panel sketch The following parts are located on the rear panel (View from left to right).  WPS/Reset: Pressing this button for less than 5 seconds enables the WPS function. If your client devices,...
Page 14 ON/OFF: The switch for the power.  POWER: The Power socket is where you will connect the power adapter. Please use the power adapter provided with this ARL02754U1 AC750 Wireless Dual Band Gigabit Router.  Wireless antenna: To receive and transmit the wireless data.
Page 15: Chapter 2. Connecting The Router
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Chapter 2. Connecting the router System Requirements Broadband Internet Access Service (DSL/Cable/Ethernet)  One DSL/Cable Modem that has an RJ45 connector (which is not necessary if the router is  connected directly to the Ethernet) PCs with a working Ethernet Adapter and an Ethernet cable with RJ45 connectors ...
Page 16: Chapter 3. Quick Installation Guide
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 2-1 Hardware Installation Figure 2-2 USB Installation  Note: If you want to use the router to share files, plug the USB storage device to the USB port. Chapter 3. Quick Installation Guide This chapter will show you how to configure the basic functions of your AC750 Wireless Dual Band Gigabit Router using Quick Setup Wizard within minutes.
Page 17: Tcp/Ip Configuration
ARL02754U1 AC750 Wireless Dual Band Gigabit Router TCP/IP Configuration The default IP address of the router is 192.168.1.1 and the default Subnet Mask is 255.255.255.0. These values can be changed as you desire. In this guide, we use all the default values for description.
Page 18: Quick Installation Guide
ARL02754U1 AC750 Wireless Dual Band Gigabit Router  Note: The Ethernet LED on the router and LEDs on your PC's adapter should be lit. Is the TCP/IP configuration for your PC correct?  Note: If the router's IP address is 192.168.1.1, your PC's IP address must be within the range of 192.168.1.2 ~ 192.168.1.254.
Page 19 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 3-4 Login Windows  Note: If the above screen does not pop up, it means that your Web-browser has been set to a proxy. Go to Tools menu>Internet Options>Connections>LAN Settings, in the screen that appears, cancel the Using Proxy checkbox, and click OK to finish it.
Page 20 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 3-6 WAN Connection Type The router provides Auto-Detect function and supports five types of WAN connection: Dynamic IP, Static IP, PPPoE/Russian PPPoE, L2TP/Russian L2TP, and PPTP/Russian PPTP. It’s recommended that you make use of the Auto-Detect function. If you are sure of what kind of connection type your ISP provides, you can select the very type and click Next to go on configuring.
Page 21 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 3-7 Quick Setup – MAC Clone 2) If the connection type detected is Static IP, the next screen will appear as shown in Figure 3-8. Configure the following parameters and then click Next to continue.
Page 22 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Secondary DNS Server-（Optional） If your ISP provides another DNS server, enter it  into this field. 3) If the connection type detected is PPPoE/Russia PPPoE, the next screen will appear as shown in Figure 3-9. Configure the following parameters and then click Next to continue.
Page 23 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 3-10 Quick Setup – L2TP/Russia L2TP Username/Password - Enter the Username and Password provided by your ISP.  These fields are case-sensitive. If you have difficulty with this process, please contact your ISP.
Page 24 ARL02754U1 AC750 Wireless Dual Band Gigabit Router 5) If your connection type is PPTP/Russia PPTP, select PPTP/Russia PPTP in Figure 3-6 and the next screen will appear as shown in Figure 3-11. Configure the following parameters and then click Next to continue.
Page 25 ARL02754U1 AC750 Wireless Dual Band Gigabit Router After finishing the WAN Connection Type selection, the Dual Band Selection page will appear as shown in Figure 3-12. Here we take “2.4GHz and 5GHz” for example. Click Next to continue. Figure 3-12 Quick Setup – Dual Band Selection 2.4GHz - You can use the 2.4GHz band to connect to many classic wireless devices like...
Page 26 ARL02754U1 AC750 Wireless Dual Band Gigabit Router network. The default SSID is set to be Wireless_2.4GHz_XXXXXX. This value is case- sensitive. For example, TEST is NOT the same as test. Region - Select your region from the drop-down list. This field specifies the region where ...
Page 27 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 3-14 Quick Setup – Wireless 5GHz Wireless Network Name - Also called the SSID (Service Set Identification). Enter a  value of up to 32 characters. The same name must be assigned to all wireless devices in your network.
Page 28 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Band - This field displayed the operating frequency being configured.  Mode - This field determines the wireless mode which the router works on.   11an mixed - Select if you are using both 802.11a and 802.11n wireless clients.
Page 29 PW - AC4573R AC750 Wireless Dual Band Gigabit Router Figure 3-15 Quick Setup - Confirm Click the Finish button to complete the Quick Setup. - 21 -...
Page 30: Chapter 4. Configuring The Router
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 3-16 Quick Setup - Finish Chapter 4. Configuring the router This chapter will show each key function of the Web page and its configuration method. Login After your successful login, you will see the main menus on the left of the Web-based utility. On the right, there are the corresponding explanations and instructions.
Page 31 PW - AC4573R AC750 Wireless Dual Band Gigabit Router - 23 -...
Page 32: Quick Setup
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-1 Status Quick Setup Please refer to 3.2 Quick Installation Guide. Network Figure 4-2 the Network menu There are three submenus under the Network menu (shown in Figure 4-2): WAN, LAN and MAC Clone.
Page 33 PW - AC4573R AC750 Wireless Dual Band Gigabit Router Figure 4-3 WAN – Dynamic IP This page displays the WAN IP parameters assigned dynamically by your ISP, including IP address, Subnet Mask, Default Gateway, etc. Click the Renew button to renew the IP parameters from your ISP.
Page 34 ARL02754U1 AC750 Wireless Dual Band Gigabit Router  Set DNS server manually - If your ISP gives you one or two DNS addresses, select Set DNS server manually and enter the primary and secondary addresses into the correct fields. Otherwise, the DNS servers will be assigned automatically from your ISP.
Page 35 PW - AC4573R AC750 Wireless Dual Band Gigabit Router MTU (Bytes)- The normal MTU (Maximum Transmission Unit) value for most Ethernet  networks is 1500 Bytes. It is not recommended that you change the default MTU size unless required by your ISP. - 27 -...
Page 36 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Enable IGMP Proxy - IGMP (Internet Group Management Protocol) is used to manage  multicasting on TCP/IP networks. Some ISPs use IGMP to perform remote configuration for client devices, such as the modem router. The default value is enabled, and if you are not sure, please contact your ISP or just leave it.
Page 37 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Secondary Connection - It’s available only for PPPoE Connection. If your ISP provides an  extra Connection type such as Dynamic/Static IP to connect to a local area network, then you can check the radio button of Dynamic/Static IP to activate this secondary connection.
Page 38 ARL02754U1 AC750 Wireless Dual Band Gigabit Router ISP Specified IP Address - If your ISP does not automatically assign IP addresses to the  router during login, please click “Use IP address specified by ISP” check box and enter the IP address provided by your ISP in dotted-decimal notation.
Page 39 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Auth Server - Enter the authenticating server IP address or host name.  Auth Domain - Type in the domain suffix server name based on your location. e.g.  NSW / ACT - nsw.bigpond.net.au VIC / TAS / WA / SA / NT - vic.bigpond.net.au QLD...
Page 40 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-7 WAN - L2TP/Russia L2TP Username/Password - Enter the User Name and Password provided by your ISP. These  fields are case-sensitive. Addressing Type - Choose the addressing type given by your ISP, either Dynamic IP or Static ...
Page 41 ARL02754U1 AC750 Wireless Dual Band Gigabit Router client devices, such as the modem router. The default value is enabled, and if you are not sure, please contact your ISP or just leave it. Connection Mode-choose the Internet connection mode. ...
Page 42 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-8 PPTP Settings Username/Password - Enter the User Name and Password provided by your ISP. These  fields are case-sensitive. Dynamic IP/ Static IP - Choose the addressing type given by your ISP, either Dynamic IP or ...
Page 43 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Enable IGMP Proxy - IGMP (Internet Group Management Protocol) is used to manage  multicasting on TCP/IP networks. Some ISPs use IGMP to perform remote configuration for client devices, such as the modem router. The default value is enabled, and if you are not sure, please contact your ISP or just leave it.
Page 44: Lan
ARL02754U1 AC750 Wireless Dual Band Gigabit Router The router cannot detect PPTP/L2TP/Big Pond connections with your ISP. If your ISP uses one of these protocols, then you must configure your connection manually. 4.4.2 Choose menu “Network → LAN”, you can configure the IP parameters of the LAN on the screen as below.
Page 45: Dual Band Selection
PW - AC4573R AC750 Wireless Dual Band Gigabit Router Figure 4-10 MAC Clone Some ISPs require that you register the MAC Address of your adapter. Changes are rarely needed here. WAN MAC Address - This field displays the current MAC address of the port.
Page 46: Wireless 2.4Ghz
PW - AC4573R AC750 Wireless Dual Band Gigabit Router Figure 4-11 Dual Band Selection 2.4GHz (802.11b/g/n) - Click the box, and then the router will only work in 2.4GHz frequency.  You can use the 2.4GHz band to connect to many classic wireless devices like gaming consoles, laptops, DVRs, etc.
Page 47 PW - AC4573R AC750 Wireless Dual Band Gigabit Router Figure 4-13 Wireless Settings – 2.4GHz Wireless Network Name - Also called the SSID (Service Set Identification). Enter a value  of up to 32 characters. The same name must be assigned to all wireless devices in your network.
Page 48 PW - AC4573R AC750 Wireless Dual Band Gigabit Router Note Dialog - 40 -...
Page 49 ARL02754U1 AC750 Wireless Dual Band Gigabit Router  Note: Limited by local law regulations, version for North America does not have region selection option. Mode - Select the desired mode.   11bg mixed - Select if you are using both 802.11b and 802.11g wireless clients.
Page 50: Wps
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-14 WDS Setting SSID (to be bridged) - The SSID of the AP your router is going to connect to as a client.  You can also use the search function to select the SSID to join.
Page 51 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-15 WPS WPS - Enable or disable the WPS function here.  Current PIN - The current value of the router's PIN is displayed here. The default PIN of the  router can be found in the label or User Guide.
Page 52 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-16 Figure 4-17 Add A New Device Step 2: Press and hold the WPS button of the client device. Step 3: The Wi-Fi Protected Setup LED flashes for two minutes during the Wi-Fi Protected Setup process.
Page 53: Wireless Security
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Step 2: Enter the PIN number from the client device in the field on the WPS screen above. Then click Connect button. Step 3: “Connect successfully” will appear on the screen of Figure 4-18, which means the client device has successfully connected to the router.
Page 54 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-19 Wireless Security Disable Wireless Security - If you do not want to use wireless security, check this radio button.  But it’s strongly recommended to choose one of the following modes to enable security.
Page 55 ARL02754U1 AC750 Wireless Dual Band Gigabit Router  Note: If you check the WPA/WPA2-Personal radio button and choose TKIP encryption, you will find a notice in red as shown in Figure 4-20. Figure 4-20 WPA/WPA2 – Personal Wireless Password - You can enter ASCII characters between 8 and 63 characters or 8 to •...
Page 56: Wireless Mac Filtering
ARL02754U1 AC750 Wireless Dual Band Gigabit Router WEP - It is based on the IEEE 802.11 standard. If you check this radio button, you will find a  notice in red as show in Figure 4-22. Figure 4-22 WEP Authentication Type - you can choose the type for the WEP security on the drop-down list.
Page 57 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-23 Wireless MAC Filtering To filter wireless users by MAC Address, click Enable. The default setting is Disabled. MAC Address - The wireless station's MAC address that you want to filter. ...
Page 58: Wireless Advanced
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Wireless station A. Select Enabled or Disabled for this entry on the Status drop-down list. Click the Save button to save this entry. To edit or delete an existing entry: Click the Edit in the entry you want to modify. If you want to delete the entry, click the Delete.
Page 59 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Choose menu “Wireless 2.4GHz → Wireless Advanced”, you can configure the advanced settings of your wireless network. Figure 4-25 Wireless Advanced Transmit Power - Here you can specify the transmit power of router. You can select High, ...
Page 60: Wireless Statistics
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Enable Short GI - This function is recommended for it will increase the data capacity by  reducing the guard interval time Enabled AP Isolation - This function can isolate wireless stations on your network from each ...
Page 61: Wireless 5Ghz
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Wireless 5GHz Figure 4-27 Wireless menu There are six submenus under the Wireless menu (shown in Figure 4-12): Basic Settings, WPS, Wireless Security, Wireless MAC Filtering, Wireless Advanced and Wireless Statistics. Click any of them, and you will be able to configure the corresponding functions.
Page 62 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Wireless_5GHz_XXXXXX. This value is case-sensitive. For example, TEST is NOT the same as test. Region - Select your region from the drop-down list. This field specifies the region where  the wireless function of the router can be used. It may be illegal to use the wireless function of the router in a region other than one of those specified in this field.
Page 63 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Enable WDS Bridging - Check this box to enable WDS. With this function, the router can  bridge two or more WLANs. If this checkbox is selected, you will have to set the following parameters as shown in Figure 4-29.
Page 64 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-30 WPS WPS - Enable or disable the WPS function here.  Current PIN - The current value of the router's PIN is displayed here. The default PIN of the  router can be found in the label or User Guide.
Page 65 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-31 Figure 4-32 Add A New Device Step 2: Press and hold the WPS button of the client device directly. Step 3: The Wi-Fi Protected Setup LED flashes for two minutes during the Wi-Fi Protected Setup process.
Page 66 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Step 2: Enter the PIN number from the client device in the field on the above WPS screen. Then click Connect button. Step 3: “Connect successfully” will appear on the screen of Figure 4-33, which means the client device has successfully connected to the router.
Page 67 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-34 Wireless Security Disable Security - If you do not want to use wireless security, check this radio button. But it’s  strongly recommended to choose one of the following modes to enable security.
Page 68 ARL02754U1 AC750 Wireless Dual Band Gigabit Router If you check the WPA/WPA2-Personal radio button and choose TKIP encryption, you will find a notice in red as shown in Figure 4-35. Figure 4-35 WPA/WPA2 – Personal Wireless Password - You can enter ASCII characters between 8 and 63 characters or 8 •...
Page 69 ARL02754U1 AC750 Wireless Dual Band Gigabit Router WEP - It is based on the IEEE 802.11 standard. If you check this radio button, you will find a  notice in red as show in Figure 4-37. Figure 4-37 WEP Authentication Type - you can choose the type for the WEP security on the drop-down •...
Page 70 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-38 Wireless MAC Filtering To filter wireless users by MAC Address, click Enable. The default setting is Disabled. MAC Address - The wireless station's MAC address that you want to filter. ...
Page 71 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Give a simple description for the wireless station in the Description field. For example: Wireless station A. Select Enabled or Disabled for this entry on the Status drop-down list. Select the Host for the entry.
Page 72 ARL02754U1 AC750 Wireless Dual Band Gigabit Router 4.7.5 Wireless Advanced Choose menu “Wireless → Wireless Advanced”, you can configure the advanced settings of your wireless network. Figure 4-40 Wireless Advanced Transmit Power - Here you can specify the transmit power of router. You can select High, ...
Page 73 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Fragmentation Threshold - This value is the maximum size determining whether packets  will be fragmented. Setting the Fragmentation Threshold too low may result in poor network performance because of excessive packets. 2346 is the default setting and is recommended.
Page 74: Guest Network
ARL02754U1 AC750 Wireless Dual Band Gigabit Router If the numbers of connected wireless stations go beyond one page, click the Next button to go to the next page and click the Previous button to return the previous page.  Note: This page will be refreshed automatically every 5 seconds.
Page 75 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-42 Guest Network Wireless Settings  Allow Guest To Access My Local Network - If enabled, guests can communicate with hosts.  Allow Guest To Access My USB Storage Sharing - If enabled, guests can access to USB storage sharing servers.
Page 76: Dhcp Settings
PW - AC4573R AC750 Wireless Dual Band Gigabit Router  Guest Network Bandwidth Control - If enabled, the Guest Network Bandwidth Control rules will take effect.  Band Select/Guest Network – Select the wireless network band (2.4G/5G) and enabled or disable its Guest Network function.
Page 77 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-44 DHCP Settings DHCP Server - Enable or Disable the DHCP server. If you disable the Server, you must have  another DHCP server within your network, otherwise you must configure the computer manually.
Page 78: Dhcp Clients List
PW - AC4573R AC750 Wireless Dual Band Gigabit Router 4.9.2 DHCP Clients List Choose menu “DHCP → DHCP Clients List”, you can view the information about the clients attached to the router in the screen as shown in Figure 4-45. Figure 4-45 DHCP Clients List Client Name - The name of the DHCP client ...
Page 79: Usb Settings
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-46 Address Reservation MAC Address - The MAC address of the PC for which you want to reserve an IP address.  IP Address - The IP address reserved for the PC by the router.
Page 80: User Accounts
PW - AC4573R AC750 Wireless Dual Band Gigabit Router Figure 4-48 The USB Settings menu There are six submenus under the USB Settings menu (shown in Figure 4-48): USB Mass Storage, User Accounts, Storage Sharing, FTP Server and Media Server. Click any of them, and you will be able to configure the corresponding functions.
Page 81 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-50 User Account Management Only Administrator can use a Web browser to transfer the files from a PC to the Writable shared volume on the USB drive. To add a new user account, please follow the steps below: Choose the Index from the drop-down list.
Page 82: Storage Sharing
PW - AC4573R AC750 Wireless Dual Band Gigabit Router Please restart the service for the new settings to take effect. If you cannot use the new user name and password to access the shares, press Windows logo + R to open the Run dialog box and type net use \\192.168.1.1 /delete /yes and press Enter.
Page 83 ARL02754U1 AC750 Wireless Dual Band Gigabit Router User Access – Indicates user access of the shared folder. F stands for fully access, R stands  for read-only and N stands for no-access. Status - Indicates the shared or non-shared status of the volume.
Page 84 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Click the Apply button to make the settings take effect. 4.10.4 FTP Server Choose menu “USB Settings→FTP Server”, you can create an FTP server that can be accessed from the Internet or your local network.
Page 85: Media Server
ARL02754U1 AC750 Wireless Dual Band Gigabit Router If WAN type is PPPoE/PPTP/L2TP, two connections will be available. Therefore, users can access FTP server via two connections. Users in a private LAN can access ftp server via Public Address while Internet users can access ftp server via Internet Address.
Page 86 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-55 Media Server Setting Server Enable - Indicates the Media Server’s current status, started or stopped. You can click  the Enable button to enable the Media Server and click the Disable button to disable it.
Page 87 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-57 Add New Folder  Share Name - You can enter a display name for the share folder. Directory - Displays the location of this folder.  Browse – Click the button to select the folder to share.
Page 88: Virtual Servers
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-58 The Forwarding menu Enable NAT Control - If enabled, the NAT function and the Forwarding configuration will take  effect. Disable NAT Control - If disabled, neither NAT function nor Forwarding configuration will take ...
Page 89 ARL02754U1 AC750 Wireless Dual Band Gigabit Router using the DHCP function. If you want the Virtual Servers configuration take effect, please make sure the NAT is enabled. Figure 4-60 Virtual Servers Service Port - The numbers of External Service Ports. You can enter a service port or a range ...
Page 90: Port Triggering
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-61 Add or Modify a Virtual Server Entry  Note: It is possible that you have a computer or server that has more than one type of available service. If so, select another service, and type the same IP address for that computer or server.
Page 91 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-62 Port Triggering Trigger Port - The port for outgoing traffic. An outgoing connection using this port will trigger  this rule. Trigger Protocol - The protocol used for Trigger Ports, either TCP, UDP, or All (all protocols ...
Page 92 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-63 Add or Modify a Triggering Entry To modify or delete an existing entry: Find the desired entry in the table. Click Edit or Delete as desired on the Edit column. Click the Enable Selected button to make selected entries enabled.
Page 93 ARL02754U1 AC750 Wireless Dual Band Gigabit Router 4.12.3 Choose menu “Forwarding→DMZ”, and then you can view and configure DMZ host in the screen (shown in Figure 4-64).The DMZ host feature allows one local host to be exposed to the Internet for a special-purpose service such as Internet gaming or videoconferencing.
Page 94: Basic Security
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Current UPnP Status - UPnP can be enabled or disabled by clicking the Enable or Disable  button. This feature is enabled by default. Current UPnP Settings List - This table displays the current UPnP information.
Page 95 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-67 Basic Security Firewall - A firewall protects your network from the outside world. Here you can enable or  disable the router’s firewall. SPI Firewall - SPI (Stateful Packet Inspection, also known as dynamic packet filtering) ...
Page 96: Advanced Security
ARL02754U1 AC750 Wireless Dual Band Gigabit Router L2TP Passthrough - Layer Two Tunneling Protocol (L2TP) is the method used to enable  Point-to-Point sessions via the Internet on the Layer Two level. To allow L2TP tunnels to pass through the router, click Enable.
Page 97 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-68 Advanced Security  DoS Protection - Denial of Service protection. Check the Enable or Disable button to enable or disable the DoS protection function. Only when it is enabled, will the flood filters be enabled.
Page 98: Local Management
ARL02754U1 AC750 Wireless Dual Band Gigabit Router  TCP-SYN-FLOOD Packets Threshold (5~3600) - The default value is 50. Enter a value between 5 ~ 3600. When the current TCP-SYN-FLOOD Packets numbers is beyond the set value, the router will startup the blocking function immediately.
Page 99: Remote Management
ARL02754U1 AC750 Wireless Dual Band Gigabit Router  Note: If your PC is blocked but you want to access the router again, use a pin to press and hold the WPS/Reset button (hole) on the back panel for about 5 seconds to reset the router’s factory defaults on the router’s Web-Based Utility.
Page 100: Parent Control
ARL02754U1 AC750 Wireless Dual Band Gigabit Router 4.14 Parent Control Choose menu “Parent Control”, and then you can configure the parent control in the screen as shown in Figure 4-71. The Parent Control function can be used to control the Internet activities of the child, limit the child to access certain websites and restrict the time of surfing.
Page 101 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-71 Parent Control Settings Parent Control - Check Enable if you want this function to take effect; otherwise, check  Disable. - 93 -...
Page 102 ARL02754U1 AC750 Wireless Dual Band Gigabit Router MAC Address of Parental PC - In this field, enter the MAC address of the controlling PC, or  you can make use of the Copy To Above button below. MAC Address of Current PC - This field displays the MAC address of the PC that is managing ...
Page 103 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-72 Parent Control Settings - 95 -...
Page 104: Access Control
ARL02754U1 AC750 Wireless Dual Band Gigabit Router 4.15 Access Control Figure 4-73 Access Control There are four submenus under the Access Control menu: Rule, Host, Target and Schedule (as shown in Figure 4-73). Click any of them, and you will be able to configure the corresponding function.
Page 105 ARL02754U1 AC750 Wireless Dual Band Gigabit Router  Enable - Here displays the status of the rule, enabled or not. Check this option to enable a specific entry.  Edit - Here you can edit or delete an existing rule.
Page 106 ARL02754U1 AC750 Wireless Dual Band Gigabit Router For example: If you desire to allow the host with MAC address 00 : 11 : 22 : 33 : 44 : AA to access www.google.com only from 18:00 to 20:00 on Saturday and Sunday, and forbid other hosts in the LAN to access the Internet, you should follow the settings below: Click the submenu Rule of Access Control in the left to return to the Rule List page.
Page 107 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-76 Host Settings Description - Here displays the description of the host and this description is unique.  Address Info - Here displays the information about the host. It can be IP or MAC.
Page 108 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-78 Add or Modify a Host Entry For example: If you desire to restrict the internet activities of host with MAC address 00:11:22:33:44:AA, you should first follow the settings below: Click Add New button in Figure 4-76 to enter the Add or Modify a Host Entry page.
Page 109 ARL02754U1 AC750 Wireless Dual Band Gigabit Router  Details - The target can be IP address, port, or domain name.  Edit- To modify or delete an existing entry. To add a new entry, please follow the steps below. Click the Add New button.
Page 110 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-82 Add or Modify an Access Target Entry In Description field, create a unique description for the target (e.g. Target_1). In Add URL Address field, enter the domain name, either the full name or the keywords (for example, google) in the blank.
Page 111 ARL02754U1 AC750 Wireless Dual Band Gigabit Router 4.15.4 Schedule Choose menu “Access Control → Schedule”, and then you can view and set a Schedule list in the next screen as shown in Figure 4-83. The Schedule list is necessary for the Access Control Rule.
Page 112: Advanced Routing
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-84 Advanced Schedule Settings For example: If you desire to restrict the internet activities of host with MAC address 00:11:22:33:44:AA to access www.google.com only from 18:00 to 20:00 on Saturday and Sunday, you should first follow the settings below: Click Add New button shown in Figure 4-83 to enter the Advanced Schedule Settings page.
Page 113: Static Route List
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-85 Advanced Routing There are two submenus under the Advanced Routing menu as shown in Figure 4-85: Static Route List and System Routing Table. Click any of them, and you will be able to configure the corresponding function.
Page 114: System Routing Table
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Gateway - This is the IP Address of the gateway device that allows for contact between the  router and the network or host. Select Enabled or Disabled for this entry on the Status drop-down list.
Page 115: Bandwidth Control
ARL02754U1 AC750 Wireless Dual Band Gigabit Router 4.17 Bandwidth Control Figure 4-89 Bandwidth Control Choose menu “Bandwidth Control”, and then you can configure the bandwidth control in the screen as shown in Figure 4-89 Bandwidth Control. You can configure the Egress Bandwidth and Ingress Bandwidth in this page. Their values you configure should be less than 100000Kbps.
Page 116: Ip & Mac Binding
ARL02754U1 AC750 Wireless Dual Band Gigabit Router To add/modify a Bandwidth Control rule, follow the steps below. Click Add New shown in Figure 4-89, you will see a new screen shown in Figure 4-90. Enter the information like the screen shown below.
Page 117 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-92 Binding Setting  MAC Address - The MAC address of the controlled computer in the LAN.  IP Address - The assigned IP address of the controlled computer in the LAN.
Page 118: Dynamic Dns
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Find the desired entry in the table. Click Edit or Delete as desired on the Edit column. 4.18.2 ARP List To manage the computer, you could observe the computers in the LAN by checking the relationship of MAC address and IP address on the ARP list, and you could also configure the items on the ARP list.
Page 119: No-Ip.com Ddns
ARL02754U1 AC750 Wireless Dual Band Gigabit Router 4.19.1 No-ip.com DDNS If the dynamic DNS Service Provider you select is www.no-ip.com, the page will appear as shown in. Figure 4-95 Figure 4-95 No-ip.com DDNS Settings To set up for DDNS, follow these instructions: Enter the Domain Name you received from dynamic DNS service provider.
Page 120: Dyndns.com Ddns
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-96 Comexe.cn DDNS Settings To set up for DDNS, follow these instructions: Enter the Domain Name your dynamic DNS service provider gave. Enter the Username for your DDNS account. Enter the Password for your DDNS account.
Page 121 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-97 Dyndns.org DDNS Settings To set up for DDNS, follow these instructions: Enter the Domain Name you received from dynamic DNS service provider. Enter the Username for your DDNS account. Enter the Password for your DDNS account.
Page 122: Ipv6 Status
ARL02754U1 AC750 Wireless Dual Band Gigabit Router There are three submenus under the IPv6 Support menu (shown in Figure 4-98): IPv6 Status, IPv6 WAN and IPv6 LAN. Click either of them, and you will be able to scan or configure the corresponding function.
Page 123 ARL02754U1 AC750 Wireless Dual Band Gigabit Router 4.20.2 IPv6 WAN Figure 4-100 Enable/Disable IPv6  Connection Type - Choose the correct WAN connection type based on your ISP network topology. Dynamic IPv6 - Connections which use dynamic IPv6 address assignment.
Page 124 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-101 Dynamic IPv6  IPv6 Address - The IPv6 address assigned by your ISP dynamically.  Prefix Length - The length of IPv6 address prefix.  IPv6 Gateway - Enter the default gateway provided by your ISP.
Page 125 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-102 Static IPv6  IPv6 Address - Enter the IPv6 address provided by your ISP.  Prefix Length - The length of IPv6 address prefix.  IPv6 Gateway - Enter the default gateway provided by your ISP.
Page 126 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-103 PPPoEv6  PPP Username/Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive.  Authentication Type – Choose one authentication type from AUTO-AUTH, PAP, CHAP and MS-CHAP.
Page 127 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-104 Tunnel 6to4 This type is used in the situation that your WAN connection is IPv4 while LAN connection is IPv6. WAN Connection - Display the available wan connection.  Click the Save button to save your settings.
Page 128: System Tools
ARL02754U1 AC750 Wireless Dual Band Gigabit Router 4.21 System Tools Figure 4-106 The System Tools menu Choose menu “System Tools”, and you can see the submenus under the main menu: Time Settings, Diagnostic, Firmware Upgrade, Factory Defaults, Backup & Restore, Reboot, Password, System Log and Statistics.
Page 129 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Date - Enter your local date in MM/DD/YY into the right blanks.  Time - Enter your local time in HH/MM/SS into the right blanks.  Get From PC - Enter your PC’s current time into the right blanks.
Page 130 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-108 Time settings  Note: This setting will be used for some time-based functions such as firewall. You must specify your time zone once you login to the router successfully, otherwise, these functions will not take effect.
Page 131 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-109 Diagnostic Tools Diagnostic Tool - Check the radio button to select one diagnostic too.   Ping - This diagnostic tool troubleshoots connectivity, reachability, and name resolution to a given host or gateway.
Page 132: Firmware Upgrade
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Ping Timeout - Time to wait for a response, in milliseconds. The default is 800.   Traceroute Max TTL - Set the maximum number of hops (max TTL to be reached) in the path to search for the target (destination).
Page 133: Factory Defaults
ARL02754U1 AC750 Wireless Dual Band Gigabit Router  Hardware Version - Displays the current hardware version. The hardware version of the upgrade file must accord with the router’s current hardware version. To upgrade the router's firmware, follow these instructions below: Enter or select the path name where you save the upgrade file on the computer into the Firmware File Path blank.
Page 134: Backup And Restore
ARL02754U1 AC750 Wireless Dual Band Gigabit Router 4.21.5 Backup & Restore Choose menu “System Tools → Backup & Restore”, and then you can save the current configuration of the router as a backup file and restore the configuration via a backup file as shown in Figure 4-113.
Page 135: System Log
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Change the LAN IP Address (system will reboot automatically). • Upgrade the firmware of the router (system will reboot automatically). • Restore the router's settings to factory defaults (system will reboot automatically). •...
Page 136 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Log Type - By selecting the log type, only logs of this type will be shown.  Log Level - By selecting the log level, only logs of this level will be shown.
Page 137 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Statistics Interval （5-60） - The default value is 10. Select a value between 5 and 60  seconds in the drop-down list. The Packets Statistic interval indicates the time section of the packets statistic.
Page 138 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure 4-117 Logout - 130 -...
Page 139 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Appendix A: FAQ How do I configure the router to access Internet by ADSL users? First, configure the ADSL Modem configured in RFC1483 bridge model. Connect the Ethernet cable from your ADSL Modem to the WAN port on the router. The telephone cord plugs into the Line port of the ADSL Modem.
Page 140 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Login to the router, click the “Network” menu on the left of your browser, and click "WAN" submenu. On the WAN page, select “Dynamic IP” for "WAN Connection Type", finish by clicking “Save”.
Page 141 ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure A-4 Virtual Servers Figure A-5 Add or Modify a Virtual server Entry  Note: Your opposite side should call your WAN IP, which is displayed on the “Status” page. How to enable DMZ Host: Log in to the router, click the “Forwarding” menu on the left of your browser, and click "DMZ"...
Page 142: Appendix B: Configuring The Pc
ARL02754U1 AC750 Wireless Dual Band Gigabit Router How to enable H323 ALG: Log in to the router, click the “Security” menu on the left of your browser, and click “Basic Security” submenu. On the “Basic Security” page, check the Enable radio button next to H323 ALG. Remember to click the Save button.
Page 143 ARL02754U1 AC750 Wireless Dual Band Gigabit Router First make sure your Ethernet Adapter is working, refer to the adapter’s manual if needed. Install TCP/IP component On the Windows taskbar, click the Start button, point to Settings, and then click Control Panel.
Page 144: Appendix C: Specifications
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Figure B-3 Appendix C: Specifications General IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a, IEEE 802.11e, IEEE 802.11i, IEEE 802.1X, IEEE 802.3X, Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP, IGMPv3, L2TP, PPTP,...
Page 145: Appendix D: Glossary
ARL02754U1 AC750 Wireless Dual Band Gigabit Router Frequency Expansion DSSS (Direct Sequence Spread Spectrum) 11ac: 256-QAM for OFDM 11n/g/a: QPSK,BPSK,16-QAM, 64-QAM for OFDM Modulation 11b: CCK,DQPSK,DBPSK Security WEP, WPA/WPA2, WPA2-PSK/WPA-PSK 5G： 2.4G： 11a 6Mbps：-91dBm 11g 54M：-74dBm 11a 54Mbps：-74dBm 11n HT20：-72dmB Sensitivity @PER 11ac HT20：-66dBm...
Page 146 ARL02754U1 AC750 Wireless Dual Band Gigabit Router DHCP (Dynamic Host Configuration Protocol) - A protocol that automatically configure the  TCP/IP parameters for the all the PC(s) that are connected to a DHCP server. DMZ (Demilitarized Zone) - A Demilitarized Zone allows one local host to be exposed to the ...
