DISMANTLING INFORMATION for USE
by PROFESSIONAL RECYCLERS
ORIGINAL MANUAL ISSUE DATE: 2025.05
Model:
K-55XR5
K-65XR5
Conditions of Use:
(1) Please use this information only for the purpose of performing repair and recycling Sony products. Using this information
for any purpose other than the purpose described foregoing is forbidden.
(2) Do not copy, replicate, reproduce, alter, translate, transmit, sell, lease, or distribute this information in whole or in part
without the prior written permission of the author.
Revision of Information:
This information may be changed or updated at any time without any prior notice. Please confirm that this information is up-
to-date before using it.
K-75XR5
K-85XR5
K-98XR5
9-888-933-41
Sony EMCS (Malaysia) Sdn. Bhd. HES-M
LCD TV
© 2025
