AIR CONDITIONING SYSTEMS
MODEL
PUMY-SP100-140VKM2-PA, DA(-BS)
PUMY-SP100-140YKM2-PA, DA(-BS)
PUMY-CP100-140VKM2-PA, DA(-BS)
PUMY-CP100-140YKM2-PA(-BS)
PUMY-CP112-140VKM2-TH
PUMY-CP112-140YKM2-TH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CITY MULTI PUMY-SP100-140VKM2-PA and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Electric CITY MULTI PUMY-SP100-140VKM2-PA

Summary of Contents for Mitsubishi Electric CITY MULTI PUMY-SP100-140VKM2-PA

  • Page 1 AIR CONDITIONING SYSTEMS MODEL PUMY-SP100-140VKM2-PA, DA(-BS) PUMY-SP100-140YKM2-PA, DA(-BS) PUMY-CP100-140VKM2-PA, DA(-BS) PUMY-CP100-140YKM2-PA(-BS) PUMY-CP112-140VKM2-TH PUMY-CP112-140YKM2-TH...

  • Page 2: General Line-Up

    GENERAL LINE-UP GENERAL LINE-UP I.GENERAL LINE-UP Line-up of Outdoor Units of R410A CITY MULTI S-Series PUMY-SP100VKM2-PA, DA(-BS) PUMY-CP100VKM2-PA, DA(-BS) PUMY-SP100YKM2-PA, DA(-BS) PUMY-CP100YKM2-PA(-BS) PUMY-SP125VKM2-PA, DA(-BS) PUMY-CP112VKM2-TH PUMY-SP125YKM2-PA, DA(-BS) PUMY-CP112YKM2-TH PUMY-SP140VKM2-PA, DA(-BS) PUMY-CP125VKM2-TH PUMY-SP140YKM2-PA, DA(-BS) PUMY-CP125VKM2-PA, DA(-BS) PUMY-CP125YKM2-TH PUMY-CP125YKM2-PA(-BS) PUMY-CP140VKM2-TH PUMY-CP140VKM2-PA, -DA(-BS) PUMY-CP140YKM2-TH PUMY-CP140YKM2-PA(-BS) 4, 4.5, 5, 6HP...

  • Page 3: Table Of Contents

    CONTENTS S-Series PUMY-SP-YKM2, PUMY-SP-VKM2, PUMY-CP-YKM2, PUMY-CP-VKM2 I.S-Series 1. SPECIFICATIONS............................ 2 2. EXTERNAL DIMENSIONS ........................8 3. CENTER OF GRAVITY ..........................10 4. ELECTRICAL WIRING DIAGRAMS ......................11 5. SOUND LEVELS ............................17 6. OPERATION TEMPERATURE RANGE....................19 7. CAPACITY TABLES ..........................20 7-1.

  • Page 4: Specifications

    0.20 × 1 External static press. 0 Pa / 30 Pa Compressor Type × Quantity Twin rotary hermetic compressor × 1 Manufacturer Mitsubishi Electric Corporation Starting method Inverter Capacity control Cooling 29 to 100 Cooling 24 to 100 Cooling 21 to 100...
  • Page 5 0.20 × 1 External static press. 0 Pa / 30 Pa Compressor Type × Quantity Twin rotary hermetic compressor × 1 Manufacturer Mitsubishi Electric Corporation Starting method Inverter Capacity control Cooling 29 to 100 Cooling 24 to 100 Cooling 21 to 100...
  • Page 6 0.20 x 1 External static press. 0 Pa / 30 Pa Compressor Type × Quantity Twin rotary hermetic compressor × 1 Manufacture Mitsubishi Electric Corporation Starting method Inverter Capacity control Cooling 29 to 100 Cooling 24 to 100 Cooling 21 to 100...
  • Page 7 0.20 x 1 External static press. 0 Pa / 30 Pa Compressor Type × Quantity Twin rotary hermetic compressor × 1 Manufacture Mitsubishi Electric Corporation Starting method Inverter Capacity control Cooling 29 to 100 Cooling 24 to 100 Cooling 21 to 100...
  • Page 8 0.20 x 1 External static press. 0 Pa / 30 Pa Compressor Type × Quantity Twin rotary hermetic compressor × 1 Manufacture Mitsubishi Electric Corporation Starting method Inverter Capacity control Cooling 26 to 100 Cooling 24 to 100 Cooling 21 to 100...
  • Page 9 0.20 x 1 External static press. 0 Pa / 30 Pa Compressor Type × Quantity Twin rotary hermetic compressor × 1 Manufacture Mitsubishi Electric Corporation Starting method Inverter Capacity control Cooling 26 to 100 Cooling 24 to 100 Cooling 21 to 100...

  • Page 10: External Dimensions

    2. EXTERNAL DIMENSIONS S-Series 2. EXTERNAL DIMENSIONS PUMY-SP100, 125, 140VKM2-PA, DA(-BS) Unit: mm PUMY-SP100, 125, 140YKM2-PA, DA(-BS) M-P0881...
  • Page 11 2. EXTERNAL DIMENSIONS S-Series PUMY-CP100, 125, 140VKM2-PA, DA(-BS) / PUMY-CP112, 125, 140VKM2-TH Unit: mm PUMY-CP100, 125, 140YKM2-PA(-BS) / PUMY-CP112, 125, 140YKM2-TH M-P0881...

  • Page 12: Center Of Gravity

    3. CENTER OF GRAVITY S-Series 3. CENTER OF GRAVITY PUMY-SP100, 125, 140VKM2-PA, DA(-BS) PUMY-SP100, 125, 140YKM2-PA, DA(-BS) Unit: mm PUMY-CP100, 125, 140VKM2-PA, DA(-BS) / PUMY-CP112, 125, 140VKM2-TH PUMY-CP100, 125, 140YKM2-PA(-BS) / PUMY-CP112, 125, 140YKM2-TH M-P0881...

  • Page 13: Electrical Wiring Diagrams

    4. ELECTRICAL WIRING DIAGRAMS S-Series 4. ELECT RICAL WIR ING DIAGRAMS PUMY-SP100, 125, 140VKM2-PA, DA(-BS) PUMY-SP100VKM2-PA,DA PUMY-SP125VKM2-PA,DA PUMY-SP140VKM2-PA,DA M-P0881...
  • Page 14 4. ELECTRICAL WIRING DIAGRAMS S-Series PUMY-SP100, 125, 140YKM2-PA, DA(-BS) PUMY-SP100YKM2-PA,DA PUMY-SP125YKM2-PA,DA PUMY-SP140YKM2-PA,DA M-P0881...
  • Page 15 4. ELECTRICAL WIRING DIAGRAMS S-Series PUMY-CP100, 125, 140VKM2-PA, DA(-BS) PUMY-CP100VKM2-PA,DA PUMY-CP125VKM2-PA,DA PUMY-CP140VKM2-PA,DA M-P0881...
  • Page 16 4. ELECTRICAL WIRING DIAGRAMS S-Series PUMY-CP100, 125, 140YKM2-PA(-BS) M-P0881...
  • Page 17 4. ELECTRICAL WIRING DIAGRAMS S-Series PUMY-CP112, 125, 140VKM2-TH M-P0881...
  • Page 18 4. ELECTRICAL WIRING DIAGRAMS S-Series PUMY-CP112, 125, 140YKM2-TH M-P0881...

  • Page 19: Sound Levels

    5. SOUND LEVELS S-Series 5. SOUND LEVELS Measurement condition Sound level of PUMY-SP140VKM2-PA, DA(-BS)/PUMY-SP140YKM2-PA, DA(-BS) PUMY-SP100, 125, 140VKM2-PA, DA(-BS) Cool Silent1 PUMY-SP100, 125, 140YKM2-PA, DA(-BS) Silent Silent2 Heat NC-70 Microphone NC-60 NC-50 Unit NC-40 NC-30 1.5m Approximate minimum audible limit on NC-20 continuous noise Octave band central frequency (Hz)
  • Page 20 5. SOUND LEVELS S-Series Sound level of PUMY-CP125VKM2-PA, DA(-BS), -TH/PUMY-CP125YKM2-PA(-BS), -TH Measurement condition PUMY-CP100, 125, 140VKM2-PA, DA(-BS) Nomal Silent1 PUMY-CP112, 125, 140VKM2-TH Silent Silent2 PUMY-CP100, 125, 140YKM2-PA(-BS) PUMY-CP112, 125, 140YKM2-TH NC-70 Microphone NC-60 NC-50 Unit NC-40 NC-30 1.5m Approximate minimum audible limit on NC-20 continuous noise...

  • Page 21: Operation Temperature Range

    6. OPERATION TEMPERATURE RANGE S-Series 6. OPERATION TEMPERATURE RANGE PUMY-SP100, 125, 140VKM2-PA, DA(-BS) PUMY-SP100, 125, 140YKM2-PA, DA(-BS) • Cooling °FWB °CWB °CDB 104 113 °FDB Outdoor temperature * 10 to 52°CDB (50 to 126°FDB): When connecting following models such as PKFY-P15/20/25/32VLM-E, PFFY-P20/25/32VKM-E, PFFY-P20/25/32VLE(R)M(M)-E, PFFY-P20/25/32VCM-E, PEFY-P25/40/63/71VMA4-E, and M series, S series, and P series type indoor unit.

  • Page 22: Capacity Tables

    7. CAPACITY TABLES S-Series 7-1. Correction by temperature/total indoor 7. CAPACITY TABLES 7-1-1. Cooling capacity PUMY-SP100VKM2-PA, DA(-BS)/PUMY-SP100YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B.
  • Page 23 7. CAPACITY TABLES S-Series PUMY-SP100VKM2-PA, DA(-BS)/PUMY-SP100YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 24 7. CAPACITY TABLES S-Series PUMY-SP100VKM2-PA, DA(-BS)/PUMY-SP100YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 25 7. CAPACITY TABLES S-Series PUMY-SP100VKM2-PA, DA(-BS)/PUMY-SP100YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 26 7. CAPACITY TABLES S-Series PUMY-SP100VKM2-PA, DA(-BS)/PUMY-SP100YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 27 7. CAPACITY TABLES S-Series PUMY-SP125VKM2-PA, DA(-BS)/PUMY-SP125YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 28 7. CAPACITY TABLES S-Series PUMY-SP125VKM2-PA, DA(-BS)/PUMY-SP125YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 29 7. CAPACITY TABLES S-Series PUMY-SP125VKM2-PA, DA(-BS)/PUMY-SP125YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 30 7. CAPACITY TABLES S-Series PUMY-SP125VKM2-PA, DA(-BS)/PUMY-SP125YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 31 7. CAPACITY TABLES S-Series PUMY-SP125VKM2-PA, DA(-BS)/PUMY-SP125YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 32 7. CAPACITY TABLES S-Series PUMY-SP140VKM2-PA, DA(-BS)/PUMY-SP140YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 33 7. CAPACITY TABLES S-Series PUMY-SP140VKM2-PA, DA(-BS)/PUMY-SP140YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 34 7. CAPACITY TABLES S-Series PUMY-SP140VKM2-PA, DA(-BS)/PUMY-SP140YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 35 7. CAPACITY TABLES S-Series PUMY-SP140VKM2-PA, DA(-BS)/PUMY-SP140YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 36 7. CAPACITY TABLES S-Series PUMY-SP140VKM2-PA, DA(-BS)/PUMY-SP140YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B.
  • Page 37 7. CAPACITY TABLES S-Series PUMY-CP100VKM2-PA, DA(-BS)/PUMY-CP100YKM2-PA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Combination Outdoor Indoor air temp. air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B. 19°C W.B.
  • Page 38 7. CAPACITY TABLES S-Series PUMY-CP100VKM2-PA, DA(-BS)/PUMY-CP100YKM2-PA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Combination Outdoor Indoor air temp. air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B. 19°C W.B.
  • Page 39 7. CAPACITY TABLES S-Series PUMY-CP100VKM2-PA, DA(-BS)/PUMY-CP100YKM2-PA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Combination Outdoor Indoor air temp. air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B. 19°C W.B.
  • Page 40 7. CAPACITY TABLES S-Series PUMY-CP112VKM2-TH/PUMY-CP112YKM2-TH TC: Total Capacity (kW), PI: Power Input (kW) Combination Outdoor Indoor air temp. air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B. 19°C W.B.
  • Page 41 7. CAPACITY TABLES S-Series PUMY-CP112VKM2-TH/PUMY-CP112YKM2-TH TC: Total Capacity (kW), PI: Power Input (kW) Combination Outdoor Indoor air temp. air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B. 19°C W.B.
  • Page 42 7. CAPACITY TABLES S-Series PUMY-CP112VKM2-TH/PUMY-CP112YKM2-TH TC: Total Capacity (kW), PI: Power Input (kW) Combination Outdoor Indoor air temp. air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B. 19°C W.B.
  • Page 43 7. CAPACITY TABLES S-Series PUMY-CP125VKM2-TH/PUMY-CP125VKM2-PA, DA(-BS)/PUMY-CP125YKM2-TH/PUMY-CP125YKM2-PA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Combination Outdoor Indoor air temp. air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B. 19°C W.B.
  • Page 44 7. CAPACITY TABLES S-Series PUMY-CP125VKM2-TH/PUMY-CP125VKM2-PA, DA(-BS)/PUMY-CP125YKM2-TH/PUMY-CP125YKM2-PA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Combination Outdoor Indoor air temp. air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B. 19°C W.B.
  • Page 45 7. CAPACITY TABLES S-Series PUMY-CP125VKM2-TH/PUMY-CP125VKM2-PA, DA(-BS)/PUMY-CP125YKM2-TH/PUMY-CP125YKM2-PA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Combination Outdoor Indoor air temp. air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B. 19°C W.B.
  • Page 46 7. CAPACITY TABLES S-Series PUMY-CP140VKM2-TH/PUMY-CP140VKM2-PA, -DA(-BS)/PUMY-CP140YKM2-TH/PUMY-CP140YKM2-PA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Combination Outdoor Indoor air temp. air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B. 19°C W.B.
  • Page 47 7. CAPACITY TABLES S-Series PUMY-CP140VKM2-TH/PUMY-CP140VKM2-PA, -DA(-BS)/PUMY-CP140YKM2-TH/PUMY-CP140YKM2-PA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Combination Outdoor Indoor air temp. air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B. 19°C W.B.
  • Page 48 7. CAPACITY TABLES S-Series PUMY-CP140VKM2-TH/PUMY-CP140VKM2-PA, -DA(-BS)/PUMY-CP140YKM2-TH/PUMY-CP140YKM2-PA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Combination Outdoor Indoor air temp. air temp. 22°C D.B. 23°C D.B. 25°C D.B. 27°C D.B. 28°C D.B. 30°C D.B. 32°C D.B. 15°C W.B. 16°C W.B. 18°C W.B. 19°C W.B.

  • Page 49: Heating Capacity

    7. CAPACITY TABLES S-Series 7-1-2. Heating capacity PUMY-SP100VKM2-PA, DA(-BS)/PUMY-SP100YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 15°C D.B. 20°C D.B. 25°C D.B. 27°C D.B. °C D.B. -20.0 8.00 1.50 6.71 1.69 5.42 1.97 4.91...
  • Page 50 7. CAPACITY TABLES S-Series PUMY-SP100VKM2-PA, DA(-BS)/PUMY-SP100YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 15°C D.B. 20°C D.B. 25°C D.B. 27°C D.B. °C D.B. -20.0 7.75 1.67 6.50 1.89 5.25 2.20 4.75 2.35 -17.5 8.34...
  • Page 51 7. CAPACITY TABLES S-Series PUMY-SP100VKM2-PA, DA(-BS)/PUMY-SP100YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 15°C D.B. 20°C D.B. 25°C D.B. 27°C D.B. °C D.B. -20.0 4.65 1.09 3.90 1.23 3.15 1.43 2.85 1.53 -17.5 5.01...
  • Page 52 7. CAPACITY TABLES S-Series PUMY-SP125VKM2-PA, DA(-BS)/PUMY-SP125YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 15°C D.B. 20°C D.B. 25°C D.B. 27°C D.B. °C D.B. -20.0 10.23 2.23 8.58 2.51 6.93 2.93 6.27 3.13 -17.5 11.01...
  • Page 53 7. CAPACITY TABLES S-Series PUMY-SP125VKM2-PA, DA(-BS)/PUMY-SP125YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 15°C D.B. 20°C D.B. 25°C D.B. 27°C D.B. °C D.B. -20.0 9.92 2.53 8.32 2.86 6.72 3.32 6.08 3.56 -17.5 10.68...
  • Page 54 7. CAPACITY TABLES S-Series PUMY-SP125VKM2-PA, DA(-BS)/PUMY-SP125YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) Outdoor Indoor air temp. Combination air temp. 15°C D.B. 20°C D.B. 25°C D.B. 27°C D.B. °C D.B. -20.0 5.85 1.42 4.91 1.61 3.97 1.87 3.59 2.00 -17.5 6.30...
  • Page 55 7. CAPACITY TABLES S-Series PUMY-SP140VKM2-PA, DA(-BS)/PUMY-SP140YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) SP140 Outdoor Indoor air temp. Combination air temp. 15°C D.B. 20°C D.B. 25°C D.B. 27°C D.B. °C D.B. -20.0 10.64 2.29 8.93 2.59 7.21 3.01 6.53 3.23 -17.5...
  • Page 56 7. CAPACITY TABLES S-Series PUMY-SP140VKM2-PA, DA(-BS)/PUMY-SP140YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) SP140 Outdoor Indoor air temp. Combination air temp. 15°C D.B. 20°C D.B. 25°C D.B. 27°C D.B. °C D.B. -20.0 10.23 2.61 8.58 2.94 6.93 3.43 6.27 3.67 -17.5...
  • Page 57 7. CAPACITY TABLES S-Series PUMY-SP140VKM2-PA, DA(-BS)/PUMY-SP140YKM2-PA, DA(-BS) TC: Total Capacity (kW), PI: Power Input (kW) SP140 Outdoor Indoor air temp. Combination air temp. 15°C D.B. 20°C D.B. 25°C D.B. 27°C D.B. °C D.B. -20.0 6.49 1.53 5.44 1.73 4.40 2.01 3.98 2.16 -17.5...

  • Page 58: Correction By Refrigerant Piping Length

    7. CAPACITY TABLES S-Series 7-2. Correction by refrigerant piping length CITY MULTI systems can have extended piping lengths if certain limitations are followed, but cooling/heating capacity could be reduced. Using following correction factor by equivalent piping length shown at 7-2-1 and 7-2-2, capacity can be found. 7-2-3 shows how to obtain the equivalent piping length.

  • Page 59: Correction At Frost And Defrost

    7. CAPACITY TABLES S-Series 7-2-2. Heating capacity correction PUMY-SP100, 125, 140VKM2-PA, DA(-BS) PUMY-SP100, 125, 140YKM2-PA, DA(-BS) 1.00 0.95 0.90 0.85 0.80 0.75 0.70 0.65 0.60 0.55 0.50 Piping equivalent length (m) 7-2-3. How to obtain the equivalent piping length Equivalent length = (Actual piping length to the farthest indoor unit) + (0.30 x number of bends on the piping) m 7-3.

  • Page 60: Optional Parts

    8. OPTIONAL PARTS S-Series 8-1. JOINT 8. OPTIONAL PARTS CMY-Y62-G-E Unit: mm 1. Specification Items Details Number of ports 2 ports Main Number of branch joints One for each liquid and gas pipe Pipe material Phosphorus deoxidized copper C1220T-OL (JIS H3300) Insulation material Foamed polyethylene (one for each liquid and gas pipe) Accessory...

  • Page 61: Header

    8. OPTIONAL PARTS S-Series 8-2. HEADER Unit: mm CMY-Y64-G-E 1. Specification Items Details Number of ports 3 ~ 4 ports Main Number of branch joints One for each liquid and gas pipe Pipe material Phosphorus deoxidized copper C1220T-OL (JIS H3300) Insulation material Foamed polyethylene Accessory...

  • Page 62: Electrical Work

    9. ELECTRICAL WORK S-Series 9-1. General cautions 9. ELECTRICAL WORK Follow ordinance of your governmental organization for technical standard related to electrical equipment, wiring regulations, and guidance of each electric power company. Wiring for control (hereinafter referred to as transmission cable) shall be (50mm[1-5/8in.] or more) apart from power source wiring so that it is not influenced by electric noise from power source wiring.

  • Page 63: Power Supply For Outdoor Unit

    9. ELECTRICAL WORK S-Series 9-2. Power supply for Outdoor unit 9-2-1. Electrical characteristics of Outdoor unit at cooling mode Symbols: MCA (Max Circuit Amps =1.25 x Temperature correction x RLA) RLA (Rated Load Amps), SC (Starting Current) Units Power supply Compressor PUMY-SP-YKM2 RLA (A)

  • Page 64: Power Cable Specifications

    9. ELECTRICAL WORK S-Series 9-3. Power cable specifications PUMY-SP100, 125, 140VKM2-PA, DA(-BS) PUMY-SP100, 125, 140YKM2-PA, DA(-BS) Thickness of Wire for Main Power Supply and On/Off Capacities Minimum Wire Thickness (mm²) Breaker for Power supply Breaker for Current Leakage Model Wiring *1 Main Cable Ground When power is supplied...
  • Page 65 9. ELECTRICAL WORK S-Series PUMY-CP100, 112, 125, 140VKM2-PA, DA(-BS), -TH PUMY-CP100, 112, 125, 140YKM2-PA(-BS), -TH Thickness of Wire for Main Power Supply and On/Off Capacities Minimum Wire Thickness (mm²) Breaker for Power supply Breaker for Current Leakage Main Cable Ground Wiring *1 Model When power is supplied...

  • Page 66: Power Supply Examples

    9. ELECTRICAL WORK S-Series 9-4. Power supply examples The local standards and/or regulations is applicable at a higher priority. 9-4-1. PUMY-SP100, 125, 140YKM2-PA, DA(-BS) PUMY-CP100, 112, 125, 140YKM2-PA(-BS), -TH Note 1. The transmission cable is non-polarity two wires. PQRY 2. Symbol means a screw terminal.

  • Page 67: M-Net Control

    10. M-NET CONTROL S-Series 10-1. Transmission cable length limitation 10. M-NET CONTROL 10-1-1. Using MA Remote controller Long transmission cable causes voltage down, therefore, the length limitation should be obeyed to secure proper transmission. Max. length via Outdoor (M-NET cable) L1+L2+L3, L1+L2+L4+L5, L3+L4+L5 <=500m[1640ft] 1.25mm...

  • Page 68: 10-2.Transmission Cable Specifications

    10. M-NET CONTROL S-Series 10-2. Transmission cable specifications Transmission cables (Li) ME Remote controller cables MA Remote controller cables Type of cable Shielded cables (2-core) Shielded cables (2-core) VCTF, VCTFK, CVV, VVR, VVF, VCT CVVS, CPEVS, and MVVS CVVS, CPEVS, and MVVS Cable size Larger than 1.25 mm [AWG16], or...

  • Page 69: 10-3.System Configuration Restrictions

    10. M-NET CONTROL S-Series 10-3. System configuration restrictions 10-3-1. Common restrictions for the CITY MULTI system For each Outdoor/Heat source unit, the maximum connectable quantity of Indoor unit is specified at its Specifications table. A) 1 Group of Indoor units can have 1-16 Indoor units; *OA processing unit GUF-RD(H) is considered as Indoor unit.
  • Page 70 10. M-NET CONTROL S-Series Table 2 The equivalent power supply Category Model The equivalent power supply Transmission Booster PAC-SF46EPA-G 25 *1 Power supply unit PAC-SC51KUA Expansion controller PAC-YG50ECA BM ADAPTER BAC-HD150 AE-200E/AE-50E 0.75 System controller EW-50E LM-AP TB3 and TB7 total TB7 only TB3 only 32 *1-equivalent power...
  • Page 71 10. M-NET CONTROL S-Series 10-3-3. Ensuring proper power supply to System controller The power to System controller (excluding AE-200E, AE-50E, EW-50E, BAC-HD150, LM-AP) is supplied via M-NET transmission line. M-NET transmission line at TB7 side is called Centralized control transmission line while one at TB3 side is called Indoor-Outdoor/Heat source transmission line.
  • Page 72 10. M-NET CONTROL S-Series 10-3-4. Power supply to LM-AP 1-phase 220-240VAC power supply is needed. The power supply unit PAC-SC51KUA is not necessary when connecting only the LM-AP. Yet, make sure to change the power supply changeover connector CN41 to CN40 on the LM-AP. 10-3-5.

  • Page 73: 10-4.Address Setting

    10. M-NET CONTROL S-Series 10-4. Address setting 10-4-1. Switch operation In order to constitute CITY MULTI in a complete system, switch Rotary switch operation for setting the unit address No. and connection No. is Branch Unit address No. setting required. No.
  • Page 74 10. M-NET CONTROL S-Series 10-4-2. Rule of setting address Unit Address setting Example Note Use the most recent address within the same group of indoor units. Make the indoor units address connected to the BC controller (Sub) larger than the indoor units address connected to the BC controller (Main).

  • Page 75: System Example

    10. M-NET CONTROL S-Series 10-4-3. System example Factory setting Original switch setting of the outdoors, indoors, controllers, LM-AP and BM ADAPTER at shipment is as follows. Outdoor unit : Address: 00, CN41: ON (Jumper), DipSW2-1: OFF Indoor unit : Address: 00 ME Remote controller : Address: 101 LM-AP...
  • Page 76 10. M-NET CONTROL S-Series 10-4-3-3. Grouping in different refrigerant system Outdoor unit (PUMY) Group 1 Group 2 CN40 CN41 DipSW2-1 Outdoor unit (PUMY) Group 4 Group 3 CN40 CN41 DipSW2-1 NOTE It is necessary to change the connecter to CN40 on the outdoor unit (Heat source unit) control board (only one outdoor unit (Heat source unit)) when the group is set between other refrigerant systems.
  • Page 77 10. M-NET CONTROL S-Series 10-4-3-5. TG-2000A(*1)+AE-200E/AE-50E/EW-50E AE-200E can control max. 50 indoor units; TG-2000A can control max. 40 of AE-200E/AE-50E/EW-50E;*2 TG-2000A can control max. 2000 indoor units. Outdoor unit (PUMY) Group 1 Group 2 CN40 CN41 AE-200E DipSW2-1 CN21 Outdoor unit (PURY) Group 3 Group 4...
  • Page 78 10. M-NET CONTROL S-Series 10-4-3-6. AE-200E + AE-50E/EW-50E AE-200E can control max. 200 indoor units/via AE-50E/EW-50E. Outdoor unit (PUMY) AE-200E Group 1 Group 2 CN40 CN41 CN21 DipSW2-1 Outdoor unit (PURY) Group 3 Group 4 Group 5 CN40 CN41 BC controller DipSW5-1 Outdoor unit (PUMY)
  • Page 79 10. M-NET CONTROL S-Series 10-4-3-7. LM-AP Outdoor unit AE-200E (PUMY) Group 1 Group 2 CN21 CN40 CN41 DipSW2-1 LM-AP Outdoor unit CN40 CN41 (PURY) Group 3 Group 4 Group 5 DipSW1-2 BC controller CN40 CN41 DipSW5-1 Outdoor unit (PUMY) Group 1 Group 2 LM-AP CN40 CN41...
  • Page 80 10. M-NET CONTROL S-Series 10-4-3-8. BM ADAPTER BM ADAPTER can transmit for max. 50 indoor units; Change Jumper from CN41 to CN40 to activate power supply to BM ADAPTER itself for those BM ADAPTER connected without the power supply unit. Outdoor unit (PUMY) Group 1...
  • Page 81 10. M-NET CONTROL S-Series 10-4-3-9. BM ADAPTER+PAC-YG50ECA (Expansion controller) BM ADAPTER(*1) can transmit for max. 150 indoor units/via expansion controllers (PAC-YG50ECA). When the dual-set-point function is used, no expansion controllers can be connected, and only up to 50 units can be controlled from each BAC-HD150.
  • Page 82 10. M-NET CONTROL S-Series 10-4-3-10. B M ADAPTER+AE-200E/AE-50E/EW-50E BM ADAPTER can transmit for max. 50 indoor units. One BM ADAPTER is required for one AE-200E/AE-50E/EW-50E. BM ADAPTER BACnet ® CN40 CN41 <Three outdoor units> <Two outdoor units> <One outdoor unit> PUHY PUHY PUHY...

  • Page 83: Piping Design

    The maximum operation pressure of R410A air conditioner is 4.30 MPa [623psi]. The refrigerant piping should ensure the safety under the maximum operation pressure. MITSUBISHI ELECTRIC recommends pipe size as Table1, or You shall follow the local industrial standard. Pipes of radical thickness 0.7mm or less shall not be used.

  • Page 84: 11-2.Piping Design

    11. PIPING DESIGN S-Series 11-2. Piping Design 11-2-1. Use of the existing refrigerant piping Before operating the compressor, make sure the refrigerant pipes are properly installed. WARNING • Operating the compressor without the refrigerant pipes properly being connected and with the stop (ball) valve open, the compressor may suck in air, raising the pressure inside the refrigerant cycle abnormally high and resulting in pipe bursting and personal injury.
  • Page 85 11. PIPING DESIGN S-Series 11-2-2. PUMY-SP100, 125, 140YKM2-PA, DA(-BS)/PUMY-SP100, 125, 140VKM2-PA, DA(-BS) Line-Branch Method Connection Examples (Connecting to 4 Indoor Units) Outdoor Unit First Branch Indoor unit Permissible Total Piping Length A+B+C+a+b+c+d 120 m Length Farthest Piping Length A+B+C+d 70 m Farthest Piping Length After B+C+d 50 m First Branch...
  • Page 86 11. PIPING DESIGN S-Series Header-Branch Method Connection Examples (Connecting to 4 Indoor Units) Outdoor Unit First Branch Indoor unit Permissible Total Piping Length A+a+b+c+d 120 m Length Farthest Piping Length 70 m Farthest Piping Length After d is 50 meters or less First Branch Permissible High/Low Di erence in Indoor/...
  • Page 87 11. PIPING DESIGN S-Series Note: Pipe re-branching after the header branching is not possible. Method of Combined Branching of Lines and Headers Connection Examples (Connecting to 5 Indoor Units) Outdoor unit First branching (branching joint) Branching joint Indoor unit Branching header Blind caps Permissible Total Piping Length...
  • Page 88 11. PIPING DESIGN S-Series A:Outdoor unit B:Branching joint C:Branch box Branch box Method D:Indoor unit Connection Examples (Connecting to 8 Indoor Units) Total piping length A + B + C + a + b + c + d + e + f + g + h 120 m Farthest piping length (L) A + C + h...
  • Page 89 11. PIPING DESIGN S-Series A: Outdoor Unit B: First joint C: Branch header (CMY) D: Branch box E: CityMulti Indoor unit F: M/S/P series Indoor unit Mixed Method Connection Examples (Connecting to 1 Branch box) Total piping length A+B+C+D+E+a+b+c+d+e+f+g+h+i+j 120 m Farthest piping length (L1) A+E+a or A+B+C+e 70 m...
  • Page 90 11. PIPING DESIGN S-Series A: Outdoor Unit B: First joint C: Branch header (CMY) D: Branch box E: CityMulti Indoor unit F: M/S/P series Indoor unit Mixed Method Connection Examples (Connecting to 2 Branch boxes) Total piping length A+B+C+D+E+a+b+c+d+e+f+g+h+i+j+k 120 m Farthest piping length (L1) A+E+a 70 m...

  • Page 91: Additional Refrigerant Charge

    11. PIPING DESIGN S-Series 11-2-3. PUMY-CP100, 125, 140YKM2-PA(-BS)/PUMY-CP112, 125, 140YKM2-TH PUMY-CP100, 125, 140VKM2-PA, DA(-BS)/PUMY-CP112, 125, 140VKM2-TH A:Outdoor unit B:Branching joint C:Branch box D:Indoor unit Branch box Method Connection Examples (Connecting to 8 Indoor Units) Total piping length A + B + C + a + b + c + d + e + f + g + h 120 m Farthest piping length (L) A + C + h...
  • Page 92 11. PIPING DESIGN S-Series A: Outdoor Unit B: First joint C: Branch header (CMY) D: Branch box E: CityMulti Indoor unit F: M/S/P series Indoor unit Mixed Method Connection Examples (Connecting to 1 Branch box) Total piping length A+B+C+D+E+a+b+c+d+e+f+g+h+i+j 120 m Farthest piping length (L1) A+E+a or A+B+C+e 70 m...
  • Page 93 11. PIPING DESIGN S-Series Mixed Method Connection Examples (Connecting to 2 Branch boxes) Total piping length A+B+C+D+E+a+b+c+d+e+f+g+h+i+j+k 120 m Farthest piping length (L1) A+E+a 70 m Farthest piping length. Via Branch box (L2) A+B+C+k 80 m Piping length between outdoor unit and branch boxes A+B+C+D 55 m Permissible...

  • Page 94: 11-3.Refrigerant Charging Calculation

    11. PIPING DESIGN S-Series 11-3. Refrigerant charging calculation Additional refrigerant charge Refrigerant for the extended piping is not included in the outdoor unit when the unit is shipped from the factory. Therefore, charge each refrigerant piping system with additional refrigerant at the installation site. In addition, in order to carry out service, enter the size and length of each liquid pipe and additional refrigerant charge amounts in the spaces provided on the “Refrigerant amount”...

  • Page 95: Outdoor Installation

    12. OUTDOOR INSTALLATION S-Series 12-1. Requirement on installation site 12. OUTDOOR INSTALLATION 12-1-1. General caution A. Avoid locations exposed to direct sunlight or other sources of heat. B. Select a location from which noise emitted by the unit will not inconvenience the neighbors. C.
  • Page 96 12. OUTDOOR INSTALLATION S-Series 12-1-3. Foundation A. Be sure to install the unit in a sturdy, level surface to prevent rattling noises during operation. (see Fig. 12-1-3) B. Foundation specifications are as follows. mm [in.] Thickness of concrete Weight-bearing capacity Foundation bolt Bolt length 120 [4-3/4"]...

  • Page 97: 12-2.Spacing

    12. OUTDOOR INSTALLATION S-Series 12-2. Spacing 12-2-1. PUMY-SP100, 125, 140VKM2/YKM2 PUMY-CP100, 112, 125, 140VKM2/YKM2 PUMY-SP-VKM2/YKM2 or PUMY-CP-VKM2/YKM2 can connect indoor unit sized P15 to P140 and can connect totally 1-12 indoor (mm) units with total capacity ranged 50%-130% of the outdoor unit apacity. Connectable Indoor capacity Connectable Indoor unit PUMY-SP100VKM2/YKM2 , SP56-SP145...

  • Page 98: 12-3.Piping Direction

    12. OUTDOOR INSTALLATION S-Series 12-3. Piping direction PUMY-SP100, 125, 140VKM2/YKM2 PUMY-CP100, 112, 125, 140VKM2/YKM2 Front piping cover Piping cover Stop valve Service panel Bend radius: 100mm-150mm Strap Front piping Right piping Bottom piping M-P0881...
  • Page 99 - Doing so may cause the unit or pipes to burst, or result in explosion or fire during use, repair, or at the time of disposal of the unit. - It may also be in violation of applicable laws. - MITSUBISHI ELECTRIC CORPORATION cannot be held responsible for malfunctions or accidents resulting from the use of the wrong type of refrigerant.
