Summary of Contents for EURA 2 EASY VXA-62A5
- Page 1 GSM MODULE VXA-62A5 FOR 2-WIRE VIDEO DOORPHONE User Manual...
-
Page 2: Table Of Contents
The producer is not responsible for damages made during incorrect set-up or maintenan- ce or in case of any unassisted repairs or modifcations. TABLE OF CONTENTS 1. EURA 2 EASY SYSTEM DESCRIPTION ................3 2. DEVICE CHARACTERISTICS ....................3 3. DEVICE CONSTRUCTION ....................4 4. -
Page 3: Eura 2 Easy System Description
1. EURA 2 EASY SYSTEM DESCRIPTION 2-wire Eura 2 Easy system is a complete Video doorphone system designed to handle one or more apartments, where the minimum wiring with one centralized power supply drastically simplify and reduces installation time. With only 2 wires throughout the whole installation between each system components and one power supply, the system allows to connect up to 128 indoor monitor units and 4 outdoor video doorphone stations. -
Page 4: Device Construction
3. DEVICE CONSTRUCTION Fig. 2 presents elements of VXA-62A5. Fig. 3 presents LED and button placed on the device. Fig. 2. Construction of VXA-62A5 Fig. 3. LEDs and buttons Note After pressing Signal Quality key, 4 LEDs go off for a second, then the VXA-62A5 kits will use 4 LEDs to display signal strength: No signal: 4 LEDs off;... -
Page 5: Installation
SIM card slot, the place to Install SIM card Output Output port, connect to Monitor Input Input port, connect to power supply and Eura 2 Easy system (rail) - LED off When the VXA-62A5 not working Power - LED flashes rapidly when the system error... -
Page 6: Dip Switch Settings
Note There is a magnet installed in the antenna base. Therefore, the antenna should be installed on a ferromagnetic surface (pre-installed on the wall). Moreover, the antenna should be installed in an open space, with no obstacles around, to eliminate any causes for signal interference. -
Page 7: Settings At Button Operation Monitors
Fig. 5 6.2. SETTINGS AT BUTTON OPERATION MONITORS ▲/▼ Maximum 3 telephone numbers can be set in the device. Use Button to move upward ▲/▼ / downward to select the item, then press the MENU button to edit. Use Button to ►... -
Page 8: Wiring Diagrams
Add a letter "P" between master telephone and slave telephone.The VXA- telephone 48A5 will call the slave telephone directly Tab. 3 8. WIRING DIAGRAM Fig. 7 shows the wiring diagrams to connect VXA-62A5 module to the Eura 2 Easy. antenna VXA-62A5 VZA-57A5 ID=00... -
Page 9: Technical Data
9. TECHNICAL DATA Power input 20~28V DC (supplied by VZA-55A5) Power consumption (standby / working) 0,78W / 2,08W Working temperature -10°C…+40°C Wiring 2 (non-polarity) Waterproof rating IP20 Dimensions (H x W x D) 90 x 72 x 60 (mm) - Page 10 EU Conformity Declaration of this device is available on http://www.eura-tech.eu website Eura-Tech Sp. z o.o. ul. Przemysłowa 35A, 84-200 Wejherowo, POLAND www.eura-tech.eu All rights reserved. Pictures, graphs and texts are the property of “Eura-Tech” Sp. z o.o. Copying, distributing and publication without permission of author is forbidden.
