VICTRIX
SUPERIOR
35 PLUS
IE
Instructions and
recommendations
Installer
User
Maintenance technician
Technical Data

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VICTRIX SUPERIOR 35 PLUS and is the answer not in the manual?

Questions and answers

Related Manuals for Immergas VICTRIX SUPERIOR 35 PLUS

Summary of Contents for Immergas VICTRIX SUPERIOR 35 PLUS

  • Page 1 VICTRIX SUPERIOR Instructions and 35 PLUS recommendations Installer User Maintenance technician Technical Data...

  • Page 2: Table Of Contents

    1.12 External temperature probe (Optional)..............................25 1.13 Temperature control setting ..................................25 1.14 General examples of types of installation of flue systems ........................27 1.15 Immergas flue systems ....................................28 1.16 Maximum flue length ....................................30 1.17 Equivalent lengths of "Green Range" flue system components......................31 1.18 Outdoor installation or in a partially protected area ..........................37...
  • Page 3 4.2 Combustion parameters ..................................151 4.3 Technical data table ....................................152 Technical parameters for combination boilers (in compliance with Regulation 813/2013) .............153 4.5 Product fiche (in compliance with Regulation 811/2013) ........................154 Parameters for filling in the package fiche .............................155 ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 4: Dear Customer

    Congratulations for having chosen a top-quality Immergas product, able to assure well-being and safety for a long period of time. As an Im- mergas customer you can also count on a Qualified Authorised After-Sales Technical Assistance Centre, prepared and updated to guarantee the constant efficiency of your products.

  • Page 5: General Recommendations

    Law. • Improper installation or assembly of the Immergas device and/or components, accessories, kits and devices can cause unex- pected problems for people, animals and objects. Read the instructions provided with the product carefully to ensure proper installation.

  • Page 6: Safety Symbols Used

    DISPOSAL WARNING The user must not dispose of the appliance at the end of its service life as municipal waste, but send it to appropriate collection centres. PERSONAL PROTECTIVE EQUIPMENT SAFETY GLOVES EYE PROTECTION SAFETY FOOTWEAR ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 7: Unit Installation

    This appliance has been designed for wall mounted installation only, for central heating and production of domestic hot water for domestic use and similar purposes. The place of installation of the appliance and relative Immergas accessories must have suitable features (technical and structur- al), such as to allow for (always in safe, efficient and comfortable conditions): - installation (according to the provisions of technical legislation and technical regulations);...
  • Page 8 Packing materials (staples, nails, plastic bags, polystyrene foam, etc.) constitute a hazard and must be kept out of the reach of children. If the appliance is installed inside or between cabinets, ensure sufficient space for routine servicing; for minimum installation distances, see Fig. 6. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 9 They must be connected to a central heating system and domestic hot water circuit suited to their performance and capacity. The storage tank unit, if present, must also be installed in an environment in which the temperature cannot fall below 0°C. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 10 After a few minutes of operation, check that combustion flue gases are no longer coming out of the condensate drain; this means that the drain trap has filled to a correct condensate height that the flue gases cannot pass through. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 11 Install the appliances in B and B configuration in non-residential premises and which are permanently ventilated. Failure to comply with the above implies personal responsibility and invalidates the warranty. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 12: Data Nameplate And Installation Information Sticker

    DATA NAMEPLATE AND INSTALLATION INFORMATION STICKER 1.2.1 Data nameplate positioning Key (Fig. 2): Data plate ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 13: Key For Data Nameplate

    At the time of installation, the authorised technician must fill in the facsimile of the installation information sticker (Fig. 4) with the information indicated. This sticker is inside the warranty group, it must also be filled out and applied on the outside of the appliance (in visible position) (see paragraph 3.2 Initial check). ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 14: Main Dimensions

    Condensate drain (minimum internal diameter Ø 13 mm) Electrical connection System return Gas supply System flow Storage tank unit return Storage tank unit flow Height (mm) Width (mm) Depth (mm) TEMPLATE CONNECTIONS SYSTEM DOMESTIC HOT WATER MU-RU 3/4" 3/4" 3/4" 1/2" ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 15: Minimum Installation Distances

    - The materials used for the central heating circuit of Immergas appliances resist propylene glycol based antifreeze liquids (if the mix- tures are prepared perfectly).
  • Page 16 (carefully read the installation instructions in the ac- cessory kit pack). In the previously listed conditions ad with the addition of the antifreeze kit, the appliance is protected against freezing up to a temperature of -15°C. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 17: Appliance Connection Unit

    3/4" storage tank unit flow Ø 18 copper pipe System filling 1/2" Cycloidal filter copper pipe 3/4” system return Cycloidal filter copper pipe 3/4” System flow Cycloidal filter unit Condensate drain (minimum internal diameter Ø13 mm) ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 18: Gas Connection

    (i.e. downstream from the pipes connecting the system to the appliance), according to the manufacturer’s instructions. The Immergas connection unit, supplied as an optional kit, also includes the gas isolation valve, whose installation instructions are provided in the kit.

  • Page 19: Hydraulic Connection

    In order to meet the system requirements established by EN 1717 in terms of pollution of drinking water, we recommend installing the IMMERGAS anti-backflow kit to be used upstream of the cold water inlet connection of the appliance. We also recommend using cate- gory 2 heat transfer fluid (e.g.: water+ glycol) in the appliance's primary circuit (C.H.

  • Page 20: Cyclonic Filter Unit

    7. Open the two shut-off valves and restore power to the appliance to bring it back to normal operating conditions; at the same time check the operating pressure of the appliance and, if necessary, restore it to a correct value. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 21 Key (Fig. 10): System return Key (Fig. 11): Flat gaskets Return connection pipe Interception valve Cyclonic filter System flow connection pipe ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 22: Electrical Connection

    To carry out electrical connections, all you have to do is open the connections compartment as follows. 1. Remove the front panel (Fig. 87 - 88) 2. Loosen the screws (a). 3. Remove the cover (b) from the control panel (c). ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 23 55°C in series with the appliance power supply. Execute connection to terminal boards 14 and 15, eliminating link X70 (Fig. 70). The thermostat must be positioned on the system flow pipe at a distance of at least 2 metres from the appliance. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 24: Remote Controls And Room Chrono-Thermostats (Optional)

    1.11 REMOTE CONTROLS AND ROOM CHRONO-THERMOSTATS (OPTIONAL) The appliance is set up for room chrono-thermostats or remote controls, available as optional kits. All Immergas chrono-thermostats are connected with 2 wires only. Carefully read the user and assembly instructions contained in the accessory kit.

  • Page 25: External Temperature Probe (Optional)

    The external probe always operates when connected, regardless of the presence or type of room chrono-thermostat used and can work in combination with Immergas chrono-thermostats and wireless room probes. If wireless room probes are used, it is possible to activate or deactivate the action of the external probe for each individual zone in use, by acting on the parameter in the zone menu.
  • Page 26 = NO Key (Fig. 15, 16) External temperature Flow temperature Maximum flow set Minimum flow set* Minimum external temperature* Maximum external temperature * Climatic curve offset * Functions reserved for Service ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 27: General Examples Of Types Of Installation Of Flue Systems

    A second pipe is provided for the intake of combustion air from outside. Appliance connected, through a ducted exhaust pipe, to a vertical terminal. The exhaust pipe, by means of the cavity, also acts as a combustion air intake pipe. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 28: Immergas Flue Systems

    These solutions form an integral part of the product. The appliance must be installed with an original Immergas "Green Range" inspectionable air intake system and flue gas extrac- tion system made of plastic, with the exception of configuration C in the configurations envisaged in Parag.
  • Page 29 When installing horizontal pipes, a minimum inclination of 5% towards the appliance must be maintained, and a section clamp with plug must be installed every 3 metres. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 30: Maximum Flue Length

    "Length equivalent to m of pipe" in the table in par. 1.17, and check that the resulting sum is equal to or less than the maximum length (L max) indicated in par. 1.16. (L ≤ L max). For further information on functional check calculations of any flue configuration, consult the Immergas website of your country or contact the indicated Customer Service.

  • Page 31: Equivalent Lengths Of "Green Range" Flue System Components

    Reduction kit from Ø 60/100 to 80/125 Ø 80/125 mm Horizontal terminal Ø 80/125 mm L = 0,75 m Horizontal terminal Ø 80/125 mm L = 1 m Vertical terminal Ø 80/125 mm L = 1 m ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 32 L = 1,25 m Pipe Ø 80/125 mm L = 1 m 90° bend Ø 80/125 mm 45° bend Ø 80/125 mm Reduction kit from Ø 60/100 to Ø 80/125 mm Thermoformed kit for type B Intake installation ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 33 Pipe Ø 80/125 mm L = 1 m 90° bend Ø 80/125 mm 45° bend Ø 80/125 mm Reduction kit from Ø 60/100 to Ø 80/125 mm Suction kit Ø 80 mm for configura- Intake tion B ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 34 Horizontal terminal Ø 80 mm grid part Intake Pipe Ø 60/100 mm Exhaust L = 1 m 90° bend Ø 60/100 mm Exhaust 45° bend Ø 60/100 mm Exhaust Suction kit Ø 80 mm for configura- Intake tion B ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 35 Intake Pipe Ø 80/125 mm L = 1 m 90° bend Ø 80/125 mm 45° bend Ø 80/125 mm Reduction kit from Ø 60/100 to Ø 80/125 mm Suction kit Ø80 mm for configuration Intake ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 36 Exhaust 90° bend Ø 80 mm Intake (10)3 (12)3 80/80 Exhaust 45° bend Ø 80 mm Intake Horizontal terminal Ø 80 mm L = 1 m Intake Horizontal terminal Ø 80 mm grid part Intake ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 37: Outdoor Installation Or In A Partially Protected Area

    - the flue gas exhaust must be connected to its own single chimney (B ) or ducted directly outside via a vertical terminal for direct ex- haust (B ) or via an Immergas ducting system (B The technical regulations in force must be respected. Cover kit assembly (Fig. 20).

  • Page 38: Concentric Horizontal Kit Installation

    Make sure that the external silicone wall sealing plate is properly inserted in the wall. For correct functioning of the system the terminal with grid must be installed correctly ensuring that, the "high" indication present on the terminal is respected on installation. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 39 Flanged 90° concentric elbow Ø60/100 (do not consider Lmax - Maximum length when calculating the equivalent length) The maximum lengths ((L max) of the various flues that can be installed are given in the summary table in parag. 1.16. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 40 L = T1 + C2 + T2 + C3 + TS L = T1 + C4 + TS Calculation example (VICTRIX SUPERIOR 35 PLUS): L = 1 + 1 + 1 + 1 + 1 = 5 m 5 m ≤ 13 m L ≤...
  • Page 41 Ø80/125 90° concentric elbow Lmax - Maximum length Concentric pipe Ø80/125 Concentric pipe Ø80/125 The maximum lengths ((L max) of the various flues that can be installed are given in the summary table in parag. 1.16. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 42 L = A1 + C1 + T1 + C4 + TS L = A1 + C1 + T1 + C2 + T2 + C3 + TS Calculation example (VICTRIX SUPERIOR 35 PLUS): L = 0,5 + 1,4 + 1 + 1,4 + 1 = 5,3 m 5,3 m ≤...

  • Page 43: Concentric Vertical Kit Installation

    The kit includes (Fig. 28): N°1 Gasket (1) N°1 Female concentric flange (2) N°1 Wall sealing plate (3) N°1 Aluminium slate (4) N°1 Concentric intake/exhaust pipe Ø 60/100 (5) N°1 Fixed half-shell (6) N°1 Mobile half-shell (7) ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 44 1.16. Key Fig. 29: Concentric pipe Ø60/100 Concentric intake / exhaust terminal Ø 60/100 Equivalent length Lmax - Maximum length L = T1 + Ts L ≤ L max ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 45 L = T1 + C1 + T2 + C4 + TS L = C2 + T1 + C3 + TS Calculation example (VICTRIX SUPERIOR 35 PLUS): L = 1 + 1,3 + 1 + 1,3 + 1,25 = 5,85 m 5,85 m ≤...
  • Page 46 1.16. Key Fig. 32: Flanged adapter Ø80/125 Concentric pipe Ø80/125 Concentric intake / exhaust terminal Ø80/125 Equivalent length Lmax - Maximum length L = A1 + T1 + Ts L ≤ L max ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 47 L = A1 + T1 + C1 + T2 + C4 + TS L = A1 + C2 + T1 + C3 + TS Calculation example (VICTRIX SUPERIOR 35 PLUS): L = 0,5 + 1 + 1,4 + 1 + 1,4 + 1 = 6,3 m 6,3 m ≤...

  • Page 48: Installation Of Vertical Terminals Ø 80

    The 80 Ø steel terminal is used to install the boiler outdoors with a direct exhaust. The terminal cannot be shortened and once it is in- stalled it will extend out by 1000 mm (Fig. 38). The Kit includes (Fig. 37): N°1 Steel exhaust terminal Ø 80 (1) ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 49: Separator Kit Installation

    N°1 Intake terminal Ø 80 (6) N°2 Internal wall sealing plates (7) N°1 External wall sealing plate (8) N°1 Exhaust pipe Ø 80 (9) For technical data concerning the C configuration, please refer to the table in par. 4.2. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 50 Equivalent length Intake terminal Ø80 L max - Maximum length Pipe Ø80 Pipe Ø80 The maximum lengths ((L max) of the various flues that can be installed are given in the summary table in parag. 1.16. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 51 L = L1 + C1 + C2 + L2 = (TA + T1) + C1 + C2 + (T2 + T3 + T4 + T5) Calculation example (VICTRIX SUPERIOR 35 PLUS): L = (2,5 + 0,7) + 1,6 + 2,1 + (1 + 1 +1 + 1) = 10,9 m 10,9 m ≤...

  • Page 52: Adaptor Kit Installation C

    1.23 ADAPTOR KIT INSTALLATION C This kit allows an Immergas appliance to be installed in C configuration, with combustion air intake directly from the shaft where the flue gas exhaust is, obtained by means of a ducting system. System composition...
  • Page 53 Maximum 2 changes of direction are allowed on the vertical section of the flue system with a maximum clearance angle of 30° with re- spect to the vertical. The maximum lengths ((L max) of the various flues that can be installed are given in the summary table in parag. 1.16. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 54: Ducting Of Flues Or Technical Slots

    Ø 50 Flexible T terminal kit 0,16 Ø80/125 vertical terminal kit 0,48 Ø60 Rigid Concentric vertical terminal kit Ø60 0,49 Ø 80 flexible Ø80/125 vertical terminal kit 0,48 Ø80 rigid Concentric vertical terminal kit Ø80 0,65 ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 55: Configuration Cconcentric Kit

    1.25 CONFIGURATION C CONCENTRIC KIT (15)3 Installation in C configuration of an Immergas appliance, (15)3 (15)3 makes it possible to extract combustion air directly from the shaft where the flue gas exhaust is present in the dedicated flue. Information for C...

  • Page 56: Configuration Cconcentric Kit (Ø 80/125)

    (Fig.48). Installation in C configuration of an Immergas appliance (only (10)3 (10)3 permitted with type-approved original flue, including the specific...
  • Page 57 12. Carry out the quick calibration procedure (Par.3.13). Once all components have been assembled properly, the exhaust flue gas will be expelled in the collective flue, the combustion air for normal appliance operation will be aspirated directly by the shaft (Fig. 45). ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 58 Non-return valve on flue gas (do not consider when calcu- L max - Maximum length lating the equivalent length) 90° elbow Ø80/125 The maximum lengths ((L max) of the various flues that can be installed are given in the summary table in parag. 1.16. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 59 The Ø 80/125 extension pipe kit includes: (kit Ø 80/125) Concentric gasket (15) Extension pipe unit Ø 80/125 (10) Supplied separately (Fig. 51): No.1 Ducting kit door (A) The bend kit Ø 80/125 includes: Concentric bend Ø 80/125 at 87° (11) ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 60: Configuration Cseparator Kit (Ø 80/80)

    C installations, the appliance flue exhaust must be fitted with a (10)3 (12)3 flue gas non-return valve kit, supplied by Immergas as an optional, consisting of the valve itself with instructions and relative sticker with additional safety information (Fig.48). (10)3 (12)3 ST.006205/002...
  • Page 61 (using knobs "Set DHW" and " Set CH") and press "Ok" after which, the "Menu access level" menu will open, where you will need to select the type of access:"Service". 10. Refer to the path Menu/Service/Boiler/Flue 11. At item -Enable Klapet valve-, set "Yes". 12. Carry out the quick calibration procedure (Par.3.13). ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 62 No.2 Bend 90° Ø 80 (5) - 1 Non-return valve on flue gas Ø 80 (10c) Extension Ø 80 (6) (only C (10)3 N.B.: remove extension Ø 125 Intake terminal Ø 80 (6) (only C (12)3 ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 63 Equivalent length Intake terminal Ø80 L max - Maximum length Pipe Ø80 Pipe Ø80 The maximum lengths ((L max) of the various flues that can be installed are given in the summary table in parag. 1.16. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 64 , which con- (10)3 (12)3 tains the additional exhaust flue gas non-return valve, necessary for the pressurised collective flues. It is advisable to affix the sticker in a clearly visible position on the front casing. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 65 Summary table of information for C installations (Only Methane 2E - 2H) (10)3 VICTRIX SUPERIOR 35 PLUS Qmin Qn max Heat input 34,0 % of reference [%] Maximum boiler outlet pressure Minimum boiler outlet pressure C -200 -200 (10)3 Minimum boiler outlet pressure C...

  • Page 66: Configuration For Cflue Installation

    - The maximum permissible percentage of flue gas recirculation in windy conditions is 10%; - Suction and exhaust pipes cannot be installed on opposing walls; - With flues in configuration C discharge into pressurised flues is not permitted. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 67: Configuration Type B, Open Chamber And Fan Assisted For Indoors

    It is possible to replace a type C conventional device with one provided with condensation, connected to multiple flues, only if the deroga- tion conditions established by the regulations in force have been met. The flues, chimneys and chimney caps for the evacuation of combustion products must be in compliance with applicable standards. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 68: Flues, Chimneys And Chimney Caps

    In spaces closed on all sides with open tops (ventilation pits, courtyards etc.), direct combustion product exhaust is allowed for natural draught or fan assisted gas appliances with a heat input range from 4 to 35 kW, provided the conditions as per the current technical stand- ards are respected. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 69: Water Treatment Plant Filling

    Key (Fig. 58): Total water hardness °F Litres of system water For quantities and methods of use of water-treatment products, refer to the instructions provided by their manufacturer. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 70: System Filling

    - open windows and doors; - avoid presence of sparks or naked flames; - bleed all air from pipelines; - ensure the internal system is properly sealed according to the specifications set forth by technical regulations in force. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 71: Appliance Start-Up (Ignition)

    12. ensure that the safety device intervenes in the event of gas supply failure and check the relative intervention time; 13. Check the activation of the main switch located upstream of the appliance and in the appliance. Even if just one single safety check provides a negative result, do not commission the system. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 72: Upm3 Circulation Pump

    Adjust using a flat head screwdriver, turn clockwise and open the by-pass, anticlockwise it is closed. The bypass ensures minimum circulation of the water in the appliance and its correct operation in case of systems with shut-off components or external hydraulic adjustments. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 73: Upm4 Circulation Pump

    Adjust using a flat head screwdriver, turn clockwise and open the by-pass, anticlockwise it is closed. The bypass ensures minimum circulation of the water in the appliance and its correct operation if the systems are divided into more than one zone. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 74: Kits Available On Request

    The data of the graph(s) above include the cyclonic filter, which is standard in these models. 1.39 KITS AVAILABLE ON REQUEST Check the complete list of kits available and which can be combined with the product, consult the Immergas website, the Im- mergas Price List or the technical-commercial documentation (catalogues and data sheets).

  • Page 75: Main Components

    Flue gas sampling cap with pres- Storage tank flow manifold Safety valve drain pipe sure point System shut-off valve Bypass pipe Heat exchanger Storage tank return pipe Burner gas manifold Module gasket Ignition glow plug Fan gasket Fan assembly ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 76: Instructions For Use And Maintenance

    In the event of malfunctions, faults or incorrect operation, turn the appliance off and contact an authorised company (e.g. the Authorised Technical Assistance Centre, which has specifically trained staff and original spare parts). Do not attempt to modify or repair the appliance alone. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 77 At the end of its service life, the appliance must not be disposed of like normal household waste nor abandoned in the environment, but must be removed by a professionally authorised com- pany as required by current legislation. Contact the manufacturer for disposal instructions. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 78: Cleaning And Maintenance

    “Set central heating / C.H.” knob. Zones area (number and information of zone in use). Selection confirmation/ok button. Operating mode. Menu button. Anomaly code/flow temperature display. Anomalies/esc. reset button. System general icon display. “Set DHW (Domestic hot water)” Knob. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 79: Using The Appliance

    Protection function Operating mode Description Central heating (Antifreeze...) Disabled Disabled Disabled Summer (*) Enabled Disabled Activated Winter Enabled Enabled Activated Stand-by Disabled Disabled Activated (*) When the appliance is connected with an external storage tank unit. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 80: Operating Mode

    Display operation Below is a description of how to use the control panel, including: - Enter the menus; - Moving in the menus; - Set a menu item; - Confirming a change; - Exit without saving. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 81 2020 YEAR • Automatic summer time Time and program / Auto switch to DST The automatic adaptation of the time can be enabled or disabled when changing from winter to summer time (and vice versa). ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 82 • Holiday program. Time and program / Holiday program If required, it is possible to pause system operation for an established period. Both the DHW (Domestic hot water) control and central heating / C.H. are stopped. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 83: Dhw Mode

    If the anti-legionella function is activated (disabled as a standard), the temperature inside the storage tank is brought to 65°C for 30 min- utes. Water at temperatures above 50°C can cause severe burns. When the anti-legionella function is activated, always check the water temperature before any use. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 84: Central Heating Mode

    With the external probe connected, the flow setpoint for room central heating / C.H. is managed by the system depending on the external temperature measured (Par.1.12). It is possible to enable thermal adjustment for each individual zone. The symbol is present if the probe is connected and working. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 85 The wireless room probe (with concentrator) allows the measurement of the room temperature and sending of this value to the appli- ance control panel where possible, via the display board, set a weekly program for the room temperature control. There is no manual command or adjustment of the room control on the probe. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 86 Adjustment of the central heating system flow temperature Acting directly on the "Set central heating" knob, you may set the value ' A ' (Fig. 15) by setting the flow temperature to the system with ac- tive request. No external probe ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 87 The presence of the jumper on the TA contact is required when the central heating / C.H. demand needs to be checked using only CAR ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 88: Parameters And Information Menu

    = Auto" is selected) Sets manual set (manual set will be active 24 hours a day if "Set manage- Set manual 10 ÷ 60 °C 10°C ment = Man" is selected) (*) See the DHW paragraph (Parag.2.6). ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 89 The following tables will appear the same also for any Zone 2 and Zone 3. ZONES/Zone 1 Menu item Description Information This displays the system operating data Settings Defines the operating parameters to manage zone 1 Definition Defines any further operating parameters to manage zone 1 ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 90 - if closed, it will go in combination with the appliance programming. • Central heating / C.H. set - info on the actual active set in real time (depends on the central heating / C.H. programming or any external probe). ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 91 - the external probe is present - the parameter "Function Mode" is set at "Auto" or "Off" lack or - a room probe is configured unavailability of room probes - the "Enable room sensor" parameter is set to "Yes" ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 92 Holiday program heating and room central heating functions. At the end of the set days, Day/s the previously active functions will be reset. (*) When the appliance is connected with an external storage tank unit. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 93 This displays the boiler anomaly history. The size of the anomaly history is equal to 10 anomalies and they are displayed in Show alarm decreasing order of appearance (no.1 is the most recent). The displayed anomalies are accompanied by the time and date of the anomaly being generated. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 94 In case the user restores the factory conditions through "Menu/General settings/User factory settings", the menu will appear in Eng- lish. Proceed in the following way to restore the desired display language: - Enter Menu/General setting/Language. - Select the desired language from those available and press OK. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 95: Fault And Anomaly Signals

    (1) If the shutdown or fault persists, contact an authorised company (e.g. Authorised Service Centre) (2) The anomaly can only be verified in the list of errors in the “Information” menu (3) Error displayed only on CAR ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 96 (1) If the shutdown or fault persists, contact an authorised company (e.g. Authorised Service Centre) (2) The anomaly can only be verified in the list of errors in the “Information” menu (3) Error displayed only on CAR ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 97 (1) If the shutdown or fault persists, contact an authorised company (e.g. Authorised Service Centre) (2) The anomaly can only be verified in the list of errors in the “Information” menu (3) Error displayed only on CAR ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 98 (1) If the shutdown or fault persists, contact an authorised company (e.g. Authorised Service Centre) (2) The anomaly can only be verified in the list of errors in the “Information” menu (3) Error displayed only on CAR ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 99 (1) If the shutdown or fault persists, contact an authorised company (e.g. Authorised Service Centre) (2) The anomaly can only be verified in the list of errors in the “Information” menu (3) Error displayed only on CAR ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 100 (1) If the shutdown or fault persists, contact an authorised company (e.g. Authorised Service Centre) (2) The anomaly can only be verified in the list of errors in the “Information” menu (3) Error displayed only on CAR (*) Errors visible below zone area icons. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 101 The reset of the error signal (following a solving operation) can take up to 10 minutes. It is recommended to “force” the commu- nication between the probe and concentrator by briefly pressing the probe button; in this way the RF communication between the two devices will be forced and the error signal will be quickly cancelled. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 102: Appliance Switch-Off

    2.13 ANTIFREEZE PROTECTION The appliance has an antifreeze function that switches the burner on automatically when the temperature drops below 4°C (standard protection to minimum temperature of -5°C). ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 103: Prolonged Inactivity

    In order to guarantee the integrity of the appliance and the domestic hot water heating system in areas where the temperature drops be- low zero, we recommend protecting the central heating system using anti-freeze liquid and installing the Immergas Antifreeze Kit in the appliance.

  • Page 104: Instructions For Maintenance And Initial Check

    The device’s warranty shall be rendered null and void if unapproved or unsuitable parts are used for maintenance or repairs. These will also compromise the product’s compliance, and the said product may no longer be valid and fail to meet the current regulations. in regard to the above, only use original Immergas spare parts when replacing components. ST.006205/002...

  • Page 105: Initial Check

    - check the tightness of the hydraulic circuits; - check ventilation and/or aeration of the installation room where provided. Even if just one single safety check provides a negative result, do not commission the system. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 106: Yearly Appliance Check And Maintenance

    If the flue gas non-return valve in the flues must be removed to inspect and clean it, temporarily plug the exhaust pipe connected to the collective flue. This prevents the return of fumes from the other appliances connected to the flue itself. Victrix Superior 35 Plus Gas type to Nominal Q.
  • Page 107 When adjusting nominal heat input, if the O values are not reached with the gas flow regulator completely open, no further adjustments are required. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 108: Hydraulic Diagram

    3 bar safety valve drain fitting signal Cycloidal filter unit shut-off valves System flow shut-off valve Cycloidal filter unit Gas supply Storage tank unit return Storage tank unit flow System filling Condensate drain RU MU System flow System return ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 109: Wiring Diagram

    TECHNICAL DATA MAINTENANCE TECHNICIAN USER INSTALLER...
  • Page 110 TECHNICAL DATA MAINTENANCE TECHNICIAN USER INSTALLER Key (Fig. 70): Key (Fig. 70): Colour code key (Fig. 70): Removable memory 230 Vac 50Hz Power supply Black Flow probe Wireless room probes (optional) Blue B1-2 System flow probe (optional) Wireless concentrator (optional) Brown Boiler probe (optional) Display board...

  • Page 111: Removable Memory

    Dominus and timer maintenance. Should the display board be replaced, you can use the memory of the replaced board again so it is not necessary to reconfigure the appli- ance. Key (Fig. 72): Black removable memory (A19) ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 112: Troubleshooting

    LED switches from red to green after about 10 seconds. Electrical error Check that there is no fault on the pump (on its wiring or electronics). ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 113: Access Reserved To Service

    - the burner flame is not too high or low and that it is stable (does not detach from burner); Maintenance operations must be carried out by an authorised company (e.g. Authorised After-Sales Technical Assistance Cen- tre). ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 114: Calibration Type Involving The Replacement Of A Component

    Reset the parameters P.C.B. (New virgin P.C.B. without removable memory recovery) Complete calibration with CO check P.C.B. (Recovery of the removable memory with the boiler parameters No calibration required. set from the replaced board) ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 115: Complete Calibration

    - Flame: indicates the presence of a flame (thus the ignition of the burner) The text indicating the circuit on which the energy produced is discharged appears at the bottom of the display ("Central Heating active" oppure "Domestic Hot Water active") ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 116 (Par. 4.2), change the value, as described in the paragraph (Par. 3.12). When the combustion value measured on the intermediate power is correct, request the advancement of the procedure to the next phase (minimum power) by pressing OK "Calibration Phase med Ok". ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 117 The end of the function is accompanied by the window “Calibration completed”. If the message "Max Err" on the "Calibration Phase" item appears, it means that something was not successful during the cali- bration process. In which case, the operation must be repeated from the beginning. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 118: Co Adjustment

    “Ok” to confirm the new value. Wait for the text "Max Ok" "med Ok" or "Min Ok" to appear before checking the combustion linked to the new value based on the phase in which the change is made. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 119: Quick Calibration

    The end of the function is accompanied by the window "Calibration completed". If the message "Max Err" on the "Calibration Phase" item appears, it means that something was not successful during the cali- bration process. In which case, the operation must be repeated from the beginning. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 120: Flue Test

    The function ends after 15 minutes, or by selecting "Stop". Check the ΔP between two pressure tests (Par. 1.40) and set the parameter "Length Flue" according to the values below: VICTRIX SUPERIOR 35 PLUS Menu \ Service \ Boiler \ Flue Pressure ≤...

  • Page 121: Parameters And Information Menu

    = Auto" is selected) Sets manual set (manual set will be active 24 hours a day if "Set manage- Set manual 10 ÷ 60 °C 10°C ment = Man" is selected) (*) See the DHW paragraph (Parag.2.6). ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 122 Zone 1 Information Menu is always present regardless of whether or not a CAR is connected. (**) not displayed when the “Enable room probe” is set to No (***) displayed when the zone of interest is associated with a room probe (RF probe,...) ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 123 - the external probe is present - the parameter "Function Mode" is set at "Auto" or "Off" lack or - a room probe is configured unavailability of room probes - the "Enable room sensor" parameter is set to "Yes" ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 124 85°C tem operation Defines the minimum central heating / C.H. system operation flow Minimum flow set temperature (if external probe is present, it will be correlated to the 20°C ÷ 85°C 20°C maximum outdoor temperature) ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 125 This displays the number of ignitions and the hours of operation of the burner Allows selecting the panel operating language, the display operating mode and to access the password-protected menus General settings dedicated to a qualified technician. Service Gives access to the functions exclusive for Service ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 126 Maintenance withing activated, the line is not displayed Main board rev. SW Boiler board sw version display Firmware version Display board sw version display (*) When the appliance is connected with an external storage tank unit. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 127 In case the user restores the factory conditions through "Menu/General settings/User factory settings", the menu will appear in Eng- lish. Proceed in the following way to restore the desired display language: - Enter Menu/General setting/Language. - Select the desired language from those available and press OK. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 128 Bol.: boiler with Bol. = boiler with DHW storage tank Hydraulic Defines the type of boiler hydraulics DHW storage Herc. = Not used on this model tank Herc. Sol. = Not used on this model ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 129 The P.C.B. defines the operating mode and the boiler output according to the combination of several parameters. The correct ranges to obtain the correct operating power of the appliance are defined from the combination of parameters "Model", "Gas type", "Length Flue". ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 130 Set the preset parameters on the board software to allow installation in Enable Klapet valve No / Yes configuration C (10) (12) A change in these parameters will cause the appliance block signalled with E72; to reset E72, a quick calibration must be activated. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 131 This defines the type of speed control Delta t 15°C of the pump in central heating / C.H. Delta t = 5…25 : constant Delta t opera- tion (at the set value) ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 132 Anti-legion.cycle time: Sets the an- ti-legionella function intervention 00:00 ÷ 24:00 02:00 time Antilegionella Anti-legion.cycle day: Sets the day(s) of activation of the anti-legionella func- None ... All None tion ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 133 Disable / Flow temp / Photovol. Disable and 20 IMG BUS: select this mode when con- necting an Immergas remote control (e.g. CARv2) to terminals 44-41 1: select this mode when a commercial remote is connected to terminals 44- 41 (with this selection, the control of...
  • Page 134 If the "BMW" is activated and these devices are present simultaneously, a conflict will be generated and will appear on the display with the text "Way not compatible". * When the BMS parameter is selected, the parameters already set and ready to communicate with the Immergas system manager will appear and be visible in the following table:...
  • Page 135 MENU/Service/Special function/Fast calibration Menu item Description Range Activates the quick calibration function (Access to the calibration window Fast calibration with activation of the quick calibration command ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 136 (to hours be added to the days of the previous item) MENU/Service/Maintenance Customised Menu item Description Range Default value Select number of months Sets the number of months for scheduled maintenance Off - 36 ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 137: Replacing The Manifold Insulating Panel

    5. Refit the ignition and detection electrode (5) using the previously removed screws (6) and replace the relative gasket (4). Electrode distance To regain optimal operation, make sure that the following variables are respected when refitting the electrodes. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 138: Assembly Of Manifold Gasket On Condensation Module

    Every time the manifold is opened, the condition and integrity of the ceramic fibres must be verified and replaced, if necessary. The manifold gasket, on the other hand, must be replaced every 2 years. After replacing the external silicone gasket, it is mandatory to check the fume tightness. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 139: Assembling The Manifold On The Condensation Module

    2. Tighten the 4 nuts (1) on the condensation module (3) according to the sequence (A, B, C, D) indicated in the drawing. The maximum tightening force in assembling the manifold (2) on the condensation module (3) must be 5 Nm. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 140: Replacing The Control Panel Keyboard

    4. Pulirand the surface (4) of the control panel by removing any residue of the double-sided adhesive. 5. Glue the new keyboard to the control panel by applying finger pressure along the entire perimeter of the keyboard. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 141: Specific Information For Correct Appliance Installation In Common Pressurised Flue Systems (C )

    Only then proceed to verify the components, making sure that the non-return valve siphon on the flue gas (on the exhaust) (Fig. 48) is full and replacing them if malfunctioning or damaged. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 142: Appliance Coupling With Wireless Room Probes

    - Status = ...: indicates the mode of association in progress. - Status = Ok: indicates the correct association between the wireless probe and the zone to be controlled. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 143: Automatic Vent

    On the second line of the “Deaeration” page it is possible to activate the manual de-aeration by selecting “Deaeration = Start". This function lasts 18 hours and it can be ended by setting "Deaeration = Stop" and by pressing the “Reset” button on the control panel. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 144: Chimney Sweep

    20 minutes after the last action on the buttons and/or encoder. With the function active, it is possible to return to the initial screen and then re-enter the "Chimney sweeper" window with a long press on the reset button, keeping the function always active. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 145: Screed Heater

    During functioning in Central heating mode or with appliance in Standby, the function activates every 18 hours after the last appliance check/power supply. In case of functioning in domestic hot water mode the self-check starts within 10 minutes after the end of the with- drawing in progress, for duration of approx. 10 seconds. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 146 During the self-check, the appliance remains off. Warnings included. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 147: Casing Removal

    Front panel (Fig. 88) 3. Open the door (c). 4. Remove the cover caps (d) and loosen the screws (e). 5. Pull the front panel (f) towards you and release it from its lower seat. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 148 Front (Fig. 89) 6. Loosen the two screws (g). 7. Pull the front (h) slightly towards you. 8. Release front (h) from pins (i) pulling it towards you while pushing it upwards. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 149 10. Tilt the control panel (l) towards you. Sides (Fig. 91) 11. Unscrew the side (m) fastening screws (n). 12. Disassemble the sides (n) by first lifting them upwards and then pulling them towards you. Ref. X ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 150: Technical Data

    4050 1,64 4175 1,20 13,5 13,1 3725 1,43 3875 1,05 12,0 11,6 3475 1,27 3650 0,93 10,0 3150 1,06 3350 0,78 2800 0,85 3050 0,62 2475 0,63 2775 0,47 1975 0,31 2300 0,23 1850 0,23 ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 151: Combustion Parameters

    0% O at Nom./Min. Q. mg/kWh 33 / 18 34 / 25 Flue temperature at nominal output °C Flue temperature at minimum output °C Max air combustion temperature °C Maximum flue gas circuit temperature °C ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 152: Technical Data Table

    4.3 TECHNICAL DATA TABLE VICTRIX SUPERIOR 35 PLUS Domestic hot water nominal heat input 34,0 Central heating nominal heat input 32,8 Minimum heat input DHW nominal heat input with 20%H2NG gas 31,2 PoCentral heating nominal heat input with 20%H2NG gas...

  • Page 153: Technical Parameters For Combination Boilers (In Compliance With Regulation 813/2013)

    TECHNICAL PARAMETERS FOR COMBINATION BOILERS (IN COMPLIANCE WITH REGULATION 813/2013) The efficiencies and NO values in the following tables refer to the gross calorific value. Model VICTRIX SUPERIOR 35 PLUS Condensing Boiler Low temperature boiler Boiler type B1 Co-generation appliance for central heating...

  • Page 154: Product Fiche (In Compliance With Regulation 811/2013)

    4.5 PRODUCT FICHE (IN COMPLIANCE WITH REGULATION 811/2013) punto soluzioni srl "!! VICTRIX SUPERIOR 35 PLUS 2019 811/2013 Parameter Value Annual energy consumption for the central heating mode (QHE) Seasonal space heating energy efficiency (ηs) ST.006205/002 VICTRIX SUPERIOR 35 PLUS...

  • Page 155: Parameters For Filling In The Package Fiche

    Boiler and supplementary heat pump installed with low temperature heat emitters at 35 °C? FFrom the board of the heat ( 50 ‘II’ pump in the distribution system and the size of the products compared to the size and features of the building. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 156 Parameters for filling in the assembly chart Parameter VICTRIX SUPERIOR 35 PLUS "I" "II" "III" 0,84 "IV" 0,33 * to be established by means of table 5 of Regulation 811/2013 in case of “assembly” including a heat pump to integrate the boiler. In this case the boiler must be considered as the main appliance of the assembly.
  • Page 157 ≥ 131 % ≥ 170 % ≥ 213 % Colder: - 0.2 x Hotter: + 0.4 x in the distribution system and the size of the products compared to the size and features of the building. ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 158 Parameters for filling in the DHW package fiche Parameter VICTRIX SUPERIOR 35 PLUS "I" "II" "III" * to be determined according to Regulation 811/2013 and transient calculation methods as per Notice of the European Community no. 207/2014. Domestic hot water production system package fiche.
  • Page 159 ST.006205/002 VICTRIX SUPERIOR 35 PLUS...
  • Page 160 Immergas S.p.A. 42041 Brescello (RE) - Italy IMMERGAS SPA - ITALY Tel. 0522.689011 CERTIFIED COMPANY UNI EN ISO 9001:2015 immergas.com Design, manufacture and post-sale assistance of gas boilers, gas water heaters and related accessories This instruction booklet is made of...

Table of Contents
