FLOCELL XFM 900 FILTERS
INSTALLATION & OPERATING MANUAL
PLEASE READ INSTRUCTIONS THOROUGHLY BEFORE INSTALLATION
Document Title
Flocell XFM 900 Filter - Installation & Operation Manual
Document Number XFM900-OM-001
Revision
01
Date
15-04-2025
Prepared By
Zile Bashir
Checked By
Jasper Kuijper
Approved By
Gavin Haywood
Kellet Close, Wigan, Lancashire, United Kingdom, WN5 0LP
t: +44 (0) 1942 216 554 e:
Flocell XFM Fines Filter 900
Operations Manual
TERMS & CONDITIONS
AND COMMISSIONING
info@FlocellFiltration.com
FlocellFiltration.com
P a g e
| 1
Rev 01
.
1
Advertisement
Related Manuals for Flocell XFM 900
Summary of Contents for Flocell XFM 900
- Page 1 FLOCELL XFM 900 FILTERS INSTALLATION & OPERATING MANUAL TERMS & CONDITIONS PLEASE READ INSTRUCTIONS THOROUGHLY BEFORE INSTALLATION AND COMMISSIONING Document Title Flocell XFM 900 Filter - Installation & Operation Manual Document Number XFM900-OM-001 Revision Date 15-04-2025 Prepared By Zile Bashir...
- Page 2 Flocell XFM Fines Filter 900 Operations Manual Contents Introduction ............................ 3 Low cleaning frequency ......................3 No hydraulic pressure loss ......................3 Low operating costs ........................3 Low water use and air-cleaning ....................3 Standard Supply ..........................4 Specifications & Flow Rates ......................5 General Arrangement Drawing .......................
- Page 3 Flocell XFM Fines Filter 900 Operations Manual 1. Introduction Flocell XFM filters are high performance, high-capacity filtration units designed to capture large quantities of suspended particles and are not subject to the typical restrictions of particulate filters. a. Low cleaning frequency Due to much higher retention capacity, cleaning cycles are far less frequent than with other technologies therefore increasing operational efficiency.
- Page 4 Flocell XFM Fines Filter 900 Operations Manual 2. Standard Supply Standard Supplied Items The following items are supplied as standard with the Flocell XFM 900 Filter: Item Description Flocell XFM 900 Filter Primary filtration unit constructed from HDPE for suspended solids...
- Page 5 Flocell XFM Fines Filter 900 Operations Manual Note: All pipework and associated components—including inlet, sludge, outlet, and head of works ball valves—are supplied loose. It is the responsibility of the end user to assemble, position, glue, and connect these components on-site according to installation requirements. Additional installation materials (e.g.
- Page 6 Flocell XFM Fines Filter 900 Operations Manual 4. General Arrangement Drawing Kellet Close, Wigan, Lancashire, United Kingdom, WN5 0LP t: +44 (0) 1942 216 554 e: info@FlocellFiltration.com FlocellFiltration.com P a g e Rev 01...
- Page 7 Flocell XFM Fines Filter 900 Operations Manual 5. Media Flocell XFM filters use a proprietary open-cell media that has been optimised for fine particle mechanical filtration. The graph above shows expected performance as a function of the particles present; this can be used for mass balance calculations with the appropriate gravimetric test results to optimise cleaning frequency.
- Page 8 Flocell XFM Fines Filter 900 Operations Manual 6. XFM Filter Installation NOTE: Filters are delivered conveniently packed and due to their weight, size and difficulties arising in placing them, we recommend that their handling and movement be done with mechanical apparatus (forklifts, cranes, etc.).
- Page 9 Flocell XFM Fines Filter 900 Operations Manual XFM filters should be installed as close as possible to the inlet supply and preferably at a level of 0.50 metres below the surface of the water in and settlement vessel or sump. Make sure there is accessible drainage for filter overflow.
- Page 10 Flocell XFM Fines Filter 900 Operations Manual 7. Operational design Flocell XFM filters are not designed to filter gross solids, and it is paramount that a pre-filter screen is present in any situation where this may occur. Power Isolation: Before performing maintenance on the filter or valves, ensure that the •...
- Page 11 Flocell XFM Fines Filter 900 Operations Manual 8. Operational Modes The Flocell XFM 900 Filter operates using an up-flow filtration system: b. Filtration Mode: 1. Inlet: Water enters the filter through the lower tank connection (INLET valve open, SLUDGE valve closed).
- Page 12 Flocell XFM Fines Filter 900 Operations Manual c. Cleaning Procedures Single Filter Cleaning Process Step 1: Preparation Care should be taken to ensure combination air valve is unobstructed to allow media to freely circulate during cleaning and to prevent pressure increase...
- Page 13 Flocell XFM Fines Filter 900 Operations Manual Step 2: Media Agitation III. Step 3: Sludge Removal Kellet Close, Wigan, Lancashire, United Kingdom, WN5 0LP t: +44 (0) 1942 216 554 e: info@FlocellFiltration.com FlocellFiltration.com P a g e | 13 Rev 01...
- Page 14 Flocell XFM Fines Filter 900 Operations Manual d. Refill on Head of Works Bypass Mode e. Return to Operating Mode Multiple Filters in Parallel With multiple filters connected, single control valves may be utilised, or the system can be valved to clean filters independently depending on operational requirements.
- Page 15 Flocell XFM Fines Filter 900 Operations Manual 9. Maximising efficiency / performance As all installations are different, cleaning frequency will need to be determined to limit cleaning when necessary. In single and parallel installations, it may be optimal to run more than one cleaning cycle to prevent carry-over of dirty water transferred to the top of the filter during air sparging, but it is unlikely that more than 2 cleaning cycles will be needed in even the most loaded systems.
- Page 16 Outlet pump not running Ensure the outlet pump is operational (if applicable) By following these troubleshooting steps, most operational issues with the Flocell XFM 900 Filter can be resolved efficiently. Kellet Close, Wigan, Lancashire, United Kingdom, WN5 0LP t: +44 (0) 1942 216 554 e: info@FlocellFiltration.com...
- Page 17 Flocell XFM Fines Filter 900 Operations Manual Spare Parts & Maintenance Checklist Recommended Spare Parts Part Description Recommended Qty XFM Fines Media As required Combination Air Valve 1 spare Sludge Drain Valve 1 spare Inlet/Outlet Ball Valves 2-3 spares O-Ring Seals for Pipe Connections 1 set...
- Page 18 Flocell XFM Fines Filter 900 Operations Manual Quick Reference – Do’s and Don’ts Table Do’s Don’ts � � � Install on a solid, level base Don’t exceed 2 bar inlet pressure � � � Use pre-filter for gross solids Don’t connect directly to unregulated mains �...
- Page 19 Flocell XFM Fines Filter 900 Operations Manual Appendices a. Blower Technical specifications and Operation and Maintenance Details Supplied Model: AIRFLO 900W Kellet Close, Wigan, Lancashire, United Kingdom, WN5 0LP t: +44 (0) 1942 216 554 e: info@FlocellFiltration.com FlocellFiltration.com P a g e...
