Related Manuals for Cudy LT450
Summary of Contents for Cudy LT450
- Page 1 Quick Installation Guide English Deutsch Español Italiano Français Email: Website: support@cudy.com www.cudy.com...
- Page 2 Quick Installation (English) Make sure the antennas are installed properly and place vertically as the picture below. LAN1 LAN2 LAN3 LAN4/WAN RESET POWER Nano SIM With the gold contacts facing down, gently slide the nano SIM card into the slot until you hear a click sound.
- Page 3 Connect power adapter and turn on the router. Waiting for 2 minutes for it to start. Check the status of the system LED. When the system LED turns solid blue, it means the router is connected to the 4G cellular network. If the system LED turns to solid purple, it means the router is connected to 2/3G cellular network.
-
Page 4: Led And Button
LED and Button Name Status Indication Internet is not connected Blue 4G or WAN Internet is connected Solid On Purple 2/3G is Connected System System is starting up Flashing Blue WPS is in progress Red-Purple-Blue Software Upgrading Power adapter is not connected to the device. The corresponding Ethernet port is connected. - Page 5 Network name and password is printed on the bottom of the router. 4G LTE Wi-Fi Router Wi-Fi: Cudy-XXXX Password: XXXXXXXX Note: For LT450 and LT500, the device will create two WiFi signals, 2.4GHz WiFi network name is Cudy-XXXX, 5GHz WiFi network name is Cudy-XXXX-5G.
- Page 6 Launch a web browser and enter http://cudy.net/ (or http://192.168.10.1/) in the address bar, use admin as password to login. http://cudy.net/ Auto admin Password Log In...
- Page 7 The page below would pop up if your SIM card needs PIN to unlock. Please enter your PIN and click Save & Apply, then wait 15 seconds to con- nect to the Internet. 4G Settings The SIM is locked, please enter the PIN code. You have 3 attempts at most for entering the PIN code.
- Page 8 Then please check 4G information card of the status page. If the status is connected, means connected to the internet successfully. Status Connected Status Not connected RSSI RSSI Upload / Download Upload / Download 770.63KB / 681.69KB 0.00 B / 0.00 B More Details More Details Connected...
- Page 9 4G Router Model XXXXX Quick Setup Note： 1. If you are not sure about APN parameters, please contact your internet provider. 2. If you meet any other problems, don't hesitate to contact our technical support team: support@cudy.com Enjoy the internet!
- Page 10 A1: If the computer is set to a static IP address, change its settings to obtain an IP address automatically. A2: Make sure http://cudy.net/ or http://192.168.10.1/ is correctly entered in the web browser. A3: Use another web browser and try again.
-
Page 11: Fcc Statements
EU Declaration of Conformity 1. English: Cudy hereby declares that the device is in compliance with the essential requirements and other relevant provisions of 16. Slovenčina: directives 2014/53/EU, 2009/125/EC and 2011/65/EU.
