Kryptonite Avenue R-50 Manual

Kryptonite
437 Turnpike Street
Canton, MA 02021
(781) 828-6655
www.kryptonitelock.com
POWER BUTTON:
To turn on the Avenue R-50 hold down the power button (A)
until the light is on and then release. There are 6 modes for this
light. Press and release the light power button (A) briefly to
cycle through each mode. To turn off the light hold down on the
power button (A) until the light is off and then release.
MODES:
FRONT:
I. First Click – High Flash
II. Second Click- Medium Steady
III. Second Click – Low Steady
IV. Third Click- Daytime Pulse
V. Fourth Click – Nighttime Pulse
VI. Fifth Click- Economical Flash
MEMORY FUNCTION:
When the light is turned off it will remember the mode it was on
last and turn back on at that mode.
LOW BATTERY INDICATOR:
When the rechargeable battery is at 25% power or less a red
indicator located around the power button (A) will illuminate.
POWER SAVER FUNCTION:
At 10% battery power or less the light will switch to "Economical
Flash" which is the lowest power output to save battery.
CHARGING:
The Avenue R-50 is equipped with a built-in lithium polymer
battery that has a USB charging port (B) located on the back of
the light. To charge, open the USB cover (C). DO NOT FULLY
REMOVE THE COVER. Insert the USB charging cord into the USB
charging port (B). Connect larger end of USB cord to a power
source like a computer or USB block (not included).
To ensure that the light is charging, look for a red indicator light
located around the power button (A).
Once fully charged indicator light will turn green. Disconnect
from power source. Push and seal USB cover (C) properly to
ensure dirt and grime does not get into the charging port.
MOUNTING:
The Avenue R-50 light comes with a mounting clip already
attached to clip on bags, jerseys, etc.
To mount the light on a bike: First remove the clip (D) by pushing
down on the release leaver (E) and sliding the clip (D) down.
Then take the standard bracket (H) and slide it into the wide
part of the groove (I) on the back of the light until it snaps. Take
the bracket and hold it against the seatpost. Take the standard
rubber fastening strap (G) around the seatpost so that it is snug
and insert hook (F) through a hole in the strap. Adjust the strap
Avenue R-50
A
C
B
INS-AVE_R50_0617
A
C
