- Page 1 5.1-CHANNEL HOME THEA TER SYSTEM WITH WIRELESS SUBWOOFER AND AM/FM DIGIT AL TUNER Model: BWA18SB003 Ver.00 08/03/18...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Additional safety information Please read and save for future reference. Some of the following information may not apply • Apparatus shall not be exposed to dripping or to your particular product; however, as with splashing and no objects filled with liquids, such any electronic product, precautions should be as vases, shall be placed on the apparatus. -
Page 3: Safety Precautions
Safety Precautions THE LIGHTNING FLASH AND ARROWHEAD WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING YOU OF “DANGEROUS VOLTAGE” INSIDE THE PRODUCT. THE EXCLAMATION POINT WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING IMPORTANT INSTRUCTIONS ACCOMPANYING THE PRODUCT. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). - Page 4 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio / TV technician for help.
-
Page 5: Headset Safety
This product should be serviced only by those specially trained appropriate servicing techniques. For instructions on how to obtain service, refer to the warranty included in this user manual. Technical Specification Product: Home Theater System Brand : Blackweb Electrical Consumption Power Supply: 120V ~ 60Hz... -
Page 6: Important Battery Information
For Your Safety The AC power plug is polarized (one blade is wider than the other) and only fits into AC power outlets one way. If the plug won’t go into the outlet completely, turn the plug over and try to insert it the other way. - Page 7 General Controls Main Unit 6 7 8 9 5. AUX 2 jacks ON/STANDBY Connect game consoles or other AV products Turns on / off the unit. When the unit is turned that have AUX audio outputs. on, the unit will go to the mode it was in before powered off.
-
Page 8: General Controls
General Controls Remote Control Install two “AAA” batteries in the remote control prior to use. 1. ON•OFF Turn on/off the unit. 2. SLEEP Selects sleep time. 3. NIGHT Selects among night mode options (MODE RATE / QUIET / OFF) which compresses the volume difference between normal voices and sounds such as explosions. - Page 9 6. DISTANCE Adjusts the speakers’ listening distance. • Press to select among setting items in Setup mode. • Press to adjust the values when the display shows the setup you want to change. • Press OK to confirm your selection. 8. LEVEL Speaker level setting.
- Page 10 Connections and Setup Connecting to HDMI Components You can experience superb Home Theater quality sorround-sound from any HDMI connected device such as Blu-Ray Disc Player, Satellite Receiver and Cable Box, DVD Player, etc. HDMI IN Three “HDMI in” jacks receive digital signal from Blu- Ray Disc Player, Satellite Receiver and Cable Box, DVD Player, etc.
- Page 11 Coaxial Digital In (Audio) - Better Connect to coaxial digital output of DVD, Cable box, Satellite receiver, TV or other compatible devices using the Coaxial Digital Cable (not included). Press the SOURCE button on the Home Theater System or the COAXIAL button on the remove control to select Coaxial Digital cable COAXIAL.
- Page 12 AM Loop Antenna and FM Indoor Antenna 1. Uncoil the antenna wire and locate the base end of the AM antenna. 2. Press down on the antennas tab to open the terminal. 3. Insert the antenna wires into the terminal and release the tabs to secure the wires in place. 4.
- Page 13 Positioning speakers Front Left speaker Center speaker Front Right speaker Subwoofer Rear Left speaker Rear Right speaker Front speakers Front speakers carry primarily music and sound effects. • Place the left and right speakers to form a 45-degree angle with your favorite viewing position to duplicate the soundtrack mixer’s perspective.
- Page 14 Connections and Setup Pairing the Subwoofer with Home Theater System In order to use the wireless Subwoofer, you must pair it with the Home Theater System. A. AUTOMATICALLY 1. Connect the power cord to a wall outlet. 2. Turn on the Home Theater System. 3.
-
Page 15: Operating Your Unit
Operating Your Unit Setting the sleep timer You can set the system to turn off at a preset time, so you can fall asleep listening to music. You can preset the time in 30-minutes increments. 1. Press SLEEP button on the remote control. 2. - Page 16 RECONNECTING A BLUETOOTH® ENABLED DEVICE Bluetooth® enabled devices must be reconnected when the device has been turned off or the unit has been turned off. 1. Press button to turn on the unit. 2. Press SOURCE button or button on the remote control to select the BT mode.
-
Page 17: Selecting Source
Selecting Source When one of the SOURCE buttons on the front panel or on the remote control is pressed, the corresponding input will be activated. The unit acts as a switching device between all the sources that are plugged into it. Example 1: If you have connected a DVD player to the HDMI IN 3 jack on the unit, press SOURCE on the front... - Page 18 Example: Connecting a Blu-ray Player 1. Connect the optical digital audio out jack of Blu- ray player to OPTICAL 1 jack on the rear panel of the unit. ON/STANDBY on the front panel of the 2. Press unit or press ON•OFF on the remote control to switch on the unit.
- Page 19 RADIO The unit has a built-in tuner that allows for AM/FM radio function. Connect the FM antenna and the AM loop antenna at the back of the unit. Rotate the AM loop for better reception. Automatic Tuning 1. Press TUNER button on the remote control to select AM/FM mode.
- Page 20 3. Press MEMORY. While the Program Preset number is still flashing, input your desired preset number using the numeric buttons, then press MEMORY to store it. Select Preset Stations 1. Press TUNER button on the remote control to select AM/FM mode. 2.
-
Page 21: Advanced Sound Control
Advanced Sound Control Sound Enhancement Systems This receiver is equipped with several built-in sound enhancement systems. Dolby Digital The Dolby Digital mode lets you enjoy full digital surround from software processed in the Dolby Digital format. Dolby Digital provides better sound quality and a more powerful presence than conventional Dolby Surround. -
Page 22: Fine Setting Of The Components
DSP (Digital Sound Processor) These digital sound effects resemble sounds in a real environment such as (HALL, CHURCH, DOLBY 5 CH, DOLBY PL EMULATION, DOLBY PL II MUSIC, DOLBY PL II MOVIE). DSP automatically converts analog audio signals to digital ones which enables you to adjust the sound without degrading the sound quality. -
Page 23: Fine Setting Of The Speakers
Advanced Sound Control You have the capability to change audio inputs for the SAT-CABLE, BD, TV or GAME sources. Source Default input HDMI 1 (BD: HD 1) SAT-CABLE HDMI 2 (SAT: HD 2) HDMI 3 (DVD: HD 3) Rear Analog (TV: ANLG) Built in tuner AM/FM Rear Analog (VCR) -
Page 24: Speaker Configurations
Adjusting Speaker Loudness Without Using Test Tones 1. To adjust individual speaker volume level, press LEVEL on the remote control. 2. Continue to press LEVEL on the remote control to select the speaker to be adjusted, then press buttons to adjust the level. 3. - Page 25 Center / Surround Speaker Setup NIGHT Mode Selection 1. Press the SETUP button on the remote control “Night Mode” will limit the volume on loud to show setup options. passages of movies (such as action sequences) 2. Press / until CTR YES or SUR YES is displayed. while still allowing you to hear quiet passages 3.
-
Page 26: Troubleshooting Tips
Troubleshooting Tips AM / FM Operation ST indicator is off. • Adjust the antenna. • Press MONO / ST button to insure you are not outputting in mono. The signal is Mono. Severe hum or noise. • The signal is too weak. Connect an external antenna. -
Page 27: Care And Maintenance
No sound from the wireless subwoofer • Turn off and turn on the Home Theater System and Subwoofer again. • Set up the wireless subwoofer connection manually (Refer to the Pairing the Subwoofer with the Home Theater System). Care and Maintenance Disconnect the audio system from the power source before performing any maintenance. - Page 28 LIMITED WARRANTY VENTURER ELECTRONICS (“VENTURER”) makes the following limited warranty. This limited warranty extend to the original consumer purchaser and is limited to non-commercial use of the product. Ninety (90) Day Parts & Labor Warranty Venturer products purchased in the United States are warranted to be free from defects in materials or workmanship for a period of ninety (90) days from the date of their original retail purchase.
- Page 29 any state thereof, is hereby limited to ninety (90) days from the date of purchase. This limitation does not apply to implied warranties arising under state law. This warranty gives you specific legal rights and you may also have other rights, which may vary from state to state.Some states do not allow limitations on how long an implied warranty lasts, when an action may be brought, or the exclusion or limitation of incidental or consequential damages, so the above provisions may not apply to you.
