Installation Manual
Schluter
-DITRA-HEAT-E-RS1
®
Smart Thermostat
This installation manual is subject to change without notice.
Please visit www.schluter.com for the latest version.
WARNINGS
The installation of this thermostat must be performed by qualified personnel
and comply with the national and local electrical codes and regulations.
To avoid electric shock, disconnect the heating system power supply at the
main electrical panel before installation and maintenance of the thermostat.
Advertisement
Table of Contents
Related Manuals for Schluter Systems DITRA-HEAT-E-RS1
Summary of Contents for Schluter Systems DITRA-HEAT-E-RS1
- Page 1 Installation Manual Schluter -DITRA-HEAT-E-RS1 ® Smart Thermostat This installation manual is subject to change without notice. Please visit www.schluter.com for the latest version. WARNINGS The installation of this thermostat must be performed by qualified personnel and comply with the national and local electrical codes and regulations.
-
Page 2: Thermostat Installation
THERMOSTAT INSTALLATION 1. Loosen the screw at the bottom and remove the faceplate. 2. Connect the heating cable to the load terminals and the power supply wires to the line terminals located on the back of the thermostat. Connect the heating cable ground wire to the grounding screw in the electrical junction box. - Page 3 3. Connect the temperature sensor as shown. Use the floor temperature sensor supplied with the DITRA-HEAT-E-HK heating cable(s). Any other type of sensor used needs to be 300 volt rated and meet the other requirements of the electrical codes in your region. 4.
- Page 4 5. Replace the cover and tighten the screw at the bottom. 6. Power up the thermostat. After performing a test sequence, the thermostat should display the floor temperature. If not, refer to the troubleshooting guide in this manual.
-
Page 5: Application Settings
APPLICATION SETTINGS (Can also be done with the app) 1. Press the dot soft button and hold for 1 second to access the menu. Press the appropriate arrow to move up and down into the choices and press the dot soft button to make a selection and move to the next parameter, until reaching the end. - Page 6 2. Settings Which Can Be Modified with the Device Parameter and Setting No. Name Further Explanation possible settings Temperature unit: Temperature °F or °C (default: °F) The thermostat offers 2 temperature regulation modes: Control Mode: Floor mode: Regulates floor temperature by means of an external floor Control Floor or Ambient temp.
- Page 7 MANUAL TEMPERATURE ADJUSTMENTS To adjust the temperature, press the up down arrow to change the set point temperature.
- Page 8 CONNECT THE THERMOSTAT TO THE SCHLUTER SMART ® THERMOSTAT APP 1. If you do not yet have an account, download the Schluter Smart Thermostat app for iOS or ® Android™ to create an account and add your device. 2. Tap the menu icon on your smart phone, then select “Add Device”...
- Page 9 CONNECTING THE DITRA-HEAT-E-RRS POWER MODULE(S) DITRA-HEAT-E-RRS DITRA-HEAT-E-RRS DITRA-HEAT-E-RS1 OTHER DITRA-HEAT-E-RSS When requiring more than 15 amps in a room, the Schluter -DITRA-HEAT-E-RRS power module is ® recommended. This power module is the only model which can be used with the Schluter -DITRA-HEAT- ®...
-
Page 10: Ground Fault Protection
GROUND FAULT PROTECTION The thermostat is equipped with a ground fault protection that can detect a current leakage of 5 mA. When a current leakage is detected, the ground fault protection is triggered and quickly interrupts the power supply to prevent any serious injuries. Testing the ground fault protection: This thermostat has an Auto Test which periodically verifies the correct operation of the protection circuit. -
Page 11: Factory Reset
DISCONNECTING THE THERMOSTAT FROM THE ROUTER OR FROM THE APP Tap the two arrows ( ) simultaneously to enter the connection menu. In the connection menu, hold the two arrows until “Disconnected” is displayed. FACTORY RESET To perform a reset of all parameters to the factory default: Press the dot soft button for one second and press it again repeatedly until reaching the diagnostic page. -
Page 12: Troubleshooting
LEAVING THE STANDBY MODE When the thermostat is on standby, press any button to turn back ON the thermostat. The thermostat will resume operation under its last program settings. A thermostat that is placed on standby before a power failure will be on standby by default when power is restored. -
Page 13: Technical Specifications
TECHNICAL SPECIFICATIONS Operating voltage: 120/208/240 Vac, 50/60 Hz Maximum load: 1800 W @ 120 V / 15 A, max. 3120 W @ 208 V / 15 A, max. 3600 W @ 240 V / 15 A, max. Setpoint range: 5° C to 36° C (41° F to 97° F) Display range: 0°... -
Page 14: Firmware Version
APPLE HOME Controlling this HomeKit-enabled accessory automatically and away from home requires a HomePod, HomePod mini, or Apple TV set up as a home hub. It is recommended that you update to the latest software and operating system. To control this HomeKit-enabled accessory, the latest version of iOS or iPadOS is recommended. - Page 15 This device complies with Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device does not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 16 NOTES:...
- Page 17 Warranty Visit www.schluter.com for warranty information. Schluter Systems L.P. 194 Pleasant Ridge Road, Plattsburgh, NY 12901-5841 Tel.: 800-472-4588 • Fax: 800-477-9783 Schluter Systems (Canada) Inc. 21100 chemin Ste-Marie, Ste-Anne-de-Bellevue, QC H9X 3Y8 Tel.: 800-667-8746 • Fax: 877-667-2410 www.schluter.com Item: 660-0740-0000...
