1.
Locate installation parts and
tools behind the bottom-left
display door. See graphic
below and in Step 12. Splice
wrench and torque stick
shown here.
2.
Determine the most level
surface on which to splice
multiple-section displays.
•
This may be the trailer. Follow OSHA fall protection guidelines.
3.
Do as much preparatory work on the ground while displays are easily
accessible.
•
Move mounting brackets to approximately where the structure's
uprights are located. The display's center is clearly marked for easy
measurement.
•
Assemble the webcamera to arm supplied with the display.
Assemble webcam arm to the display.
•
•
Run power and signal connections between top and bottom sections.
Evenly distribute splice plates.
•
Display Installation
1.
Verify lift-eye and set bolts are secure.
Installation
Tools and
Spare Parts
Vertical
Splice
Tube
Time-Saving
Top Section
Bottom Section
Splice
Key
Splice
Channel
Display Lift From Back
Horizontal Splice Tube
(From Top)
Tag Line
Tie Off
Used on multi-section
wide displays
Tips
Mounting
Channel
Lift-Eye Bolts
Set Bolts
Splice
Wrench
Display Lift
From Front
Angle must be
greater than 55°
Use
/
" Wrench
7
16
Top of Display
Advertisement
Related Manuals for Daktronics 6000 Series
Summary of Contents for Daktronics 6000 Series
- Page 1 Time-Saving Tips Locate installation parts and tools behind the bottom-left Top Section display door. See graphic Splice below and in Step 12. Splice Wrench wrench and torque stick Bottom Section Mounting Channel shown here. Splice Splice Determine the most level Channel surface on which to splice multiple-section displays.
- Page 2 Attach the crane to the lift-eyes in the top section. Remove the shipping hardware from the top section. Loosen and slide the black alignment bracket, circled above, up to guide the top section into the bottom section. Use a " wrench to remove the bolts holding the lift-eyes in the bottom section together and to the display.
- Page 3 Verify the LEDs on both display sections align with each other. LED Alignment Verify LEDs align in all directions between splices. If the LEDs are more than 1/4 of an LED out of alignment, adjust until properly aligned. 10. Evenly distribute the flat splice plates along the back of the display. Note: Ensure there is a flat splice plate near each end of the display.
- Page 4 14. Repeat Steps 12 - 13 on all vertical splice tubes. 15. If needed, relocate the DMP and the ISP enclosure to the alternate location to avoid structural interference when installed. 16. Slide the border splice plates and covers into place and attach with supplied Tek screws and...
-
Page 5: Electrical Installation
an opening in the mounting channel, shift the entire display left or right until the U-channel is at least 1" from the opening. 25. Tighten all of the nuts on the offset extrusion bolts to 75 ft-lbs with an impact wrench and the torque stick. - Page 6 11. Connect the signal splice cables from the display top section Signal A on the bottom section to Signal A on the top section and Signal B on the bottom section to Signal B on the top section. 12. Connect the power splice cable to the power interconnect jacks on each display section.
