Quick Setup Guide
− To register this product please visit www.samsung.com/register.
List of Parts
The provided accessories may vary depending on the model.
1
SOURCE
TTX/MIX
PRE-CH
MUTE
CH LIST
CONTENT
MENU
GUIDE
TOOLS
INFO
RETURN
EXIT
HOME
S.MODE
DUAL I-II
ALARM
P.SIZE
SUBT.
Remote Control & Batteries (AAA x 2)
1
4 • Safety Guide
• Quick Setup Guide
Installing the LED TV Stand
Stand Components
A
Stand
2
Power Cord
2
5 Holder-Wire Stand
3
B
Guide Stand
BN68-07406H-00
4
Data Cable
3
C
M4 X L14
Screws
5
Advertisement
Related Manuals for Samsung BN68
Summary of Contents for Samsung BN68
- Page 1 BN68-07406H-00 Quick Setup Guide − To register this product please visit www.samsung.com/register. List of Parts The provided accessories may vary depending on the model. SOURCE TTX/MIX PRE-CH MUTE CH LIST CONTENT MENU GUIDE TOOLS INFO RETURN EXIT HOME S.MODE DUAL I-II ALARM P.SIZE...
- Page 2 (M4 X L14) Front Side ATTENTION DO NOT USE DO NOT USE DO NOT USE CHEMICALS GREASE − Place a soft cloth over a table to protect the TV, and then place the TV on the cloth screen side down. x4 (M4 X L14)
- Page 3 Connecting the TV with STB The product color and shape may vary depending on the model. − Operation Specification of Data Cable(RJ12) : RS232 ETH MODEM Data Cable Hotel Server STB(Set Top Box) or SBB(Set Back Box) DATA PC / DVI PC / DVI AUDIO IN AUDIO IN Hotel Plug &...
- Page 4 75 ohm Unbalanced, Din Jack DATA RJ-12 Data RS232 Operating temperature 10°C ~ 40°C (50°F ~ 104°F) Operating Humidity 10% ~ 80% non-condensing Storage Temperature -20°C ~ 45°C (-4°F ~ 113°F) Storage Humidity 5% ~ 95% non-condensing − Design and specifications are subject to change without prior notice. − The above specifications may differ depending on the model. − For information about the power supply, and about power consumption, refer to the label attached to the product. − F or information on Samsung’s environmental commitments and product-specific regulatory obligations, e.g. REACH, WEEE, Batteries, visit http://www.samsung.com/uk/aboutsamsung/samsungelectronics/corporatecitizenship/data_corner.html Licences The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
