MICRO COMPONENT SYSTEM
UX-GP5
—Consists of CA-UXGP5 and SP-UXG300
Thank you for purchasing a JVC product.
Warnings, Cautions and Others
CAUTION:
Disconnect the mains plug to shut the power off completely
(the STANDBY lamp goes off). When installing the apparatus,
ensure that the plug is easily accessible. The
button in any position does not disconnect the mains line.
• When the System is on standby, the STANDBY lamp lights
red.
• When the System is turned on, the STANDBY lamp goes
off.
The power can be remote controlled.
CAUTION:
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
Dear Customer,
This apparatus is in conformance with the valid European
directives and standards regarding electromagnetic
compatibility and electrical safety.
European representative of Victor Company of Japan,
Limited is:
JVC Technology Centre Europe GmbH
Company name changed in:
JVC Technical Services Europe GmbH
Postfach 10 05 52
61145 Friedberg
Germany
©2008 Victor Company of Japan, Limited
(Standby/on) button!
INSTRUCTIONS
0108WMKMDWJMM
GVT0242-001A[B]
(Standby/on)
Advertisement
Table of Contents
Related Manuals for JVC UX-GP5
Summary of Contents for JVC UX-GP5
- Page 1 MICRO COMPONENT SYSTEM UX-GP5 —Consists of CA-UXGP5 and SP-UXG300 Thank you for purchasing a JVC product. INSTRUCTIONS GVT0242-001A[B] 0108WMKMDWJMM ©2008 Victor Company of Japan, Limited Warnings, Cautions and Others CAUTION: (Standby/on) button! Disconnect the mains plug to shut the power off completely (the STANDBY lamp goes off).
-
Page 2: Important For Laser Products
IMPORTANT for the U.K. DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or consult your dealer. - Page 3 CAUTION: Proper Ventilation To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows: 1. Front: No obstructions and open spacing. 2. Sides/Top/Back: No obstructions should be placed in the areas shown by the dimensions below. 3.
- Page 4 Basic and Common Operations Point at the remote sensor on the front panel. (The operating range is approx. 7 m.) STANDBY lamp PHONES jack Stereo mini plug cord How to cancel the demonstration Press and hold DEMO button while on standby. (Refer to the attached “Information about the demonstration function.”) Using Headphones Be sure to turn down the volume before connecting or putting on the headphones.
- Page 5 Press Indication/Result System Remote Turn on or off The STANDBY lamp on the System turns off/on. (standby) the power Select a source See “Playing Back a Disc” on page 4 and “Listening to an iPod” on page 5. Press repeatedly to select “FM” or “AM.” •...
-
Page 6: Getting Started
Getting Started Supplied Accessories After unpacking, check to be sure that you have all the following items. • Remote control, RM-SUXGP5R (× 1) • Lithium coin battery CR2025 (× 1) – The battery has been installed when shipped from the factory. - Page 7 Connections Do not connect the AC power cord until all other connections have been made. To connect the FM antenna (supplied) To connect the AM loop antenna (supplied) To assemble the AM loop antenna Extend it so that you can obtain the best reception. FM antenna (supplied) AM loop antenna (supplied) Turn it until the best reception...
-
Page 8: Playing Back A Disc
Playing Back a Disc The following operations are explained using the remote control, unless mentioned otherwise. However, if the System has the same or similar button names, they can also be used for the operations. This System can play back... –... -
Page 9: Basic Disc Operations
Basic Disc Operations Press Indication/Result Play back the disc • Current track number and elapsed playing time appear. For MP3/WMA files: Before current track number and elapsed playing time appear, the tag information appears if it is recorded. • During playback, press again to pause. Stop playback •... -
Page 10: Programming The Playing Order-Program Play
Programming the Playing Order—Program Play During stops, press until the PRGM (program) indicator lights up before playing. • For MP3/WMA files: Select a group number, then a track number. • For CD: Select a track number. Press to program the selected group/track. Repeat steps 2 and 3 to program other tracks you want. -
Page 11: Listening To An Ipod
Listening to an iPod The following operations are explained using the remote control, unless mentioned otherwise. However, if the System has the same or similar button names, they can also be used for the operations. Connecting an iPod Apple iPod Front view Insert the iPod directly to (separately... -
Page 12: Listening To Fm And Am Broadcasts
Press Indication/Result Select an item on • The UP/DOWN buttons work in the same the menu way as operating the iPod’s click wheel counterclockwise/clockwise. (Refer to the iPod’s instruction manual for details.) Play back at • Refer to the iPod’s instruction manual for random details. - Page 13 Receiving FM Stations with Radio Data System Radio Data System allows FM stations to send an additional signal along with their regular program signals. With the System, you can receive the following types of Radio Data System signals. PS (Program Service): Shows commonly known station names.
-
Page 14: Learning More About This System
Learning More about This System Basic and Common Operations Playing Back an iPod (see page 3) (see page 5) • Pressing one of the source buttons also turns on the System • Compatible iPod: and starts playing back if the source is ready or connected. –... -
Page 15: Troubleshooting
Troubleshooting If you are having a problem with your System, check this list for a possible solution before calling for service. General Power does not come on. \ Power plug is not inserted securely. Plug in securely. Adjustments or settings are suddenly canceled before you finish. -
Page 16: Ipod Operations
iPod Operations The iPod does not play, but “CONNECT” appears on the display. \ The iPod battery is low or exhausted. Charge the iPod battery. Radio Operations Hard to listen to broadcasts because of noise. \ Antennas connections are incorrect or loose. \ The AM loop antenna is too close to the System. -
Page 17: Listening To Digital Audio Player
Listening to Digital Audio Player The following operations are explained using the remote control, unless mentioned otherwise. However, if the System has the same or similar button names, they can also be used for the operations. Listening to Digital Audio Player Front view Digital Audio Player Stereo mini plug cord... -
Page 18: Setting The Clock And Using Timers
Setting the Clock and Using Timers The following operations are explained using the remote control, unless mentioned otherwise. However, if the System has the same or similar button names, they can also be used for the operations. Setting the Clock Without setting the built-in clock, you cannot use Daily Timer and Sleep Timer. -
Page 19: Setting The Daily Timer
Setting the Daily Timer Using Daily Timer, you can wake up with your favorite music. • You can store three Daily Timer settings; however, you can activate only one of the Daily Timers. Press repeatedly to select one of the timer setting modes you want to set—DAILY 1 ON time, DAILY 2 ON time, or DAILY 3 ON time—as follows: 1 Adjust the hour then the minute for on-time. -
Page 20: Maintenance
Maintenance To get the best performance of the System, keep your discs and mechanism clean. Handling discs • Remove the disc from its case by holding it at the edge while pressing the center hole lightly. • Do not touch the shiny surface of the disc, or bend the disc. •... -
Page 21: Specifications
Specifications Amplifier section OUTPUT POWER: 60 W (30 W + 30 W) at 4 Ω (10% THD) Speakers/Impedance: 4 Ω – 16 Ω Audio input AUDIO IN: 500 mV/50 kΩ (at “IN LVL1”) 250 mV/50 kΩ (at “IN LVL2”) 125 mV/50 kΩ (at “IN LVL3”) Digital input: iPod Tuner section... - Page 22 SAFETY INSTRUCTIONS “SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT” This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured. Do read the operating instructions before you attempt to use the equipment.
