Samsung IAB 146 4K Quick Setup Manual

Quick Setup Guide
IAB (IAB 146 4K / IAB 110 2K / IAB 146 2K)
* The colour and the appearance may differ depending on the product, and the content in the manual is subject to
change without prior notice to improve the performance.
* Download the user manual from the following Samsung Website for further details.
http://www.samsung.com/displaysolutions
Checking the Components
(1) Quick Setup Guide (2) Warranty card (Not available in some locations) (3) Regulatory guide
(4) Waste Electrical & Electronic Equipment (5) Power cord (IAB 146 4K, IAB 146 2K: x 2 / IAB 110 2K: x 1)
(6) Remote Control (7) Batteries (AAA x 2) (Not available in some locations) (8) RS232C adapter
(9) OCM cable (IAB 146 4K, IAB 146 2K: x 4 / IAB 110 2K: x 3)
(10) Power extension cable (IAB 146 4K, IAB 146 2K: x 2 / IAB 110 2K: x 1)
Contact the vendor where you purchased the product if any components are missing.
Components may differ in different locations.
Connecting the Power Cable
•Connect the power cable after all cables are connected.
•Before connecting external devices, be sure to disconnect the power cable.
•AC power cables may not be provided depending on the model. Contact the dealer from whom you purchased the
product if you want to be purchased separately.
Precautions when handling the cabinets
1
4
* Metal objects may adhere to the front surface of the cabinet due to its magnetism.
* If any metal object adheres, use a magnet or airgun to remove it. Be careful when removing metal objects using a
magnet, as the magnet may separate the module from the cabinet.
* Be careful when holding magnetic stripe cards close, as the magnetism may affect those cards.
[Caution to prevent external shock and dropping of the product]
1
After removing the protective brackets, be careful not to expose the product to external shocks or vibrations.
Make sure that the product is not dropped from any height.
[Caution to prevent damage to the LED]
2
Be careful not to expose the product to vibrations or external shocks when it is lying flat on the floor.
[Caution to prevent damage to corners]
3
Take extra care to ensure that the corners of a cabinet do not get damaged.
[Caution to prevent damage to the LED]
4
After removing the protective brackets, do not place the product on the floor with the LED facing down.
[Caution to prevent damage to the LED from static]
5
Do not touch the product without anti-static gloves.
• Be sure to wear anti-static gloves when touching the product.
[Caution to prevent damage to the LED]
6
When lifting the product, be careful that the module frame does not separate from the main frame.
