QUBINO Flush Dimmer Instructions

Flush Dimmer
EN: Flush Dimmer is a MOSFET-switching light device that also
supports control of low-voltage halogen lamps with electronic
transformers, dimmable compact fluorescent lights, and dimmable
LED bulbs. It measures power consumption of the connected device,
and can be paired with a digital temperature sensor (sold separately).
It supports push-button/momentary switches and toggle switches
(default).
PACKAGE CONTENTS
Flush Dimmer device, Installation Manual
INSTALLATION
1. To prevent electrical shock and/or equipment damage, disconnect
electrical power at the main fuse or circuit breaker before installation
and maintenance.
2. Be aware that even if the circuit breaker is off, some voltage may
remain in the wires — before proceeding with the installation, be sure
no voltage is present in the wiring.
3. Take extra precautions to avoid accidentally turning on the device
during installation.
4. Connect the device exactly according to the diagram.
5. Place the antenna as far as possible from metal elements as they
may cause signal interference.
6. Do not shorten the antenna.
Danger of electrocution!
Installation of this device requires a great degree of skill and may be
performed only by a licensed and qualified electrician. Please keep in
mind that even when the device is turned off, voltage may still be
present in the device's terminals.
Note!
Do not connect the device to loads exceeding the recommended
values. Connect the device exactly as shown in the provided diagrams.
Improper wiring may be dangerous and result in equipment damage.
Electrical installation must be protected by directly associated
overcurrent protection fuse 1A, gG or Time lag T, rated breaking
capacity 1500A (ESKA 522.717) must be used according to wiring
diagram to achieve appropriate overload protection of the device.
The fuse must be installed in fuse holder type: Adels contact 503Si/1
DS according to the standard IEC60669-2-1.
Z-WAVE INCLUSION
AUTO-INCLUSION
1. Enable inclusion mode on your Z-Wave gateway (hub)
2. Connect the device to the power supply (with the temperature
sensor already connected – sold separately*)
3. Auto-inclusion will be initiated within 5 seconds of connection to
the power supply and the device will automatically enroll in your
network
MANUAL INCLUSION
1. Connect the device to the power supply (with the temperature
sensor already connected*)
2. Toggle the switch connected to the I1 terminal 3 times within 3
seconds
OR
If the device is powered by 24 V SELV supply, press and hold the S
(Service) button for at least 2 seconds
3. A new dimming device (multilevel switch) will appear on your
dashboard
*Make sure the device is excluded from your network before
connecting the temperature sensor. Switch off the power supply,
connect the temperature sensor, and re-include the device to your
network.
