- Page 1 B-HYVE XR SMART INDOOR/OUTDOOR SPRINKLER TIMER...
-
Page 2: Contents In The Box
CONTENTS IN THE BOX B-hyve XR Smart Sprinkler Timer Mounting Screws and Anchors Quick Start Guide TIMER INSTALLATION Select a location Choose a location near power and away from direct sunlight, if possible. This location should also have a good Wi-Fi signal. - Page 3 Mount the timer Install a screw (included) into the wall. Use the expanding anchors (included) for plaster, masonry or drywall installations. Hang the timer on the installed screw using the keyhole slot. Level the timer and use the second screw in one of the preformed mounting holes to secure the timer.
- Page 4 CONNECT VALVE WIRES Prepare wire Strip 1/2” (13 mm) of insulation from each wire. Connect wires Push in one wire from each valve to a “Common” (COM) wire and the other wires to a numbered terminal (only one wire per terminal).
- Page 5 Open your B-hyve app, create an account or login, and follow the step-by-step process to add and set up your device. The B-hyve app will connect to your device and you will, then, be guided to connect to your home Wi-Fi network.
-
Page 6: Programming And Operation
Watering will continue, if Wi-Fi connection is lost. Manual operation All programming and full functionality of the timer are avail- able in the B-hyve app. If you have the need, there are some basic operations you can perform directly at your timer. FUNCTION BUTTON PRESS... - Page 7 Digital Lock-Out Enable/disable in app. Lights Off Mode Enable/disable in app. Hold for 10 seconds. On/Off Quickly press 5 times. Hard Reset *Default watering time for “WATER ALL ZONES” can be customized in the B-hyve App settings. instructions continued on back...
-
Page 8: The B-Hyve App
THE B-HYVE APP Install the B-hyve® app on your smart device You will need a smart device to connect the timer to Wi-Fi. timer connected weather symbol & temp. running status/ messaging stop watering rain delay next zone calendar settings... -
Page 9: Fcc & Ic Statement
FCC & IC Statement This device complies with Part 15 of the FCC Rules and Industry Canada license exempt RSS standards. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 10: Specifications
SPECIFICATIONS Rated input: Australia—240V AC 50/60Hz 0.15A Europe—230VAC 50/60Hz 0.15A USA—120V AC 60Hz 0.2A Max load: AUS & EU—24V AC 1 Amp 50/60 Cycle USA—24VAC 1 Amp 60Hz Temperature Operating Range: Operating: 32–158° F (0–70° C) Storage & transport: -4–176° F (-20–80° C) Humidity Operating Range: Operating: 0–80% | Storage &... -
Page 11: Need Help
Need Help? If the app and the website don’t have what you’re looking for, please go to our website before returning this sprinkler timer to the store. call us email us text us 1-801-299-5555 support@orbitbhyve.com 801-905-8260 or visit us at: mybhyve.com...
