- Page 1 Smart Connection Installation Guide...
-
Page 2: General Information
General information The Smart Connection Box controls Electronic Actuators, circulating pump and heat source or zone valve. The Smart Connection Box is a part of the heat management system for your home. One Smart Hub supports up to 4 Smart Connection Boxes. The Smart Connection Box has a range of functions: •... - Page 3 ⚠ Note: large metal objects located in the vicinity of or between the Smart Hub and the Smart Connection Box may have a negative effect on the quality of radio transmission between the devices. External antenna should be placed vertically. The device should be connected to a single- phase power system according to the standards in place.
- Page 4 LED output for the 3D valve pairing button relay output for 230V temperature input KTY-81-210 the circulating pump, max 0.5A protective earthing 12 outputs for electronic actuators antenna Wunda ...
- Page 5 Connecting to manifold The Smart Connection Box must be installed in a suitable location above the manifold within reach of the actuator power cables. All installation and connection steps should be performed by appropriately qualified and authorized persons in accordance with applicable regulations and standards.
- Page 6 to turn green. Open the WundaSmart application and log in to your Smart Hub, select the The installed Smart Connection Box will Devices from main menu and choose appear on the device list. Smart Connection Box. Configure heating zones (rooms) in your...
-
Page 7: Technical Data
Technical data Power supply 230V, ~50Hz IP rating IP20 protection class Permissible from 5–40°C, range of ambient without temperatures condensation Pump circuit load to 0.5A Electronic 12×230V, 20W actuator circuit max Per Channel load Internal Fuses Radio 869.85MHz, communications: two-way Maximum trans- <5 dBm e.r.p.
