Quick Start Guide
Heat pump tumble dryer
These short instructions are not a substitute for the operating instructions supplied with
the appliance. Please read the operating instructions supplied with your tumble dryer
before using it for the first time and take note of the Warning and Safety instructions, as
well as the full descriptions on how to use your appliance.
en-AU, NZ
M.-Nr. 11 909 410 / 00
Advertisement
Table of Contents
Related Manuals for Miele Heat pump tumble dryer
Summary of Contents for Miele Heat pump tumble dryer
- Page 1 Quick Start Guide Heat pump tumble dryer These short instructions are not a substitute for the operating instructions supplied with the appliance. Please read the operating instructions supplied with your tumble dryer before using it for the first time and take note of the Warning and Safety instructions, as well as the full descriptions on how to use your appliance.
-
Page 2: Using For The First Time
Using for the first time Before commissioning the tumble dryer for the first time, make sure it has been installed correctly. Connect it correctly. Please read the separate operating instructions supplied with the appliance. Damage caused by switching the appliance on too soon. -
Page 3: Operation
Values that With MobileControl you can operate your have not yet been confirmed are not saved tumble dryer remotely with the Miele App. when you return to the main menu. Drying assistant ... -
Page 4: Operating The Touch Display
MobileStart off. The tumble dryer switches off With MobileControl you can operate your automatically to save energy. This tumble dryer remotely with the Miele App. occurs 15 minutes after the end of the programme/Anti-crease phase, or after Drying assistant... -
Page 5: Preparing The Laundry
Preparing the laundry Damage due to foreign objects which were not removed from the laundry. Foreign objects can melt, burn, or explode. Remove foreign objects (e.g. detergent dispenser, loose bra hangers, lighter and all objects) from the laundry. ... - Page 6 fold here Condensed water container Door Control panel Plinth filter access panel Cold air intake grille When selecting Wash2Dry After the programme has finished in the washing machine, the tumble dryer display will show the most appropriate drying programme for the laundry. ...
-
Page 7: Selecting A Programme
1. Selecting a programme Touch the Programmes sensor. Programmes 11:02 Cottons Minimum iron 0:00 0:00 Cottons Delicates 0:00 0:00 Help Scroll to the right of the display until the programme you want appears. ... - Page 8 Selecting the programme duration You can select a programme duration for the programmes Cool air, Warm air, Basket programme. Duration Touch the sensor (only in the Warm air programme). Place your finger on the number that you want to change and move your finger in the desired direction.
-
Page 9: Starting The Programme
3. Starting the programme Touch the flashing Start/Stop sensor. The Start/Stop sensor lights up and the programme starts. When Delay start is being used, the programme duration will appear after the Delay start time has elapsed. HygieneDry drying level: the HygieneDry drying process starts at the end of the normal drying process and must not be interrupted. -
Page 10: At The End Of The Programme
End of the programme At the end of the programme Finish/ The programme is finished when Anti-crease appears in the display. The Start/Stop sensor will no longer light up. - 10 minutes after the end of the programme the Start/Stop sensor will begin to flash slowly and the display will go out. -
Page 11: Emptying The Condensed Water Container
Emptying the condensed water container Empty the condensed water container after every drying programme. The Empty the container or check the drain outlet. indicator will light up if the maximum level of the condensed water container is reached. ... - Page 12 FragranceDos Useful tip: This tumble dryer has 2 sockets for inserting fragrance flacons. You can use one or both sockets to give your laundry a pleasant fragrance. Close the unused socket. Before using a fragrance flacon, please read "Warning and Safety instructions - Using a fragrance flacon (optional accessory)"...
- Page 13 Setting the fragrance intensity The further you turn the outer ring of the fragrance flacon clockwise, the more intense the fragrance. Closing the fragrance flacon Turn the outer ring anti- clockwise until marker is in position . Removing the fragrance flacon ...
- Page 14 Programme Load [weight Items Extras of dry laundry] Cottons 9 kg Cotton items such as those described under Cottons – – – – – – – Normal with normal residual moisture. Cottons 9 kg Towelling, jersey wear, T-shirts, underwear, baby ...
-
Page 15: Cleaning And Care
Cleaning and care Fluff filter Removing visible fluff Clean the 2 fluff filters in the door opening at the end of every programme. Remove the fragrance flacon. Pull the upper fluff filter forwards to remove it. Use your fingers or a vacuum cleaner ... - Page 16 Cleaning the fluff filters and air flow openings thoroughly If the drying duration has become longer or the surface of the filters is visibly compacted with fluff, you should carry out the following cleaning procedure. Pull the upper fluff filter forwards to remove it.
-
Page 17: Plinth Filter
Plinth filter Clean the plinth filter when the programme cycle time is longer than usual. Clean it whenever the Clean the fluff and plinth filters. See the operating instruction manual for more information. message lights up too. To delete the message: Confirm with OK. ... - Page 18 Refitting the plinth filter Fit the plinth filter back on the handle the right way round. Push the plinth filter in completely. Insert the right guide pin at the same time. Close the panel.
- Page 19 Problem solving guide Problem Possible cause and remedy Access via a code has been activated. You must enter the correct PIN code to use the tumble dryer. See “Settings – Code” in the operating instructions. Empty the container or The condensed water container is full or there is a kink in the drain hose.
- Page 20 Problem Possible cause and remedy The display is in a A different language has been selected in "Settings – Language ". different language. Set the language you want. The flag symbol serves as a guide. The display remains dark, There is no power to the tumble dryer.
