PV110 Power Bank User's Manual
Overview
Front view
Product Features
Six layers of circuit protection (overcharge protection / over-discharge protection / over-temperature
●
protection / short circuit protection / over voltage protection / over-current protection)
Fine brushed aluminum exterior
●
3.1A (Max) Dual USB output
●
Fast charging
●
Power saving automatic shut down
●
LED power indicator
●
Specifications
Battery capacity: 10400mAh (Lithium-ion rechargeable battery 37.44Wh)
●
Rated voltage: Input 5V DC/1.5A (Micro-USB)
●
Output 1 DC 5V, 1A (Type-A USB)
Output 2 DC 5V, 2.1A (Type-A USB)
Charging time: 7~9 hours
●
Dimensions: 102 x 77 x 21.5mm/4.0 x 3.0 x 0.8in
●
Weight: 260g/9.2oz
●
Operating Temperature: 0°C~45°C
●
Note: Rated capacity for this product is: 7000mAh (35 Wh, DC 5V, 1A) / 6450mAh (32.25Wh：DC 5V, 2.1A)
Power Display
Press the Power ON/OFF to display the power status.
Indicator
Power display
Light on
1 . Power bank is charging
Flashing
2. Low battery warning
Dim light Standby / No power
Side View
Power / Indicator button
Status
25%
50%
Power indicator
MicroUSB Input
Output
75%
100%
