Summary of Contents for Lenovo ideacentre AIO 720 Series
- Page 1 ideacentre AIO 720 Series Quick Start Guide...
- Page 2 Unpacking Computer Keyboard* Mouse* Power cord Publications * Selected models only. 1. Some models may contain items that are not listed. 2. The descriptions in this guide might be different from what you see on your computer, depending on the computer model and configuration. 3.
-
Page 3: Adjusting The Computer Stand
Adjusting the computer stand Connecting the keyboard and mouse NOTE: If your computer is equipped with a wireless keyboard or mouse, follow the installation instructions for those devices. - Page 4 Connecting the power cable Turning on the computer...
-
Page 5: Front View Of The Computer
Front view of the computer Camera LED indicator Built-in microphone Built-in camera NOTE: Remove the plastic film before using the computer. ATTENTION: Be sure not to block any air vents on the computer. Blocked air vents may cause thermal problems. ATTENTION: If your computer is equipped with an infrared (IR) remote control, do not put the USB IR receiver on the same plane as the screen. -
Page 6: Left And Right View Of The Computer
Left and right view of the computer USB 3.0 connector HDMI-in switch Memory card reader Power button Combo audio jack Combo audio jack: Used to connect headsets. NOTES: • The combo audio jack does not support conventional microphones. • Different industry standards may lead to the recording function not being supported if third-party headphones or headsets are connected. -
Page 7: Rear View Of The Computer
Rear view of the computer Security cable slot USB 2.0 connector Power connector USB 3.0 connector Ethernet connector HDMI-in connector HDMI-out connector Air vents USB 2.0 connector... -
Page 8: Connecting To The Internet
Connecting to the Internet You need a contract with an Internet Service Provider (ISP) and some hardware in order to connect to the Internet. ISPs and the services they offer vary by country. Contact your ISP for services available in your country. Your computer supports wireless (selected models only) or wired networks that connect your computer to other devices. -
Page 9: Windows Help System
The following information describes the technical support that is available for your product, during the warranty period or throughout the life of your product. Refer to the Lenovo Limited Warranty for a full explanation of Lenovo warranty terms. See “Lenovo Limited Warranty notice” later in this document for details on accessing the full warranty. -
Page 10: Accessing Other Manuals
For models without Lenovo Companion: Open the Start menu and then click or tap Manual to access this guide. For models without preinstalled operating systems: Go to the Lenovo Support Web site to access your manuals. See “Downloading manuals” for additional information. Downloading manuals The latest electronic publications for your computer are available from the Lenovo Support Web site. -
Page 11: Replacing Or Upgrading Hardware
If you no longer have this copy of the Safety, Warranty, Environment, Recycling Information Guide and Important Product Information Guide, you can obtain one online from the website at http://www.lenovo.com/UserManuals. Pre-disassembly instructions Before proceeding with the disassembly procedure, make sure that you do the following: 1. - Page 12 Replacing or upgrading hardware Removing the computer cover Removing the hard disk drive...
- Page 13 Replacing or upgrading hardware Replacing a memory module Replacing the solid state drive...
- Page 14 The following information refers to ideacentre AIO 720 machine type: F0CM [AIO 720-24IKB/Energy Star] Lenovo, the Lenovo logo and ideacentre are trademarks of Lenovo in the United States, other countries, or both. Windows is a trademark of the Microsoft group of companies.
