  • Page 1 Send 1 commeo Send 10 commeo Send WS 10 commeo Wall Send Betriebsanleitung Bitte sorgfältig aufbewahren! Operating instruction Please keep in a safe place! Notice de réglage Prière de conserver cette notice ! Afstelhandleiding Deze handleiding zorgvuldig bewaren! Instrukcja obsługi...

  • Page 2: Anzeigen- Und Tastenerklärung

    commeo Send 1/Send 10/Send WS 10 commeo Wall Send Anzeigen- und Tastenerklärung 1 AUF-Taste, 2 STOPP-Taste, 3 AB-Taste, 4 Status-LED, 5 Hand-/Automatik -Schiebe schalter, 6 Gruppenauswahl tasten (modellabhängig), 7 Gruppen-Kontroll leuchten (modellabhängig), 8 Programmier-Taste/PROG, 9 Select-Taste/SELECT E xplanation of displays and b uttons 1 UP button, 2 STOP button, 3 DOWN button, 4 Status LED, 5 Manual/auto m atic sliding switch, 6 Group selectors (model dependent), 7 Group control lights (model depen d ent), 8 Programming button/PROG, 9 Select button/SELECT...

  • Page 3: Changing The Battery

    commeo Send 1/Send 10/Send WS 10 commeo Wall Send Batteriewechsel 1. Send 1/Send 10/Send WS 10: Lösen Sie die Schraube und ziehen Sie die Klammer ab. Wall Send: Ziehen Sie das Bedienteil ab. 2. Entnehmen Sie die Batterien. 3. Legen Sie die neuen Batterien lagerichtig ein. Send 1/Send 10: LR 03; AAA. Wall Send: CR 2032 Changing the battery 1. S end 1/Send 10/Send WS 10: Unbolt the screw and pull of the clip.

  • Page 4: Montage Wandhalterung

    commeo Send 1/Send 10/Send WS 10 Montage Wandhalterung Befestigen Sie die Halterung mit den zwei beige- legten Dübeln und Schrauben an der Wand. Installing the wall mount F ix the mount to the wall with the two screws p rovided.
  • Page 5 commeo Wall Send Montage Wandhalterung Befestigen Sie die Halterung mit den zwei beige- legten Dübeln und Schrauben an der Wand. Installing the wall mount F ix the mount to the wall with the two screws p rovided.

  • Page 6: Technische Daten

    Technische Daten Technische Änderungen vorbehalten. Technical data Subject to technical modifications. Caractéristiques techniques Sous réserve de modifications techniques. Technische data Technische wijzigingen voorbehouden. Dane techniczne Zastrzega się możliwość wprowadzenia zmian technicznych. 55 °C IP 20 868,1/ 0 °C 868,3 MHz, max. 10 mW < 25 m...
  • Page 7 General and designated use With the SELVE commeo radio transmitters, you can control any receiver and radio drive of the SELVE commeo range. They should only be used for this purpose. Please read these instructions before commissioning of your product and o bserve the safety notes. The instructions must be provided to the customer. The product must only be commissioned by authorised specialists. Explanation of functions/terms used Status LED A radio signal is indicated by the status LED lighting up green. In case of error, the LED will switch from green to red...
  • Page 8 Note for commeo Send WS 10: For setting or changing the wind and sunlight threshold values: see operating instruction commeo Sensor WS/WSRF. Intermediate position 1 T he intermediate position is a position between the upper and lower end l imits that can be freely s elected. Set intermediate position 1: Operation Move the drive to the upper end position with the UP button. Push the STOP button and then additionally push the DOWN button. Keep both pushed. After 3 seconds, the >3 s programming run starts. Set the position with the DOWN and UP buttons while keeping the STOP button pushed. Releasing the STOP b utton will save the position. Travel to intermediate position 1: Operation Push the DOWN button twice quickly in sequence.

  • Page 9: Transmitter Programming Procedure

    Intermediate position 2 (ventilation/tilt) T he intermediate position is a position between the upper and lower end l imits that can be freely s elected. Set intermediate position 2: Operation Move the drive to the lower end position with the DOWN button. Push the STOP button and then additionally push the UP button. Keep both pushed. After >3 s 3 seconds, the program- ming run starts. Set the position with the UP and DOWN buttons while keeping the STOP button pushed. Releasing the STOP b utton will save the position. Travel to intermediate position 2: Operation Push the UP button twice quickly in sequence. Transmitter programming procedure For instructions, see the receiver/drive manual.
  • Page 10 Conversion inching mode/lock The transmitter can be switched over to a inching mode using a key combination to easily set the turn of a venetian blind. After the switching, the control panel and all channels have the inch- ing mode. Upon delivered, the transmitter drives the motors in immediate lock.

  • Page 11: Safety Instructions

    Safety instructions • Use in dry rooms only. • K eep persons away from the systems o perating range. Warning! • Keep children away from controls. • Always observe country-specific regulations. • D ispose of used batteries properly. • I f the system is controlled by one or more de v ices, the system operating range must be v isible during operation. Note radio system: • E nsure that the controls are not installed and operated in the v icinity of metal surfaces or magnetic fields. • B efore installing in the position required, check that the trans m itter and receiver are functioning properly.

  • Page 12: Allgemeine Konformitätserklärung

    Vorschriften der Richtlinie 2014/53/EU befindet. Die Konformitätserklärung ist einsehbar unter www.selve.de. General conformity declaration T he company SELVE GmbH & CO. KG, hereby d eclares that the commeo Send 1/Send 10/Send WS 10/commeo Wall Send is in conformity with the basic require m ents and other r elevant provisions of the Directive 2014/53/EU. The declara t ion of con- formity can be seen at www.selve.de.
