- Page 1 Portable Power Hub Quick Start Guide...
-
Page 2: What's In The Box
Check to make sure you What’s in the Box? have everything below. Quick Start Guide 1. Portable Power Hub 2. Quick Start Guide 3. 15V 2A adapter... - Page 3 Get to Know Your Portable Power Hub Handle USB-A Output Ports Automobile Auxiliary Power USB-C Output Port Outlet Power Delivery USB-C Port LCD Display USB Output Control Button LED Indicator for Powerhub LED Indicator for DC Ports Main Power Button Display...
- Page 4 Get to Know Your Portable Power Hub 15.Ambient Light 18.Flashlight Light 16.Ambient Light Button 19.Flashlight Light Button 17.DC Input Port 20.AC Output Port 21.AC Output Control Button...
- Page 5 Get to Know Your Portable Power Hub 23 24 25 26 27 22.LED Indicator for speaker and Weather Radio 23.Power on / off (Speaker) 24.Volume Down / Previous Track 25.Volume Up / Next Track 26.Bluetooth / Play / Pause 27.NOAA Weather Radio...
-
Page 6: Lcd Display
Portable Power Hub. BATTERY LEVEL: Shows in increments of 10, up to 100 capacity. When charging your Portable Power Hub you will notice a battery segment blinking, this indicates the current charge status. Once fully charged, all battery segments will be lit and remain white solid. - Page 7 Device to Portable Power Hub IMPORTANT: Press & hold 10 seconds to activate the Portable Power Hub for INITIAL USE ONLY. PRESS & HOLD INITIAL USE ONLY Next time, you can follow below steps to charge your device. * By automobile auxiliary power outlet Press &...
- Page 8 Device to Portable Power Hub *By AC output port Press Once Press & Hold *By USB-A output ports Press & Hold Press Once...
- Page 9 Device to Portable Power Hub *By DC output ports Press & Hold Press Once TIPS: 1.When any of the control buttons are turned on, even if no devices are being charged, there will still be a certain amount of no-load power consumption.
-
Page 10: Light Mode
Light Mode Flashlight Mode Press once to toggle between low brightness, full brightness, SOS, and no brightness mode. Press Press Press Once Once Once Ambient Light Mode Press once to toggle between low brightness, medium brightness, high brightness and no brightness. Press Once... - Page 11 (not included) Preferred AC Socket (included) (not included) Solar Panel * By Power Delivery USB-C Port USB-C PD Port (not included) * You can charge your Portable Power Hub with DC IN port and USB-C PD Port at the same time.
- Page 12 Power on / o the Speaker Press & hold to power on / off the speaker Press & Hold ON/OFF...
-
Page 13: Bluetooth Connection
Bluetooth® Connection In Bluetooth mode, activate the Bluetooth function on your device and search Bluetooth devices, then select “onn. POWERHOUSE” to start connecting. Press & Hold Press Once Search Devices Press & Hold Press Once Play / Pause Press Once onn. -
Page 14: Noaa Weather Radio
NOAA Weather Radio Press once WB button to search for Weather Band, the LED indicator will be solid green. The radio will find the strongest signal Weather Band channel from the local radio. Press & hold WB button to activate or exit auto-wake-up mode. The LED indicator will flash slowly, and you will receive every advisory, watch and warning automatically once activated. -
Page 15: Hints And Tips
Hints and Tips Portable Power Hub will automatically turns off when the power of the device exceeds the rated output power (200W). The LCD display will alert when the power system detects that the device being used is shorted or overloaded. Please confirm whether the device parameter specifications meet the scope of the Portable Power Hub before using it. -
Page 16: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS flammable surface. Do not obstruct any vents on the Charger. Especially avoid placing the charger on carpets and rugs; they are not only flammable, but they also obstruct vents under the charger. Place the Charger on a stable, solid, nonflammable surface (such as a stable metal workbench or concrete floor) at least 1 foot away from all flammable objects, such as drapes or walls. - Page 17 IMPORTANT SAFETY INSTRUCTIONS Lithium Battery Safety Warnings： LITHIUM BATTERIES STORE A LARGE AMOUNT OF ENERGY AND WILL VENT FIRE OR EXPLODE IF MISTREATED: 1. Keep Battery pack dry. 2. DO NOT DO ANY OF THE FOLLOWING TO THE BATTERY PACK: a.
-
Page 18: Legal & Compliance
LEGAL & COMPLIANCE 1. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 2. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 19 LEGAL & COMPLIANCE 3. RF Exposure Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. 4. Rating Lable is located at the bottom of the product.
- Page 20 IMPORTANT SAFETY INSTRUCTIONS WARNING – When using this product, basic precautions should always be followed, including the following: a) Read all the instructions before using the product. b) To reduce the risk of injury, close supervision is necessary when the product is used near children. c) Do not put fingers or hands into the product.
-
Page 21: Personal Precautions
IMPORTANT SAFETY INSTRUCTIONS DANGEROUS. BATTERIES GENERATE EXPLOSIVE GASES DURING NORMAL BATTERY OPERATION. FOR THIS REASON, IT IS OF THE UTMOST IMPORTANCE THAT YOU FOLLOW THE INSTRUCTIONS EACH TIME YOU USE THE POWER PACK. 2) To reduce risk of battery explosion, follow these instruc- tions and those published by battery manufacturer and manufacturer of any equipment you intend to use in vicinity of the battery. - Page 22 IMPORTANT SAFETY INSTRUCTIONS 7) Remove personal metal items such as rings, bracelets, necklaces, and watches when working with a Other battery battery. A Other battery battery can produce a shortcircuit current high enough to weld a ring or the like to metal, causing a severe burn.
- Page 23 IMPORTANT SAFETY INSTRUCTIONS 2) Each step shall be a different numbered item. PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRAN- TY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALI- FIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE...
- Page 24 IMPORTANT SAFETY INSTRUCTIONS Personal Safety； 1. Stay alert, watch what you are doing and use common sense when operating a Power Hub. Do not use a Power Hub while you are tired or under the influence of drugs, alcohol or medication.
- Page 25 IMPORTANT SAFETY INSTRUCTIONS 7. Only use safety equipment that has been approved by an appropriate standards agency.Unapproved safety equipment may not provide adequate protection. Eye protection must be ANSI-approved and breathing protection must be NIOSH-ap- proved for the specific hazards in the work area. Service：Have your Power Hub serviced by a qualified repair person using only identical replacement parts.
- Page 26 100069441 We’d love to hear from you. Scan with your Walmart app and let us know what you think. 81131 41437 Need help? We're here for you every day 7 a.m. – 9 p.m. CST. 1-888-516-2630 Give us a call!
