Summary of Contents for Inrico TM-7
- Page 1 English TM 7 P us) User manual Thank you for purchasing our machine...
- Page 2 Instructionsbefore use: Do not use the mobile radio or charge the batter y in the explosive environments (such as gas, dust, steam,etc.); In the gas or parking on the gas stationplease turn off the mobile radio; The machine can not be modified or adjusted for any reason;...
- Page 3 Machine Chart: Indicator LOGO LampLCD On /off Turn up Knob key (Turn left or right to Turn down adjust the volume Press OK) Fixed bracket screw Return interface Fixed bracket Customized button SIMswitch key 2G/3G switch key Customized button GPS antenna interface DC power interface External main antenna interface (To Reserve) SIM inserting slot...
-
Page 4: Installation
Installation: Insert the SIM card, cover on the SIM holder and tighten the screws. SIM卡 SIM卡 SIMinserting slot Rotate clockwise until the antenna is tightened. and pay attention to the antenna. - Page 5 Connect with the power supply. Dc Power Input Insert GPS antenna / external main antenna. GPS antenna interface External antenna（customized） To Reserve Plug in the microphone. Hand microphone interface...
-
Page 6: Basic Functions
Basic functions: First boot: Make sure the power is plugged in. Boot: press and hold the button until the screen appears on the screen.Some SIM cards will have pin code protection. If there is an input pin code prompt, please input your PIN code.The initial password of PIN code is1234. - Page 7 Functions: Message Click into the message interface, it will display the list of message received, you can edit, send, and delete message. Calendar It allows you to access your calendar and eventsat any time. You can view the calendar respectively, You can also view several calendars at the same time.
- Page 8 ②Release PTT to finish the talk ③Receive message Green light means receiving 3. Volume Adjustment ①The radio volume can be adjusted by volume keys. ②Adjust volume via sliding volume bar...
-
Page 9: Security Information
4.It will alarm automatically after 2 seconds when emergence and pressing SOS button. 5.P1/P2/P3/P4 keys are customized, you can define quick contact or group. 6. Press return button to exit platform and back to the main interface. security information Before using the equipment, please read and follow the precautions as below, to ensure the best performance of equipment, and avoid dangerous or illegal situations. -
Page 10: Maintenance & Service
flammable and explosive materials, chemicals and any other explosive areas, please do not use the equipment, equipment may cause fire or explosion. Operating environment Please do not use equipment in dusty, humid, air dirty or near the magnetic field, so as to avoid internal circuit fault.
