QUICK INSTALLATION GUIDE
GO-SW-16G/GO-SW-24G 16/24-PORT GIGABIT UNMANAGED SWITCH
ENGLISH
SET UP
1
2
3
LED
LED INDICATIONS
LED
Color
Power
Green
(system)
Green
Link/Act/
Speed
(port)
Amber
RACK INSTALLATION
To install in a rack, attach the mounting brackets
to the switch's side panels (one on each side) and
secure them with the screws provided. Then, use the
hardware provided with the equipment rack to mount
the switch in the rack.
State
Description
Device is powered
Solid Light
on
Device is powered
Light off
off
Device connected
Solid Light
at 1000 Mbps
Blinking
Activity on the port
Device connected
Solid Light
at 10/100 Mbps
Blinking
Activity on the port
